Documentation/ABI/stable/sysfs-class-backlight

@@ -34,3 +34,23 @@ Contact:	Richard Purdie <rpurdie@rpsys.net>
 Description:
 		Maximum brightness for <backlight>.
 Users:		HAL
+
+What:		/sys/class/backlight/<backlight>/type
+Date:		September 2010
+KernelVersion:	2.6.37
+Contact:	Matthew Garrett <mjg@redhat.com>
+Description:
+		The type of interface controlled by <backlight>.
+		"firmware": The driver uses a standard firmware interface
+		"platform": The driver uses a platform-specific interface
+		"raw": The driver controls hardware registers directly
+
+		In the general case, when multiple backlight
+		interfaces are available for a single device, firmware
+		control should be preferred to platform control should
+		be preferred to raw control. Using a firmware
+		interface reduces the probability of confusion with
+		the hardware and the OS independently updating the
+		backlight state. Platform interfaces are mostly a
+		holdover from pre-standardisation of firmware
+		interfaces.

Documentation/ABI/testing/configfs-spear-pcie-gadget

@@ -0,0 +1,31 @@
+What:		/config/pcie-gadget
+Date:		Feb 2011
+KernelVersion:	2.6.37
+Contact:	Pratyush Anand <pratyush.anand@st.com>
+Description:
+
+	Interface is used to configure selected dual mode PCIe controller
+	as device and then program its various registers to configure it
+	as a particular device type.
+	This interfaces can be used to show spear's PCIe device capability.
+
+	Nodes are only visible when configfs is mounted. To mount configfs
+	in /config directory use:
+	# mount -t configfs none /config/
+
+	For nth PCIe Device Controller
+	/config/pcie-gadget.n/
+		link ... used to enable ltssm and read its status.
+		int_type ...used to configure and read type of supported
+			interrupt
+		no_of_msi ... used to configure number of MSI vector needed and
+			to read no of MSI granted.
+		inta ... write 1 to assert INTA and 0 to de-assert.
+		send_msi ... write MSI vector to be sent.
+		vendor_id ... used to write and read vendor id (hex)
+		device_id ... used to write and read device id (hex)
+		bar0_size ... used to write and read bar0_size
+		bar0_address ... used to write and read bar0 mapped area in hex.
+		bar0_rw_offset ... used to write and read offset of bar0 where
+			bar0_data will be written or read.
+		bar0_data ... used to write and read data at bar0_rw_offset.

Documentation/ABI/testing/pstore

@@ -1,6 +1,6 @@
 Where:		/dev/pstore/...
-Date:		January 2011
-Kernel Version: 2.6.38
+Date:		March 2011
+Kernel Version: 2.6.39
 Contact:	tony.luck@intel.com
 Description:	Generic interface to platform dependent persistent storage.

@@ -11,7 +11,7 @@ Description:	Generic interface to platform dependent persistent storage.
 		of the console log is captured, but other interesting
 		data can also be saved.

-		# mount -t pstore - /dev/pstore
+		# mount -t pstore -o kmsg_bytes=8000 - /dev/pstore

 		$ ls -l /dev/pstore
 		total 0
@@ -33,3 +33,9 @@ Description:	Generic interface to platform dependent persistent storage.
 		will be saved elsewhere and erased from persistent store
 		soon after boot to free up space ready for the next
 		catastrophe.
+
+		The 'kmsg_bytes' mount option changes the target amount of
+		data saved on each oops/panic. Pstore saves (possibly
+		multiple) files based on the record size of the underlying
+		persistent storage until at least this amount is reached.
+		Default is 10 Kbytes.

Documentation/ABI/testing/sysfs-bus-media

@@ -0,0 +1,6 @@
+What:		/sys/bus/media/devices/.../model
+Date:		January 2011
+Contact:	Laurent Pinchart <laurent.pinchart@ideasonboard.com>
+		linux-media@vger.kernel.org
+Description:	Contains the device model name in UTF-8. The device version is
+		is not be appended to the model name.

Documentation/ABI/testing/sysfs-bus-pci-devices-cciss

@@ -59,3 +59,15 @@ Kernel Version: 2.6.31
 Contact:	iss_storagedev@hp.com
 Description:	Displays the usage count (number of opens) of logical drive Y
 		of controller X.
+
+Where:		/sys/bus/pci/devices/<dev>/ccissX/resettable
+Date:		February 2011
+Kernel Version:	2.6.38
+Contact:	iss_storagedev@hp.com
+Description:	Value of 1 indicates the controller can honor the reset_devices
+		kernel parameter.  Value of 0 indicates reset_devices cannot be
+		honored.  This is to allow, for example, kexec tools to be able
+		to warn the user if they designate an unresettable device as
+		a dump device, as kdump requires resetting the device in order
+		to work reliably.
+

Documentation/ABI/testing/sysfs-bus-rbd

@@ -1,6 +1,6 @@
 What:		/sys/bus/rbd/
 Date:		November 2010
-Contact:	Yehuda Sadeh <yehuda@hq.newdream.net>,
+Contact:	Yehuda Sadeh <yehuda@newdream.net>,
 		Sage Weil <sage@newdream.net>
 Description:


Documentation/ABI/testing/sysfs-devices-mmc

@@ -0,0 +1,21 @@
+What:		/sys/devices/.../mmc_host/mmcX/mmcX:XXXX/enhanced_area_offset
+Date:		January 2011
+Contact:	Chuanxiao Dong <chuanxiao.dong@intel.com>
+Description:
+		Enhanced area is a new feature defined in eMMC4.4 standard.
+		eMMC4.4 or later card can support such feature. This kind of
+		area can help to improve the card performance. If the feature
+		is enabled, this attribute will indicate the start address of
+		enhanced data area. If not, this attribute will be -EINVAL.
+		Unit Byte. Format decimal.
+
+What:		/sys/devices/.../mmc_host/mmcX/mmcX:XXXX/enhanced_area_size
+Date:		January 2011
+Contact:	Chuanxiao Dong <chuanxiao.dong@intel.com>
+Description:
+		Enhanced area is a new feature defined in eMMC4.4 standard.
+		eMMC4.4 or later card can support such feature. This kind of
+		area can help to improve the card performance. If the feature
+		is enabled, this attribute will indicate the size of enhanced
+		data area. If not, this attribute will be -EINVAL.
+		Unit KByte. Format decimal.

Documentation/ABI/testing/sysfs-driver-samsung-laptop

@@ -0,0 +1,19 @@
+What:		/sys/devices/platform/samsung/performance_level
+Date:		January 1, 2010
+KernelVersion:	2.6.33
+Contact:	Greg Kroah-Hartman <gregkh@suse.de>
+Description:	Some Samsung laptops have different "performance levels"
+		that are can be modified by a function key, and by this
+		sysfs file.  These values don't always make a whole lot
+		of sense, but some users like to modify them to keep
+		their fans quiet at all costs.  Reading from this file
+		will show the current performance level.  Writing to the
+		file can change this value.
+			Valid options:
+				"silent"
+				"normal"
+				"overclock"
+		Note that not all laptops support all of these options.
+		Specifically, not all support the "overclock" option,
+		and it's still unknown if this value even changes
+		anything, other than making the user feel a bit better.

Documentation/ABI/testing/sysfs-fs-ext4

@@ -48,7 +48,7 @@ Description:
 		 will have its blocks allocated out of its own unique
 		 preallocation pool.

-What:		/sys/fs/ext4/<disk>/inode_readahead
+What:		/sys/fs/ext4/<disk>/inode_readahead_blks
 Date:		March 2008
 Contact:	"Theodore Ts'o" <tytso@mit.edu>
 Description:
@@ -85,7 +85,14 @@ Date:		June 2008
 Contact:	"Theodore Ts'o" <tytso@mit.edu>
 Description:
 		Tuning parameter which (if non-zero) controls the goal
-		inode used by the inode allocator in p0reference to
-		all other allocation hueristics.  This is intended for
+		inode used by the inode allocator in preference to
+		all other allocation heuristics.  This is intended for
 		debugging use only, and should be 0 on production
 		systems.
+
+What:		/sys/fs/ext4/<disk>/max_writeback_mb_bump
+Date:		September 2009
+Contact:	"Theodore Ts'o" <tytso@mit.edu>
+Description:
+		The maximum number of megabytes the writeback code will
+		try to write out before move on to another inode.

Documentation/ABI/testing/sysfs-fs-pstore

@@ -1,7 +0,0 @@
-What:		/sys/fs/pstore/kmsg_bytes
-Date:		January 2011
-Kernel Version: 2.6.38
-Contact:	"Tony Luck" <tony.luck@intel.com>
-Description:
-		Controls amount of console log that will be saved
-		to persistent store on oops/panic.

Documentation/ABI/testing/sysfs-platform-asus-wmi

@@ -0,0 +1,31 @@
+What:		/sys/devices/platform/<platform>/cpufv
+Date:		Oct 2010
+KernelVersion:	2.6.37
+Contact:	"Corentin Chary" <corentincj@iksaif.net>
+Description:
+		Change CPU clock configuration (write-only).
+		There are three available clock configuration:
+		    * 0 -> Super Performance Mode
+		    * 1 -> High Performance Mode
+		    * 2 -> Power Saving Mode
+
+What:		/sys/devices/platform/<platform>/camera
+Date:		Jan 2010
+KernelVersion:	2.6.39
+Contact:	"Corentin Chary" <corentincj@iksaif.net>
+Description:
+		Control the camera. 1 means on, 0 means off.
+
+What:		/sys/devices/platform/<platform>/cardr
+Date:		Jan 2010
+KernelVersion:	2.6.39
+Contact:	"Corentin Chary" <corentincj@iksaif.net>
+Description:
+		Control the card reader. 1 means on, 0 means off.
+
+What:		/sys/devices/platform/<platform>/touchpad
+Date:		Jan 2010
+KernelVersion:	2.6.39
+Contact:	"Corentin Chary" <corentincj@iksaif.net>
+Description:
+		Control the card touchpad. 1 means on, 0 means off.

Documentation/ABI/testing/sysfs-platform-eeepc-wmi

@@ -1,10 +0,0 @@
-What:		/sys/devices/platform/eeepc-wmi/cpufv
-Date:		Oct 2010
-KernelVersion:	2.6.37
-Contact:	"Corentin Chary" <corentincj@iksaif.net>
-Description:
-		Change CPU clock configuration (write-only).
-		There are three available clock configuration:
-		    * 0 -> Super Performance Mode
-		    * 1 -> High Performance Mode
-		    * 2 -> Power Saving Mode

Documentation/Changes

@@ -35,7 +35,7 @@ o  util-linux             2.10o                   # fdformat --version
 o  module-init-tools      0.9.10                  # depmod -V
 o  e2fsprogs              1.41.4                  # e2fsck -V
 o  jfsutils               1.1.3                   # fsck.jfs -V
-o  reiserfsprogs          3.6.3                   # reiserfsck -V 2>&1|grep reiserfsprogs
+o  reiserfsprogs          3.6.3                   # reiserfsck -V
 o  xfsprogs               2.6.0                   # xfs_db -V
 o  squashfs-tools         4.0                     # mksquashfs -version
 o  btrfs-progs            0.18                    # btrfsck
@@ -46,9 +46,9 @@ o  isdn4k-utils           3.1pre1                 # isdnctrl 2>&1|grep version
 o  nfs-utils              1.0.5                   # showmount --version
 o  procps                 3.2.0                   # ps --version
 o  oprofile               0.9                     # oprofiled --version
-o  udev                   081                     # udevinfo -V
-o  grub                   0.93                    # grub --version
-o  mcelog		  0.6
+o  udev                   081                     # udevd --version
+o  grub                   0.93                    # grub --version || grub-install --version
+o  mcelog                 0.6                     # mcelog --version
 o  iptables               1.4.2                   # iptables -V



Documentation/CodingStyle

@@ -168,6 +168,13 @@ Do not unnecessarily use braces where a single statement will do.
 if (condition)
 	action();

+and
+
+if (condition)
+	do_this();
+else
+	do_that();
+
 This does not apply if one branch of a conditional statement is a single
 statement. Use braces in both branches.


Documentation/DocBook/Makefile

@@ -53,7 +53,9 @@ MAN := $(patsubst %.xml, %.9, $(BOOKS))
 mandocs: $(MAN)

 build_images = mkdir -p $(objtree)/Documentation/DocBook/media/ && \
-	       cp $(srctree)/Documentation/DocBook/dvb/*.png $(srctree)/Documentation/DocBook/v4l/*.gif $(objtree)/Documentation/DocBook/media/
+	       cp $(srctree)/Documentation/DocBook/dvb/*.png \
+	          $(srctree)/Documentation/DocBook/v4l/*.gif \
+		  $(objtree)/Documentation/DocBook/media/

 xmldoclinks:
 ifneq ($(objtree),$(srctree))

Documentation/DocBook/media-entities.tmpl

@@ -11,6 +11,10 @@
 <!ENTITY func-select "<link linkend='func-select'><function>select()</function></link>">
 <!ENTITY func-write "<link linkend='func-write'><function>write()</function></link>">

+<!ENTITY media-func-close "<link linkend='media-func-close'><function>close()</function></link>">
+<!ENTITY media-func-ioctl "<link linkend='media-func-ioctl'><function>ioctl()</function></link>">
+<!ENTITY media-func-open "<link linkend='media-func-open'><function>open()</function></link>">
+
 <!-- Ioctls -->
 <!ENTITY VIDIOC-CROPCAP "<link linkend='vidioc-cropcap'><constant>VIDIOC_CROPCAP</constant></link>">
 <!ENTITY VIDIOC-DBG-G-CHIP-IDENT "<link linkend='vidioc-dbg-g-chip-ident'><constant>VIDIOC_DBG_G_CHIP_IDENT</constant></link>">
@@ -82,11 +86,24 @@
 <!ENTITY VIDIOC-S-PRIORITY "<link linkend='vidioc-g-priority'><constant>VIDIOC_S_PRIORITY</constant></link>">
 <!ENTITY VIDIOC-S-STD "<link linkend='vidioc-g-std'><constant>VIDIOC_S_STD</constant></link>">
 <!ENTITY VIDIOC-S-TUNER "<link linkend='vidioc-g-tuner'><constant>VIDIOC_S_TUNER</constant></link>">
+<!ENTITY VIDIOC-SUBDEV-ENUM-FRAME-SIZE "<link linkend='vidioc-subdev-enum-frame-size'><constant>VIDIOC_SUBDEV_ENUM_FRAME_SIZE</constant></link>">
+<!ENTITY VIDIOC-SUBDEV-ENUM-MBUS-CODE "<link linkend='vidioc-subdev-enum-mbus-code'><constant>VIDIOC_SUBDEV_ENUM_MBUS_CODE</constant></link>">
+<!ENTITY VIDIOC-SUBDEV-G-CROP "<link linkend='vidioc-subdev-g-crop'><constant>VIDIOC_SUBDEV_G_CROP</constant></link>">
+<!ENTITY VIDIOC-SUBDEV-G-FMT "<link linkend='vidioc-subdev-g-fmt'><constant>VIDIOC_SUBDEV_G_FMT</constant></link>">
+<!ENTITY VIDIOC-SUBDEV-G-FRAME-INTERVAL "<link linkend='vidioc-subdev-g-frame-interval'><constant>VIDIOC_SUBDEV_G_FRAME_INTERVAL</constant></link>">
+<!ENTITY VIDIOC-SUBDEV-S-CROP "<link linkend='vidioc-subdev-g-crop'><constant>VIDIOC_SUBDEV_S_CROP</constant></link>">
+<!ENTITY VIDIOC-SUBDEV-S-FMT "<link linkend='vidioc-subdev-g-fmt'><constant>VIDIOC_SUBDEV_S_FMT</constant></link>">
+<!ENTITY VIDIOC-SUBDEV-S-FRAME-INTERVAL "<link linkend='vidioc-subdev-g-frame-interval'><constant>VIDIOC_SUBDEV_S_FRAME_INTERVAL</constant></link>">
 <!ENTITY VIDIOC-TRY-ENCODER-CMD "<link linkend='vidioc-encoder-cmd'><constant>VIDIOC_TRY_ENCODER_CMD</constant></link>">
 <!ENTITY VIDIOC-TRY-EXT-CTRLS "<link linkend='vidioc-g-ext-ctrls'><constant>VIDIOC_TRY_EXT_CTRLS</constant></link>">
 <!ENTITY VIDIOC-TRY-FMT "<link linkend='vidioc-g-fmt'><constant>VIDIOC_TRY_FMT</constant></link>">
 <!ENTITY VIDIOC-UNSUBSCRIBE-EVENT "<link linkend='vidioc-subscribe-event'><constant>VIDIOC_UNSUBSCRIBE_EVENT</constant></link>">

+<!ENTITY MEDIA-IOC-DEVICE-INFO "<link linkend='media-ioc-device-info'><constant>MEDIA_IOC_DEVICE_INFO</constant></link>">
+<!ENTITY MEDIA-IOC-ENUM-ENTITIES "<link linkend='media-ioc-enum-entities'><constant>MEDIA_IOC_ENUM_ENTITIES</constant></link>">
+<!ENTITY MEDIA-IOC-ENUM-LINKS "<link linkend='media-ioc-enum-links'><constant>MEDIA_IOC_ENUM_LINKS</constant></link>">
+<!ENTITY MEDIA-IOC-SETUP-LINK "<link linkend='media-ioc-setup-link'><constant>MEDIA_IOC_SETUP_LINK</constant></link>">
+
 <!-- Types -->
 <!ENTITY v4l2-std-id "<link linkend='v4l2-std-id'>v4l2_std_id</link>">

@@ -98,6 +115,7 @@
 <!ENTITY v4l2-field "enum&nbsp;<link linkend='v4l2-field'>v4l2_field</link>">
 <!ENTITY v4l2-frmivaltypes "enum&nbsp;<link linkend='v4l2-frmivaltypes'>v4l2_frmivaltypes</link>">
 <!ENTITY v4l2-frmsizetypes "enum&nbsp;<link linkend='v4l2-frmsizetypes'>v4l2_frmsizetypes</link>">
+<!ENTITY v4l2-mbus-pixelcode "enum&nbsp;<link linkend='v4l2-mbus-pixelcode'>v4l2_mbus_pixelcode</link>">
 <!ENTITY v4l2-memory "enum&nbsp;<link linkend='v4l2-memory'>v4l2_memory</link>">
 <!ENTITY v4l2-mpeg-audio-ac3-bitrate "enum&nbsp;<link linkend='v4l2-mpeg-audio-ac3-bitrate'>v4l2_mpeg_audio_ac3_bitrate</link>">
 <!ENTITY v4l2-mpeg-audio-crc "enum&nbsp;<link linkend='v4l2-mpeg-audio-crc'>v4l2_mpeg_audio_crc</link>">
@@ -121,6 +139,7 @@
 <!ENTITY v4l2-mpeg-video-encoding "enum&nbsp;<link linkend='v4l2-mpeg-video-encoding'>v4l2_mpeg_video_encoding</link>">
 <!ENTITY v4l2-power-line-frequency "enum&nbsp;<link linkend='v4l2-power-line-frequency'>v4l2_power_line_frequency</link>">
 <!ENTITY v4l2-priority "enum&nbsp;<link linkend='v4l2-priority'>v4l2_priority</link>">
+<!ENTITY v4l2-subdev-format-whence "enum&nbsp;<link linkend='v4l2-subdev-format-whence'>v4l2_subdev_format_whence</link>">
 <!ENTITY v4l2-tuner-type "enum&nbsp;<link linkend='v4l2-tuner-type'>v4l2_tuner_type</link>">
 <!ENTITY v4l2-preemphasis "enum&nbsp;<link linkend='v4l2-preemphasis'>v4l2_preemphasis</link>">

@@ -129,6 +148,7 @@
 <!ENTITY v4l2-audioout "struct&nbsp;<link linkend='v4l2-audioout'>v4l2_audioout</link>">
 <!ENTITY v4l2-bt-timings "struct&nbsp;<link linkend='v4l2-bt-timings'>v4l2_bt_timings</link>">
 <!ENTITY v4l2-buffer "struct&nbsp;<link linkend='v4l2-buffer'>v4l2_buffer</link>">
+<!ENTITY v4l2-plane "struct&nbsp;<link linkend='v4l2-plane'>v4l2_plane</link>">
 <!ENTITY v4l2-capability "struct&nbsp;<link linkend='v4l2-capability'>v4l2_capability</link>">
 <!ENTITY v4l2-captureparm "struct&nbsp;<link linkend='v4l2-captureparm'>v4l2_captureparm</link>">
 <!ENTITY v4l2-clip "struct&nbsp;<link linkend='v4l2-clip'>v4l2_clip</link>">
@@ -162,11 +182,14 @@
 <!ENTITY v4l2-hw-freq-seek "struct&nbsp;<link linkend='v4l2-hw-freq-seek'>v4l2_hw_freq_seek</link>">
 <!ENTITY v4l2-input "struct&nbsp;<link linkend='v4l2-input'>v4l2_input</link>">
 <!ENTITY v4l2-jpegcompression "struct&nbsp;<link linkend='v4l2-jpegcompression'>v4l2_jpegcompression</link>">
+<!ENTITY v4l2-mbus-framefmt "struct&nbsp;<link linkend='v4l2-mbus-framefmt'>v4l2_mbus_framefmt</link>">
 <!ENTITY v4l2-modulator "struct&nbsp;<link linkend='v4l2-modulator'>v4l2_modulator</link>">
 <!ENTITY v4l2-mpeg-vbi-fmt-ivtv "struct&nbsp;<link linkend='v4l2-mpeg-vbi-fmt-ivtv'>v4l2_mpeg_vbi_fmt_ivtv</link>">
 <!ENTITY v4l2-output "struct&nbsp;<link linkend='v4l2-output'>v4l2_output</link>">
 <!ENTITY v4l2-outputparm "struct&nbsp;<link linkend='v4l2-outputparm'>v4l2_outputparm</link>">
 <!ENTITY v4l2-pix-format "struct&nbsp;<link linkend='v4l2-pix-format'>v4l2_pix_format</link>">
+<!ENTITY v4l2-pix-format-mplane "struct&nbsp;<link linkend='v4l2-pix-format-mplane'>v4l2_pix_format_mplane</link>">
+<!ENTITY v4l2-plane-pix-format "struct&nbsp;<link linkend='v4l2-plane-pix-format'>v4l2_plane_pix_format</link>">
 <!ENTITY v4l2-queryctrl "struct&nbsp;<link linkend='v4l2-queryctrl'>v4l2_queryctrl</link>">
 <!ENTITY v4l2-querymenu "struct&nbsp;<link linkend='v4l2-querymenu'>v4l2_querymenu</link>">
 <!ENTITY v4l2-rect "struct&nbsp;<link linkend='v4l2-rect'>v4l2_rect</link>">
@@ -174,6 +197,12 @@
 <!ENTITY v4l2-sliced-vbi-cap "struct&nbsp;<link linkend='v4l2-sliced-vbi-cap'>v4l2_sliced_vbi_cap</link>">
 <!ENTITY v4l2-sliced-vbi-data "struct&nbsp;<link linkend='v4l2-sliced-vbi-data'>v4l2_sliced_vbi_data</link>">
 <!ENTITY v4l2-sliced-vbi-format "struct&nbsp;<link linkend='v4l2-sliced-vbi-format'>v4l2_sliced_vbi_format</link>">
+<!ENTITY v4l2-subdev-frame-interval "struct&nbsp;<link linkend='v4l2-subdev-frame-interval'>v4l2_subdev_frame_interval</link>">
+<!ENTITY v4l2-subdev-frame-interval-enum "struct&nbsp;<link linkend='v4l2-subdev-frame-interval-enum'>v4l2_subdev_frame_interval_enum</link>">
+<!ENTITY v4l2-subdev-frame-size-enum "struct&nbsp;<link linkend='v4l2-subdev-frame-size-enum'>v4l2_subdev_frame_size_enum</link>">
+<!ENTITY v4l2-subdev-crop "struct&nbsp;<link linkend='v4l2-subdev-crop'>v4l2_subdev_crop</link>">
+<!ENTITY v4l2-subdev-format "struct&nbsp;<link linkend='v4l2-subdev-format'>v4l2_subdev_format</link>">
+<!ENTITY v4l2-subdev-mbus-code-enum "struct&nbsp;<link linkend='v4l2-subdev-mbus-code-enum'>v4l2_subdev_mbus_code_enum</link>">
 <!ENTITY v4l2-standard "struct&nbsp;<link linkend='v4l2-standard'>v4l2_standard</link>">
 <!ENTITY v4l2-streamparm "struct&nbsp;<link linkend='v4l2-streamparm'>v4l2_streamparm</link>">
 <!ENTITY v4l2-timecode "struct&nbsp;<link linkend='v4l2-timecode'>v4l2_timecode</link>">
@@ -181,6 +210,12 @@
 <!ENTITY v4l2-vbi-format "struct&nbsp;<link linkend='v4l2-vbi-format'>v4l2_vbi_format</link>">
 <!ENTITY v4l2-window "struct&nbsp;<link linkend='v4l2-window'>v4l2_window</link>">

+<!ENTITY media-device-info "struct&nbsp;<link linkend='media-device-info'>media_device_info</link>">
+<!ENTITY media-entity-desc "struct&nbsp;<link linkend='media-entity-desc'>media_entity_desc</link>">
+<!ENTITY media-links-enum "struct&nbsp;<link linkend='media-links-enum'>media_links_enum</link>">
+<!ENTITY media-pad-desc "struct&nbsp;<link linkend='media-pad-desc'>media_pad_desc</link>">
+<!ENTITY media-link-desc "struct&nbsp;<link linkend='media-link-desc'>media_link_desc</link>">
+
 <!-- Error Codes -->
 <!ENTITY EACCES "<errorcode>EACCES</errorcode> error code">
 <!ENTITY EAGAIN "<errorcode>EAGAIN</errorcode> error code">
@@ -197,11 +232,13 @@
 <!ENTITY ENXIO "<errorcode>ENXIO</errorcode> error code">
 <!ENTITY EMFILE "<errorcode>EMFILE</errorcode> error code">
 <!ENTITY EPERM "<errorcode>EPERM</errorcode> error code">
+<!ENTITY EPIPE "<errorcode>EPIPE</errorcode> error code">
 <!ENTITY ERANGE "<errorcode>ERANGE</errorcode> error code">

 <!-- Subsections -->
 <!ENTITY sub-biblio SYSTEM "v4l/biblio.xml">
 <!ENTITY sub-common SYSTEM "v4l/common.xml">
+<!ENTITY sub-planar-apis SYSTEM "v4l/planar-apis.xml">
 <!ENTITY sub-compat SYSTEM "v4l/compat.xml">
 <!ENTITY sub-controls SYSTEM "v4l/controls.xml">
 <!ENTITY sub-dev-capture SYSTEM "v4l/dev-capture.xml">
@@ -215,6 +252,7 @@
 <!ENTITY sub-dev-raw-vbi SYSTEM "v4l/dev-raw-vbi.xml">
 <!ENTITY sub-dev-rds SYSTEM "v4l/dev-rds.xml">
 <!ENTITY sub-dev-sliced-vbi SYSTEM "v4l/dev-sliced-vbi.xml">
+<!ENTITY sub-dev-subdev SYSTEM "v4l/dev-subdev.xml">
 <!ENTITY sub-dev-teletext SYSTEM "v4l/dev-teletext.xml">
 <!ENTITY sub-driver SYSTEM "v4l/driver.xml">
 <!ENTITY sub-libv4l SYSTEM "v4l/libv4l.xml">
@@ -233,6 +271,8 @@
 <!ENTITY sub-io SYSTEM "v4l/io.xml">
 <!ENTITY sub-grey SYSTEM "v4l/pixfmt-grey.xml">
 <!ENTITY sub-nv12 SYSTEM "v4l/pixfmt-nv12.xml">
+<!ENTITY sub-nv12m SYSTEM "v4l/pixfmt-nv12m.xml">
+<!ENTITY sub-nv12mt SYSTEM "v4l/pixfmt-nv12mt.xml">
 <!ENTITY sub-nv16 SYSTEM "v4l/pixfmt-nv16.xml">
 <!ENTITY sub-packed-rgb SYSTEM "v4l/pixfmt-packed-rgb.xml">
 <!ENTITY sub-packed-yuv SYSTEM "v4l/pixfmt-packed-yuv.xml">
@@ -247,6 +287,7 @@
 <!ENTITY sub-yuv410 SYSTEM "v4l/pixfmt-yuv410.xml">
 <!ENTITY sub-yuv411p SYSTEM "v4l/pixfmt-yuv411p.xml">
 <!ENTITY sub-yuv420 SYSTEM "v4l/pixfmt-yuv420.xml">
+<!ENTITY sub-yuv420m SYSTEM "v4l/pixfmt-yuv420m.xml">
 <!ENTITY sub-yuv422p SYSTEM "v4l/pixfmt-yuv422p.xml">
 <!ENTITY sub-yuyv SYSTEM "v4l/pixfmt-yuyv.xml">
 <!ENTITY sub-yvyu SYSTEM "v4l/pixfmt-yvyu.xml">
@@ -298,6 +339,13 @@
 <!ENTITY sub-reqbufs SYSTEM "v4l/vidioc-reqbufs.xml">
 <!ENTITY sub-s-hw-freq-seek SYSTEM "v4l/vidioc-s-hw-freq-seek.xml">
 <!ENTITY sub-streamon SYSTEM "v4l/vidioc-streamon.xml">
+<!ENTITY sub-subdev-enum-frame-interval SYSTEM "v4l/vidioc-subdev-enum-frame-interval.xml">
+<!ENTITY sub-subdev-enum-frame-size SYSTEM "v4l/vidioc-subdev-enum-frame-size.xml">
+<!ENTITY sub-subdev-enum-mbus-code SYSTEM "v4l/vidioc-subdev-enum-mbus-code.xml">
+<!ENTITY sub-subdev-formats SYSTEM "v4l/subdev-formats.xml">
+<!ENTITY sub-subdev-g-crop SYSTEM "v4l/vidioc-subdev-g-crop.xml">
+<!ENTITY sub-subdev-g-fmt SYSTEM "v4l/vidioc-subdev-g-fmt.xml">
+<!ENTITY sub-subdev-g-frame-interval SYSTEM "v4l/vidioc-subdev-g-frame-interval.xml">
 <!ENTITY sub-capture-c SYSTEM "v4l/capture.c.xml">
 <!ENTITY sub-keytable-c SYSTEM "v4l/keytable.c.xml">
 <!ENTITY sub-v4l2grab-c SYSTEM "v4l/v4l2grab.c.xml">
@@ -321,6 +369,15 @@
 <!ENTITY sub-media-entities SYSTEM "media-entities.tmpl">
 <!ENTITY sub-media-indices SYSTEM "media-indices.tmpl">

+<!ENTITY sub-media-controller SYSTEM "v4l/media-controller.xml">
+<!ENTITY sub-media-open SYSTEM "v4l/media-func-open.xml">
+<!ENTITY sub-media-close SYSTEM "v4l/media-func-close.xml">
+<!ENTITY sub-media-ioctl SYSTEM "v4l/media-func-ioctl.xml">
+<!ENTITY sub-media-ioc-device-info SYSTEM "v4l/media-ioc-device-info.xml">
+<!ENTITY sub-media-ioc-enum-entities SYSTEM "v4l/media-ioc-enum-entities.xml">
+<!ENTITY sub-media-ioc-enum-links SYSTEM "v4l/media-ioc-enum-links.xml">
+<!ENTITY sub-media-ioc-setup-link SYSTEM "v4l/media-ioc-setup-link.xml">
+
 <!-- Function Reference -->
 <!ENTITY close SYSTEM "v4l/func-close.xml">
 <!ENTITY ioctl SYSTEM "v4l/func-ioctl.xml">
@@ -333,6 +390,7 @@
 <!ENTITY write SYSTEM "v4l/func-write.xml">
 <!ENTITY grey SYSTEM "v4l/pixfmt-grey.xml">
 <!ENTITY nv12 SYSTEM "v4l/pixfmt-nv12.xml">
+<!ENTITY nv12m SYSTEM "v4l/pixfmt-nv12m.xml">
 <!ENTITY nv16 SYSTEM "v4l/pixfmt-nv16.xml">
 <!ENTITY packed-rgb SYSTEM "v4l/pixfmt-packed-rgb.xml">
 <!ENTITY packed-yuv SYSTEM "v4l/pixfmt-packed-yuv.xml">
@@ -347,6 +405,7 @@
 <!ENTITY yuv410 SYSTEM "v4l/pixfmt-yuv410.xml">
 <!ENTITY yuv411p SYSTEM "v4l/pixfmt-yuv411p.xml">
 <!ENTITY yuv420 SYSTEM "v4l/pixfmt-yuv420.xml">
+<!ENTITY yuv420m SYSTEM "v4l/pixfmt-yuv420m.xml">
 <!ENTITY yuv422p SYSTEM "v4l/pixfmt-yuv422p.xml">
 <!ENTITY yuyv SYSTEM "v4l/pixfmt-yuyv.xml">
 <!ENTITY yvyu SYSTEM "v4l/pixfmt-yvyu.xml">

Documentation/DocBook/media.tmpl

@@ -106,6 +106,9 @@ Foundation. A copy of the license is included in the chapter entitled
 &sub-remote_controllers;
 </chapter>
 </part>
+<part id="media_common">
+&sub-media-controller;
+</part>

 &sub-fdl-appendix;


Documentation/DocBook/rapidio.tmpl

@@ -133,7 +133,6 @@
 !Idrivers/rapidio/rio-sysfs.c
      </sect1>
      <sect1 id="PPC32_support"><title>PPC32 support</title>
-!Earch/powerpc/sysdev/fsl_rio.c
 !Iarch/powerpc/sysdev/fsl_rio.c
      </sect1>
   </chapter>

Documentation/DocBook/v4l/common.xml

@@ -846,6 +846,8 @@ conversion routine or library for integration into applications.</para>
     </section>
   </section>

+  &sub-planar-apis;
+
   <section id="crop">
     <title>Image Cropping, Insertion and Scaling</title>


Documentation/DocBook/v4l/compat.xml

@@ -1711,8 +1711,8 @@ ioctl would enumerate the available audio inputs. An ioctl to
 determine the current audio input, if more than one combines with the
 current video input, did not exist. So
 <constant>VIDIOC_G_AUDIO</constant> was renamed to
-<constant>VIDIOC_G_AUDIO_OLD</constant>, this ioctl will be removed in
-the future. The &VIDIOC-ENUMAUDIO; ioctl was added to enumerate
+<constant>VIDIOC_G_AUDIO_OLD</constant>, this ioctl was removed on
+Kernel 2.6.39. The &VIDIOC-ENUMAUDIO; ioctl was added to enumerate
 audio inputs, while &VIDIOC-G-AUDIO; now reports the current audio
 input.</para>
 	  <para>The same changes were made to &VIDIOC-G-AUDOUT; and
@@ -1726,7 +1726,7 @@ must be updated to successfully compile again.</para>
 	  <para>The &VIDIOC-OVERLAY; ioctl was incorrectly defined with
 write-read parameter. It was changed to write-only, while the write-read
 version was renamed to <constant>VIDIOC_OVERLAY_OLD</constant>. The old
-ioctl will be removed in the future. Until further the "videodev"
+ioctl was removed on Kernel 2.6.39. Until further the "videodev"
 kernel module will automatically translate to the new version, so drivers
 must be recompiled, but not applications.</para>
 	</listitem>
@@ -1744,7 +1744,7 @@ surface can be seen.</para>
 defined with write-only parameter, inconsistent with other ioctls
 modifying their argument. They were changed to write-read, while a
 <constant>_OLD</constant> suffix was added to the write-only versions.
-The old ioctls will be removed in the future. Drivers and
+The old ioctls were removed on Kernel 2.6.39. Drivers and
 applications assuming a constant parameter need an update.</para>
 	</listitem>
       </orderedlist>
@@ -1815,8 +1815,8 @@ yet to be addressed, for details see <xref
 	  <para>The &VIDIOC-CROPCAP; ioctl was incorrectly defined
 with read-only parameter. It is now defined as write-read ioctl, while
 the read-only version was renamed to
-<constant>VIDIOC_CROPCAP_OLD</constant>. The old ioctl will be removed
-in the future.</para>
+<constant>VIDIOC_CROPCAP_OLD</constant>. The old ioctl was removed
+on Kernel 2.6.39.</para>
 	</listitem>
       </orderedlist>
     </section>
@@ -2353,6 +2353,20 @@ that used it. It was originally scheduled for removal in 2.6.35.
 	</listitem>
       </orderedlist>
     </section>
+    <section>
+      <title>V4L2 in Linux 2.6.39</title>
+      <orderedlist>
+        <listitem>
+          <para>The old VIDIOC_*_OLD symbols and V4L1 support were removed.</para>
+        </listitem>
+        <listitem>
+          <para>Multi-planar API added. Does not affect the compatibility of
+          current drivers and applications. See
+          <link linkend="planar-apis">multi-planar API</link>
+          for details.</para>
+        </listitem>
+      </orderedlist>
+    </section>

     <section id="other">
       <title>Relation of V4L2 to other Linux multimedia APIs</title>

Documentation/DocBook/v4l/dev-capture.xml

@@ -18,7 +18,8 @@ files are used for video output devices.</para>
     <title>Querying Capabilities</title>

     <para>Devices supporting the video capture interface set the
-<constant>V4L2_CAP_VIDEO_CAPTURE</constant> flag in the
+<constant>V4L2_CAP_VIDEO_CAPTURE</constant> or
+<constant>V4L2_CAP_VIDEO_CAPTURE_MPLANE</constant> flag in the
 <structfield>capabilities</structfield> field of &v4l2-capability;
 returned by the &VIDIOC-QUERYCAP; ioctl. As secondary device functions
 they may also support the <link linkend="overlay">video overlay</link>
@@ -64,9 +65,11 @@ linkend="crop" />.</para>

     <para>To query the current image format applications set the
 <structfield>type</structfield> field of a &v4l2-format; to
-<constant>V4L2_BUF_TYPE_VIDEO_CAPTURE</constant> and call the
+<constant>V4L2_BUF_TYPE_VIDEO_CAPTURE</constant> or
+<constant>V4L2_BUF_TYPE_VIDEO_CAPTURE_MPLANE</constant> and call the
 &VIDIOC-G-FMT; ioctl with a pointer to this structure. Drivers fill
-the &v4l2-pix-format; <structfield>pix</structfield> member of the
+the &v4l2-pix-format; <structfield>pix</structfield> or the
+&v4l2-pix-format-mplane; <structfield>pix_mp</structfield> member of the
 <structfield>fmt</structfield> union.</para>

     <para>To request different parameters applications set the
@@ -84,8 +87,8 @@ adjust the parameters and finally return the actual parameters as
 without disabling I/O or possibly time consuming hardware
 preparations.</para>

-    <para>The contents of &v4l2-pix-format; are discussed in <xref
-linkend="pixfmt" />. See also the specification of the
+    <para>The contents of &v4l2-pix-format; and &v4l2-pix-format-mplane;
+are discussed in <xref linkend="pixfmt" />. See also the specification of the
 <constant>VIDIOC_G_FMT</constant>, <constant>VIDIOC_S_FMT</constant>
 and <constant>VIDIOC_TRY_FMT</constant> ioctls for details. Video
 capture devices must implement both the

Documentation/DocBook/v4l/dev-output.xml

@@ -17,7 +17,8 @@ files are used for video capture devices.</para>
     <title>Querying Capabilities</title>

     <para>Devices supporting the video output interface set the
-<constant>V4L2_CAP_VIDEO_OUTPUT</constant> flag in the
+<constant>V4L2_CAP_VIDEO_OUTPUT</constant> or
+<constant>V4L2_CAP_VIDEO_OUTPUT_MPLANE</constant> flag in the
 <structfield>capabilities</structfield> field of &v4l2-capability;
 returned by the &VIDIOC-QUERYCAP; ioctl. As secondary device functions
 they may also support the <link linkend="raw-vbi">raw VBI
@@ -60,9 +61,11 @@ linkend="crop" />.</para>

     <para>To query the current image format applications set the
 <structfield>type</structfield> field of a &v4l2-format; to
-<constant>V4L2_BUF_TYPE_VIDEO_OUTPUT</constant> and call the
+<constant>V4L2_BUF_TYPE_VIDEO_OUTPUT</constant> or
+<constant>V4L2_BUF_TYPE_VIDEO_OUTPUT_MPLANE</constant> and call the
 &VIDIOC-G-FMT; ioctl with a pointer to this structure. Drivers fill
-the &v4l2-pix-format; <structfield>pix</structfield> member of the
+the &v4l2-pix-format; <structfield>pix</structfield> or the
+&v4l2-pix-format-mplane; <structfield>pix_mp</structfield> member of the
 <structfield>fmt</structfield> union.</para>

     <para>To request different parameters applications set the
@@ -80,8 +83,8 @@ adjust the parameters and finally return the actual parameters as
 without disabling I/O or possibly time consuming hardware
 preparations.</para>

-    <para>The contents of &v4l2-pix-format; are discussed in <xref
-linkend="pixfmt" />. See also the specification of the
+    <para>The contents of &v4l2-pix-format; and &v4l2-pix-format-mplane;
+are discussed in <xref linkend="pixfmt" />. See also the specification of the
 <constant>VIDIOC_G_FMT</constant>, <constant>VIDIOC_S_FMT</constant>
 and <constant>VIDIOC_TRY_FMT</constant> ioctls for details. Video
 output devices must implement both the

Documentation/DocBook/v4l/dev-subdev.xml

@@ -0,0 +1,313 @@
+  <title>Sub-device Interface</title>
+
+  <note>
+    <title>Experimental</title>
+    <para>This is an <link linkend="experimental">experimental</link>
+    interface and may change in the future.</para>
+  </note>
+
+  <para>The complex nature of V4L2 devices, where hardware is often made of
+  several integrated circuits that need to interact with each other in a
+  controlled way, leads to complex V4L2 drivers. The drivers usually reflect
+  the hardware model in software, and model the different hardware components
+  as software blocks called sub-devices.</para>
+
+  <para>V4L2 sub-devices are usually kernel-only objects. If the V4L2 driver
+  implements the media device API, they will automatically inherit from media
+  entities. Applications will be able to enumerate the sub-devices and discover
+  the hardware topology using the media entities, pads and links enumeration
+  API.</para>
+
+  <para>In addition to make sub-devices discoverable, drivers can also choose
+  to make them directly configurable by applications. When both the sub-device
+  driver and the V4L2 device driver support this, sub-devices will feature a
+  character device node on which ioctls can be called to
+  <itemizedlist>
+    <listitem><para>query, read and write sub-devices controls</para></listitem>
+    <listitem><para>subscribe and unsubscribe to events and retrieve them</para></listitem>
+    <listitem><para>negotiate image formats on individual pads</para></listitem>
+  </itemizedlist>
+  </para>
+
+  <para>Sub-device character device nodes, conventionally named
+  <filename>/dev/v4l-subdev*</filename>, use major number 81.</para>
+
+  <section>
+    <title>Controls</title>
+    <para>Most V4L2 controls are implemented by sub-device hardware. Drivers
+    usually merge all controls and expose them through video device nodes.
+    Applications can control all sub-devices through a single interface.</para>
+
+    <para>Complex devices sometimes implement the same control in different
+    pieces of hardware. This situation is common in embedded platforms, where
+    both sensors and image processing hardware implement identical functions,
+    such as contrast adjustment, white balance or faulty pixels correction. As
+    the V4L2 controls API doesn't support several identical controls in a single
+    device, all but one of the identical controls are hidden.</para>
+
+    <para>Applications can access those hidden controls through the sub-device
+    node with the V4L2 control API described in <xref linkend="control" />. The
+    ioctls behave identically as when issued on V4L2 device nodes, with the
+    exception that they deal only with controls implemented in the sub-device.
+    </para>
+
+    <para>Depending on the driver, those controls might also be exposed through
+    one (or several) V4L2 device nodes.</para>
+  </section>
+
+  <section>
+    <title>Events</title>
+    <para>V4L2 sub-devices can notify applications of events as described in
+    <xref linkend="event" />. The API behaves identically as when used on V4L2
+    device nodes, with the exception that it only deals with events generated by
+    the sub-device. Depending on the driver, those events might also be reported
+    on one (or several) V4L2 device nodes.</para>
+  </section>
+
+  <section id="pad-level-formats">
+    <title>Pad-level Formats</title>
+
+    <warning><para>Pad-level formats are only applicable to very complex device that
+    need to expose low-level format configuration to user space. Generic V4L2
+    applications do <emphasis>not</emphasis> need to use the API described in
+    this section.</para></warning>
+
+    <note><para>For the purpose of this section, the term
+    <wordasword>format</wordasword> means the combination of media bus data
+    format, frame width and frame height.</para></note>
+
+    <para>Image formats are typically negotiated on video capture and output
+    devices using the <link linkend="crop">cropping and scaling</link> ioctls.
+    The driver is responsible for configuring every block in the video pipeline
+    according to the requested format at the pipeline input and/or
+    output.</para>
+
+    <para>For complex devices, such as often found in embedded systems,
+    identical image sizes at the output of a pipeline can be achieved using
+    different hardware configurations. One such example is shown on
+    <xref linkend="pipeline-scaling" />, where
+    image scaling can be performed on both the video sensor and the host image
+    processing hardware.</para>
+
+    <figure id="pipeline-scaling">
+      <title>Image Format Negotation on Pipelines</title>
+      <mediaobject>
+	<imageobject>
+	  <imagedata fileref="pipeline.pdf" format="PS" />
+	</imageobject>
+	<imageobject>
+	  <imagedata fileref="pipeline.png" format="PNG" />
+	</imageobject>
+	<textobject>
+	  <phrase>High quality and high speed pipeline configuration</phrase>
+	</textobject>
+      </mediaobject>
+    </figure>
+
+    <para>The sensor scaler is usually of less quality than the host scaler, but
+    scaling on the sensor is required to achieve higher frame rates. Depending
+    on the use case (quality vs. speed), the pipeline must be configured
+    differently. Applications need to configure the formats at every point in
+    the pipeline explicitly.</para>
+
+    <para>Drivers that implement the <link linkend="media-controller-intro">media
+    API</link> can expose pad-level image format configuration to applications.
+    When they do, applications can use the &VIDIOC-SUBDEV-G-FMT; and
+    &VIDIOC-SUBDEV-S-FMT; ioctls. to negotiate formats on a per-pad basis.</para>
+
+    <para>Applications are responsible for configuring coherent parameters on
+    the whole pipeline and making sure that connected pads have compatible
+    formats. The pipeline is checked for formats mismatch at &VIDIOC-STREAMON;
+    time, and an &EPIPE; is then returned if the configuration is
+    invalid.</para>
+
+    <para>Pad-level image format configuration support can be tested by calling
+    the &VIDIOC-SUBDEV-G-FMT; ioctl on pad 0. If the driver returns an &EINVAL;
+    pad-level format configuration is not supported by the sub-device.</para>
+
+    <section>
+      <title>Format Negotiation</title>
+
+      <para>Acceptable formats on pads can (and usually do) depend on a number
+      of external parameters, such as formats on other pads, active links, or
+      even controls. Finding a combination of formats on all pads in a video
+      pipeline, acceptable to both application and driver, can't rely on formats
+      enumeration only. A format negotiation mechanism is required.</para>
+
+      <para>Central to the format negotiation mechanism are the get/set format
+      operations. When called with the <structfield>which</structfield> argument
+      set to <constant>V4L2_SUBDEV_FORMAT_TRY</constant>, the
+      &VIDIOC-SUBDEV-G-FMT; and &VIDIOC-SUBDEV-S-FMT; ioctls operate on a set of
+      formats parameters that are not connected to the hardware configuration.
+      Modifying those 'try' formats leaves the device state untouched (this
+      applies to both the software state stored in the driver and the hardware
+      state stored in the device itself).</para>
+
+      <para>While not kept as part of the device state, try formats are stored
+      in the sub-device file handles. A &VIDIOC-SUBDEV-G-FMT; call will return
+      the last try format set <emphasis>on the same sub-device file
+      handle</emphasis>. Several applications querying the same sub-device at
+      the same time will thus not interact with each other.</para>
+
+      <para>To find out whether a particular format is supported by the device,
+      applications use the &VIDIOC-SUBDEV-S-FMT; ioctl. Drivers verify and, if
+      needed, change the requested <structfield>format</structfield> based on
+      device requirements and return the possibly modified value. Applications
+      can then choose to try a different format or accept the returned value and
+      continue.</para>
+
+      <para>Formats returned by the driver during a negotiation iteration are
+      guaranteed to be supported by the device. In particular, drivers guarantee
+      that a returned format will not be further changed if passed to an
+      &VIDIOC-SUBDEV-S-FMT; call as-is (as long as external parameters, such as
+      formats on other pads or links' configuration are not changed).</para>
+
+      <para>Drivers automatically propagate formats inside sub-devices. When a
+      try or active format is set on a pad, corresponding formats on other pads
+      of the same sub-device can be modified by the driver. Drivers are free to
+      modify formats as required by the device. However, they should comply with
+      the following rules when possible:
+      <itemizedlist>
+        <listitem><para>Formats should be propagated from sink pads to source pads.
+	Modifying a format on a source pad should not modify the format on any
+	sink pad.</para></listitem>
+        <listitem><para>Sub-devices that scale frames using variable scaling factors
+	should reset the scale factors to default values when sink pads formats
+	are modified. If the 1:1 scaling ratio is supported, this means that
+	source pads formats should be reset to the sink pads formats.</para></listitem>
+      </itemizedlist>
+      </para>
+
+      <para>Formats are not propagated across links, as that would involve
+      propagating them from one sub-device file handle to another. Applications
+      must then take care to configure both ends of every link explicitly with
+      compatible formats. Identical formats on the two ends of a link are
+      guaranteed to be compatible. Drivers are free to accept different formats
+      matching device requirements as being compatible.</para>
+
+      <para><xref linkend="sample-pipeline-config" />
+      shows a sample configuration sequence for the pipeline described in
+      <xref linkend="pipeline-scaling" /> (table
+      columns list entity names and pad numbers).</para>
+
+      <table pgwide="0" frame="none" id="sample-pipeline-config">
+	<title>Sample Pipeline Configuration</title>
+	<tgroup cols="3">
+	  <colspec colname="what"/>
+	  <colspec colname="sensor-0" />
+	  <colspec colname="frontend-0" />
+	  <colspec colname="frontend-1" />
+	  <colspec colname="scaler-0" />
+	  <colspec colname="scaler-1" />
+	  <thead>
+	    <row>
+	      <entry></entry>
+	      <entry>Sensor/0</entry>
+	      <entry>Frontend/0</entry>
+	      <entry>Frontend/1</entry>
+	      <entry>Scaler/0</entry>
+	      <entry>Scaler/1</entry>
+	    </row>
+	  </thead>
+	  <tbody valign="top">
+	    <row>
+	      <entry>Initial state</entry>
+	      <entry>2048x1536</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	    </row>
+	    <row>
+	      <entry>Configure frontend input</entry>
+	      <entry>2048x1536</entry>
+	      <entry><emphasis>2048x1536</emphasis></entry>
+	      <entry><emphasis>2046x1534</emphasis></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	    </row>
+	    <row>
+	      <entry>Configure scaler input</entry>
+	      <entry>2048x1536</entry>
+	      <entry>2048x1536</entry>
+	      <entry>2046x1534</entry>
+	      <entry><emphasis>2046x1534</emphasis></entry>
+	      <entry><emphasis>2046x1534</emphasis></entry>
+	    </row>
+	    <row>
+	      <entry>Configure scaler output</entry>
+	      <entry>2048x1536</entry>
+	      <entry>2048x1536</entry>
+	      <entry>2046x1534</entry>
+	      <entry>2046x1534</entry>
+	      <entry><emphasis>1280x960</emphasis></entry>
+	    </row>
+	  </tbody>
+	</tgroup>
+      </table>
+
+      <para>
+      <orderedlist>
+	<listitem><para>Initial state. The sensor output is set to its native 3MP
+	resolution. Resolutions on the host frontend and scaler input and output
+	pads are undefined.</para></listitem>
+	<listitem><para>The application configures the frontend input pad resolution to
+	2048x1536. The driver propagates the format to the frontend output pad.
+	Note that the propagated output format can be different, as in this case,
+	than the input format, as the hardware might need to crop pixels (for
+	instance when converting a Bayer filter pattern to RGB or YUV).</para></listitem>
+	<listitem><para>The application configures the scaler input pad resolution to
+	2046x1534 to match the frontend output resolution. The driver propagates
+	the format to the scaler output pad.</para></listitem>
+	<listitem><para>The application configures the scaler output pad resolution to
+	1280x960.</para></listitem>
+      </orderedlist>
+      </para>
+
+      <para>When satisfied with the try results, applications can set the active
+      formats by setting the <structfield>which</structfield> argument to
+      <constant>V4L2_SUBDEV_FORMAT_TRY</constant>. Active formats are changed
+      exactly as try formats by drivers. To avoid modifying the hardware state
+      during format negotiation, applications should negotiate try formats first
+      and then modify the active settings using the try formats returned during
+      the last negotiation iteration. This guarantees that the active format
+      will be applied as-is by the driver without being modified.
+      </para>
+    </section>
+
+    <section>
+      <title>Cropping and scaling</title>
+
+      <para>Many sub-devices support cropping frames on their input or output
+      pads (or possible even on both). Cropping is used to select the area of
+      interest in an image, typically on a video sensor or video decoder. It can
+      also be used as part of digital zoom implementations to select the area of
+      the image that will be scaled up.</para>
+
+      <para>Crop settings are defined by a crop rectangle and represented in a
+      &v4l2-rect; by the coordinates of the top left corner and the rectangle
+      size. Both the coordinates and sizes are expressed in pixels.</para>
+
+      <para>The crop rectangle is retrieved and set using the
+      &VIDIOC-SUBDEV-G-CROP; and &VIDIOC-SUBDEV-S-CROP; ioctls. Like for pad
+      formats, drivers store try and active crop rectangles. The format
+      negotiation mechanism applies to crop settings as well.</para>
+
+      <para>On input pads, cropping is applied relatively to the current pad
+      format. The pad format represents the image size as received by the
+      sub-device from the previous block in the pipeline, and the crop rectangle
+      represents the sub-image that will be transmitted further inside the
+      sub-device for processing. The crop rectangle be entirely containted
+      inside the input image size.</para>
+
+      <para>Input crop rectangle are reset to their default value when the input
+      image format is modified. Drivers should use the input image size as the
+      crop rectangle default value, but hardware requirements may prevent this.
+      </para>
+
+      <para>Cropping behaviour on output pads is not defined.</para>
+
+    </section>
+  </section>
+
+  &sub-subdev-formats;

Documentation/DocBook/v4l/func-mmap.xml

@@ -45,7 +45,10 @@ just specify a <constant>NULL</constant> pointer here.</para>
 	<listitem>
 	  <para>Length of the memory area to map. This must be the
 same value as returned by the driver in the &v4l2-buffer;
-<structfield>length</structfield> field.</para>
+<structfield>length</structfield> field for the
+single-planar API, and the same value as returned by the driver
+in the &v4l2-plane; <structfield>length</structfield> field for the
+multi-planar API.</para>
 	</listitem>
       </varlistentry>
       <varlistentry>
@@ -106,7 +109,10 @@ flag.</para>
 	<listitem>
 	  <para>Offset of the buffer in device memory. This must be the
 same value as returned by the driver in the &v4l2-buffer;
-<structfield>m</structfield> union <structfield>offset</structfield> field.</para>
+<structfield>m</structfield> union <structfield>offset</structfield> field for
+the single-planar API, and the same value as returned by the driver
+in the &v4l2-plane; <structfield>m</structfield> union
+<structfield>mem_offset</structfield> field for the multi-planar API.</para>
 	</listitem>
       </varlistentry>
     </variablelist>

Documentation/DocBook/v4l/func-munmap.xml

@@ -37,7 +37,8 @@
 	  <para>Length of the mapped buffer. This must be the same
 value as given to <function>mmap()</function> and returned by the
 driver in the &v4l2-buffer; <structfield>length</structfield>
-field.</para>
+field for the single-planar API and in the &v4l2-plane;
+<structfield>length</structfield> field for the multi-planar API.</para>
 	</listitem>
       </varlistentry>
     </variablelist>

Documentation/DocBook/v4l/io.xml

@@ -121,18 +121,22 @@ mapped.</para>
     <para>Before applications can access the buffers they must map
 them into their address space with the &func-mmap; function. The
 location of the buffers in device memory can be determined with the
-&VIDIOC-QUERYBUF; ioctl. The <structfield>m.offset</structfield> and
-<structfield>length</structfield> returned in a &v4l2-buffer; are
-passed as sixth and second parameter to the
-<function>mmap()</function> function. The offset and length values
-must not be modified. Remember the buffers are allocated in physical
-memory, as opposed to virtual memory which can be swapped out to disk.
-Applications should free the buffers as soon as possible with the
-&func-munmap; function.</para>
+&VIDIOC-QUERYBUF; ioctl. In the single-planar API case, the
+<structfield>m.offset</structfield> and <structfield>length</structfield>
+returned in a &v4l2-buffer; are passed as sixth and second parameter to the
+<function>mmap()</function> function. When using the multi-planar API,
+struct &v4l2-buffer; contains an array of &v4l2-plane; structures, each
+containing its own <structfield>m.offset</structfield> and
+<structfield>length</structfield>. When using the multi-planar API, every
+plane of every buffer has to be mapped separately, so the number of
+calls to &func-mmap; should be equal to number of buffers times number of
+planes in each buffer. The offset and length values must not be modified.
+Remember, the buffers are allocated in physical memory, as opposed to virtual
+memory, which can be swapped out to disk. Applications should free the buffers
+as soon as possible with the &func-munmap; function.</para>

     <example>
-      <title>Mapping buffers</title>
-
+      <title>Mapping buffers in the single-planar API</title>
       <programlisting>
 &v4l2-requestbuffers; reqbuf;
 struct {
@@ -141,63 +145,145 @@ struct {
 } *buffers;
 unsigned int i;

-memset (&amp;reqbuf, 0, sizeof (reqbuf));
+memset(&amp;reqbuf, 0, sizeof(reqbuf));
 reqbuf.type = V4L2_BUF_TYPE_VIDEO_CAPTURE;
 reqbuf.memory = V4L2_MEMORY_MMAP;
 reqbuf.count = 20;

 if (-1 == ioctl (fd, &VIDIOC-REQBUFS;, &amp;reqbuf)) {
 	if (errno == EINVAL)
-		printf ("Video capturing or mmap-streaming is not supported\n");
+		printf("Video capturing or mmap-streaming is not supported\n");
 	else
-		perror ("VIDIOC_REQBUFS");
+		perror("VIDIOC_REQBUFS");

-	exit (EXIT_FAILURE);
+	exit(EXIT_FAILURE);
 }

 /* We want at least five buffers. */

 if (reqbuf.count &lt; 5) {
 	/* You may need to free the buffers here. */
-	printf ("Not enough buffer memory\n");
-	exit (EXIT_FAILURE);
+	printf("Not enough buffer memory\n");
+	exit(EXIT_FAILURE);
 }

-buffers = calloc (reqbuf.count, sizeof (*buffers));
-assert (buffers != NULL);
+buffers = calloc(reqbuf.count, sizeof(*buffers));
+assert(buffers != NULL);

 for (i = 0; i &lt; reqbuf.count; i++) {
 	&v4l2-buffer; buffer;

-	memset (&amp;buffer, 0, sizeof (buffer));
+	memset(&amp;buffer, 0, sizeof(buffer));
 	buffer.type = reqbuf.type;
 	buffer.memory = V4L2_MEMORY_MMAP;
 	buffer.index = i;

 	if (-1 == ioctl (fd, &VIDIOC-QUERYBUF;, &amp;buffer)) {
-		perror ("VIDIOC_QUERYBUF");
-		exit (EXIT_FAILURE);
+		perror("VIDIOC_QUERYBUF");
+		exit(EXIT_FAILURE);
 	}

 	buffers[i].length = buffer.length; /* remember for munmap() */

-	buffers[i].start = mmap (NULL, buffer.length,
-				 PROT_READ | PROT_WRITE, /* recommended */
-				 MAP_SHARED,             /* recommended */
-				 fd, buffer.m.offset);
+	buffers[i].start = mmap(NULL, buffer.length,
+				PROT_READ | PROT_WRITE, /* recommended */
+				MAP_SHARED,             /* recommended */
+				fd, buffer.m.offset);

 	if (MAP_FAILED == buffers[i].start) {
 		/* If you do not exit here you should unmap() and free()
 		   the buffers mapped so far. */
-		perror ("mmap");
-		exit (EXIT_FAILURE);
+		perror("mmap");
+		exit(EXIT_FAILURE);
+	}
+}
+
+/* Cleanup. */
+
+for (i = 0; i &lt; reqbuf.count; i++)
+	munmap(buffers[i].start, buffers[i].length);
+      </programlisting>
+    </example>
+
+    <example>
+      <title>Mapping buffers in the multi-planar API</title>
+      <programlisting>
+&v4l2-requestbuffers; reqbuf;
+/* Our current format uses 3 planes per buffer */
+#define FMT_NUM_PLANES = 3;
+
+struct {
+	void *start[FMT_NUM_PLANES];
+	size_t length[FMT_NUM_PLANES];
+} *buffers;
+unsigned int i, j;
+
+memset(&amp;reqbuf, 0, sizeof(reqbuf));
+reqbuf.type = V4L2_BUF_TYPE_VIDEO_CAPTURE_MPLANE;
+reqbuf.memory = V4L2_MEMORY_MMAP;
+reqbuf.count = 20;
+
+if (ioctl(fd, &VIDIOC-REQBUFS;, &amp;reqbuf) &lt; 0) {
+	if (errno == EINVAL)
+		printf("Video capturing or mmap-streaming is not supported\n");
+	else
+		perror("VIDIOC_REQBUFS");
+
+	exit(EXIT_FAILURE);
+}
+
+/* We want at least five buffers. */
+
+if (reqbuf.count &lt; 5) {
+	/* You may need to free the buffers here. */
+	printf("Not enough buffer memory\n");
+	exit(EXIT_FAILURE);
+}
+
+buffers = calloc(reqbuf.count, sizeof(*buffers));
+assert(buffers != NULL);
+
+for (i = 0; i &lt; reqbuf.count; i++) {
+	&v4l2-buffer; buffer;
+	&v4l2-plane; planes[FMT_NUM_PLANES];
+
+	memset(&amp;buffer, 0, sizeof(buffer));
+	buffer.type = reqbuf.type;
+	buffer.memory = V4L2_MEMORY_MMAP;
+	buffer.index = i;
+	/* length in struct v4l2_buffer in multi-planar API stores the size
+	 * of planes array. */
+	buffer.length = FMT_NUM_PLANES;
+	buffer.m.planes = planes;
+
+	if (ioctl(fd, &VIDIOC-QUERYBUF;, &amp;buffer) &lt; 0) {
+		perror("VIDIOC_QUERYBUF");
+		exit(EXIT_FAILURE);
+	}
+
+	/* Every plane has to be mapped separately */
+	for (j = 0; j &lt; FMT_NUM_PLANES; j++) {
+		buffers[i].length[j] = buffer.m.planes[j].length; /* remember for munmap() */
+
+		buffers[i].start[j] = mmap(NULL, buffer.m.planes[j].length,
+				 PROT_READ | PROT_WRITE, /* recommended */
+				 MAP_SHARED,             /* recommended */
+				 fd, buffer.m.planes[j].m.offset);
+
+		if (MAP_FAILED == buffers[i].start[j]) {
+			/* If you do not exit here you should unmap() and free()
+			   the buffers and planes mapped so far. */
+			perror("mmap");
+			exit(EXIT_FAILURE);
+		}
 	}
 }

 /* Cleanup. */

 for (i = 0; i &lt; reqbuf.count; i++)
-	munmap (buffers[i].start, buffers[i].length);
+	for (j = 0; j &lt; FMT_NUM_PLANES; j++)
+		munmap(buffers[i].start[j], buffers[i].length[j]);
       </programlisting>
     </example>

@@ -286,13 +372,13 @@ pointer method (not only memory mapping) is supported must be
 determined by calling the &VIDIOC-REQBUFS; ioctl.</para>

     <para>This I/O method combines advantages of the read/write and
-memory mapping methods. Buffers are allocated by the application
+memory mapping methods. Buffers (planes) are allocated by the application
 itself, and can reside for example in virtual or shared memory. Only
 pointers to data are exchanged, these pointers and meta-information
-are passed in &v4l2-buffer;. The driver must be switched
-into user pointer I/O mode by calling the &VIDIOC-REQBUFS; with the
-desired buffer type. No buffers are allocated beforehands,
-consequently they are not indexed and cannot be queried like mapped
+are passed in &v4l2-buffer; (or in &v4l2-plane; in the multi-planar API case).
+The driver must be switched into user pointer I/O mode by calling the
+&VIDIOC-REQBUFS; with the desired buffer type. No buffers (planes) are allocated
+beforehand, consequently they are not indexed and cannot be queried like mapped
 buffers with the <constant>VIDIOC_QUERYBUF</constant> ioctl.</para>

     <example>
@@ -316,7 +402,7 @@ if (ioctl (fd, &VIDIOC-REQBUFS;, &amp;reqbuf) == -1) {
       </programlisting>
     </example>

-    <para>Buffer addresses and sizes are passed on the fly with the
+    <para>Buffer (plane) addresses and sizes are passed on the fly with the
 &VIDIOC-QBUF; ioctl. Although buffers are commonly cycled,
 applications can pass different addresses and sizes at each
 <constant>VIDIOC_QBUF</constant> call. If required by the hardware the
@@ -396,11 +482,18 @@ rest should be evident.</para>
     <title>Buffers</title>

     <para>A buffer contains data exchanged by application and
-driver using one of the Streaming I/O methods. Only pointers to
-buffers are exchanged, the data itself is not copied. These pointers,
-together with meta-information like timestamps or field parity, are
-stored in a struct <structname>v4l2_buffer</structname>, argument to
-the &VIDIOC-QUERYBUF;, &VIDIOC-QBUF; and &VIDIOC-DQBUF; ioctl.</para>
+driver using one of the Streaming I/O methods. In the multi-planar API, the
+data is held in planes, while the buffer structure acts as a container
+for the planes. Only pointers to buffers (planes) are exchanged, the data
+itself is not copied. These pointers, together with meta-information like
+timestamps or field parity, are stored in a struct
+<structname>v4l2_buffer</structname>, argument to
+the &VIDIOC-QUERYBUF;, &VIDIOC-QBUF; and &VIDIOC-DQBUF; ioctl.
+In the multi-planar API, some plane-specific members of struct
+<structname>v4l2_buffer</structname>, such as pointers and sizes for each
+plane, are stored in struct <structname>v4l2_plane</structname> instead.
+In that case, struct <structname>v4l2_buffer</structname> contains an array of
+plane structures.</para>

       <para>Nominally timestamps refer to the first data byte transmitted.
 In practice however the wide range of hardware covered by the V4L2 API
@@ -551,26 +644,40 @@ in accordance with the selected I/O method.</entry>
 	    <entry></entry>
 	    <entry>__u32</entry>
 	    <entry><structfield>offset</structfield></entry>
-	    <entry>When <structfield>memory</structfield> is
-<constant>V4L2_MEMORY_MMAP</constant> this is the offset of the buffer
-from the start of the device memory. The value is returned by the
-driver and apart of serving as parameter to the &func-mmap; function
-not useful for applications. See <xref linkend="mmap" /> for details.</entry>
+	    <entry>For the single-planar API and when
+<structfield>memory</structfield> is <constant>V4L2_MEMORY_MMAP</constant> this
+is the offset of the buffer from the start of the device memory. The value is
+returned by the driver and apart of serving as parameter to the &func-mmap;
+function not useful for applications. See <xref linkend="mmap" /> for details
+	  </entry>
 	  </row>
 	  <row>
 	    <entry></entry>
 	    <entry>unsigned long</entry>
 	    <entry><structfield>userptr</structfield></entry>
-	    <entry>When <structfield>memory</structfield> is
-<constant>V4L2_MEMORY_USERPTR</constant> this is a pointer to the
-buffer (casted to unsigned long type) in virtual memory, set by the
-application. See <xref linkend="userp" /> for details.</entry>
+	    <entry>For the single-planar API and when
+<structfield>memory</structfield> is <constant>V4L2_MEMORY_USERPTR</constant>
+this is a pointer to the buffer (casted to unsigned long type) in virtual
+memory, set by the application. See <xref linkend="userp" /> for details.
+	    </entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry>struct v4l2_plane</entry>
+	    <entry><structfield>*planes</structfield></entry>
+	    <entry>When using the multi-planar API, contains a userspace pointer
+	    to an array of &v4l2-plane;. The size of the array should be put
+	    in the <structfield>length</structfield> field of this
+	    <structname>v4l2_buffer</structname> structure.</entry>
 	  </row>
 	  <row>
 	    <entry>__u32</entry>
 	    <entry><structfield>length</structfield></entry>
 	    <entry></entry>
-	    <entry>Size of the buffer (not the payload) in bytes.</entry>
+	    <entry>Size of the buffer (not the payload) in bytes for the
+	    single-planar API. For the multi-planar API should contain the
+	    number of elements in the <structfield>planes</structfield> array.
+	    </entry>
 	  </row>
 	  <row>
 	    <entry>__u32</entry>
@@ -596,6 +703,66 @@ should set this to 0.</entry>
       </tgroup>
     </table>

+    <table frame="none" pgwide="1" id="v4l2-plane">
+      <title>struct <structname>v4l2_plane</structname></title>
+      <tgroup cols="4">
+        &cs-ustr;
+	<tbody valign="top">
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>bytesused</structfield></entry>
+	    <entry></entry>
+	    <entry>The number of bytes occupied by data in the plane
+	    (its payload).</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>length</structfield></entry>
+	    <entry></entry>
+	    <entry>Size in bytes of the plane (not its payload).</entry>
+	  </row>
+	  <row>
+	    <entry>union</entry>
+	    <entry><structfield>m</structfield></entry>
+	    <entry></entry>
+	    <entry></entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry>__u32</entry>
+	    <entry><structfield>mem_offset</structfield></entry>
+	    <entry>When the memory type in the containing &v4l2-buffer; is
+	      <constant>V4L2_MEMORY_MMAP</constant>, this is the value that
+	      should be passed to &func-mmap;, similar to the
+	      <structfield>offset</structfield> field in &v4l2-buffer;.</entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry>__unsigned long</entry>
+	    <entry><structfield>userptr</structfield></entry>
+	    <entry>When the memory type in the containing &v4l2-buffer; is
+	      <constant>V4L2_MEMORY_USERPTR</constant>, this is a userspace
+	      pointer to the memory allocated for this plane by an application.
+	      </entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>data_offset</structfield></entry>
+	    <entry></entry>
+	    <entry>Offset in bytes to video data in the plane, if applicable.
+	    </entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>reserved[11]</structfield></entry>
+	    <entry></entry>
+	    <entry>Reserved for future use. Should be zeroed by an
+	    application.</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+
     <table frame="none" pgwide="1" id="v4l2-buf-type">
       <title>enum v4l2_buf_type</title>
       <tgroup cols="3">
@@ -604,13 +771,27 @@ should set this to 0.</entry>
 	  <row>
 	    <entry><constant>V4L2_BUF_TYPE_VIDEO_CAPTURE</constant></entry>
 	    <entry>1</entry>
-	    <entry>Buffer of a video capture stream, see <xref
+	    <entry>Buffer of a single-planar video capture stream, see <xref
+		linkend="capture" />.</entry>
+	  </row>
+	  <row>
+	    <entry><constant>V4L2_BUF_TYPE_VIDEO_CAPTURE_MPLANE</constant>
+	    </entry>
+	    <entry>9</entry>
+	    <entry>Buffer of a multi-planar video capture stream, see <xref
 		linkend="capture" />.</entry>
 	  </row>
 	  <row>
 	    <entry><constant>V4L2_BUF_TYPE_VIDEO_OUTPUT</constant></entry>
 	    <entry>2</entry>
-	    <entry>Buffer of a video output stream, see <xref
+	    <entry>Buffer of a single-planar video output stream, see <xref
+		linkend="output" />.</entry>
+	  </row>
+	  <row>
+	    <entry><constant>V4L2_BUF_TYPE_VIDEO_OUTPUT_MPLANE</constant>
+	    </entry>
+	    <entry>10</entry>
+	    <entry>Buffer of a multi-planar video output stream, see <xref
 		linkend="output" />.</entry>
 	  </row>
 	  <row>

Documentation/DocBook/v4l/lirc_device_interface.xml

@@ -45,7 +45,7 @@ describing an IR signal are read from the chardev.</para>
 <para>The data written to the chardev is a pulse/space sequence of integer
 values. Pulses and spaces are only marked implicitly by their position. The
 data must start and end with a pulse, therefore, the data must always include
-an unevent number of samples. The write function must block until the data has
+an uneven number of samples. The write function must block until the data has
 been transmitted by the hardware.</para>
 </section>


Documentation/DocBook/v4l/media-controller.xml

@@ -0,0 +1,89 @@
+<partinfo>
+  <authorgroup>
+    <author>
+      <firstname>Laurent</firstname>
+      <surname>Pinchart</surname>
+      <affiliation><address><email>laurent.pinchart@ideasonboard.com</email></address></affiliation>
+      <contrib>Initial version.</contrib>
+    </author>
+  </authorgroup>
+  <copyright>
+    <year>2010</year>
+    <holder>Laurent Pinchart</holder>
+  </copyright>
+
+  <revhistory>
+    <!-- Put document revisions here, newest first. -->
+    <revision>
+      <revnumber>1.0.0</revnumber>
+      <date>2010-11-10</date>
+      <authorinitials>lp</authorinitials>
+      <revremark>Initial revision</revremark>
+    </revision>
+  </revhistory>
+</partinfo>
+
+<title>Media Controller API</title>
+
+<chapter id="media_controller">
+  <title>Media Controller</title>
+
+  <section id="media-controller-intro">
+    <title>Introduction</title>
+    <para>Media devices increasingly handle multiple related functions. Many USB
+    cameras include microphones, video capture hardware can also output video,
+    or SoC camera interfaces also perform memory-to-memory operations similar to
+    video codecs.</para>
+    <para>Independent functions, even when implemented in the same hardware, can
+    be modelled as separate devices. A USB camera with a microphone will be
+    presented to userspace applications as V4L2 and ALSA capture devices. The
+    devices' relationships (when using a webcam, end-users shouldn't have to
+    manually select the associated USB microphone), while not made available
+    directly to applications by the drivers, can usually be retrieved from
+    sysfs.</para>
+    <para>With more and more advanced SoC devices being introduced, the current
+    approach will not scale. Device topologies are getting increasingly complex
+    and can't always be represented by a tree structure. Hardware blocks are
+    shared between different functions, creating dependencies between seemingly
+    unrelated devices.</para>
+    <para>Kernel abstraction APIs such as V4L2 and ALSA provide means for
+    applications to access hardware parameters. As newer hardware expose an
+    increasingly high number of those parameters, drivers need to guess what
+    applications really require based on limited information, thereby
+    implementing policies that belong to userspace.</para>
+    <para>The media controller API aims at solving those problems.</para>
+  </section>
+
+  <section id="media-controller-model">
+    <title>Media device model</title>
+    <para>Discovering a device internal topology, and configuring it at runtime,
+    is one of the goals of the media controller API. To achieve this, hardware
+    devices are modelled as an oriented graph of building blocks called entities
+    connected through pads.</para>
+    <para>An entity is a basic media hardware or software building block. It can
+    correspond to a large variety of logical blocks such as physical hardware
+    devices (CMOS sensor for instance), logical hardware devices (a building
+    block in a System-on-Chip image processing pipeline), DMA channels or
+    physical connectors.</para>
+    <para>A pad is a connection endpoint through which an entity can interact
+    with other entities. Data (not restricted to video) produced by an entity
+    flows from the entity's output to one or more entity inputs. Pads should not
+    be confused with physical pins at chip boundaries.</para>
+    <para>A link is a point-to-point oriented connection between two pads,
+    either on the same entity or on different entities. Data flows from a source
+    pad to a sink pad.</para>
+  </section>
+</chapter>
+
+<appendix id="media-user-func">
+  <title>Function Reference</title>
+  <!-- Keep this alphabetically sorted. -->
+  &sub-media-open;
+  &sub-media-close;
+  &sub-media-ioctl;
+  <!-- All ioctls go here. -->
+  &sub-media-ioc-device-info;
+  &sub-media-ioc-enum-entities;
+  &sub-media-ioc-enum-links;
+  &sub-media-ioc-setup-link;
+</appendix>

Documentation/DocBook/v4l/media-func-close.xml

@@ -0,0 +1,59 @@
+<refentry id="media-func-close">
+  <refmeta>
+    <refentrytitle>media close()</refentrytitle>
+    &manvol;
+  </refmeta>
+
+  <refnamediv>
+    <refname>media-close</refname>
+    <refpurpose>Close a media device</refpurpose>
+  </refnamediv>
+
+  <refsynopsisdiv>
+    <funcsynopsis>
+      <funcsynopsisinfo>#include &lt;unistd.h&gt;</funcsynopsisinfo>
+      <funcprototype>
+	<funcdef>int <function>close</function></funcdef>
+	<paramdef>int <parameter>fd</parameter></paramdef>
+      </funcprototype>
+    </funcsynopsis>
+  </refsynopsisdiv>
+
+  <refsect1>
+    <title>Arguments</title>
+
+    <variablelist>
+      <varlistentry>
+	<term><parameter>fd</parameter></term>
+	<listitem>
+	  <para>&fd;</para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+
+  <refsect1>
+    <title>Description</title>
+
+    <para>Closes the media device. Resources associated with the file descriptor
+    are freed. The device configuration remain unchanged.</para>
+  </refsect1>
+
+  <refsect1>
+    <title>Return Value</title>
+
+    <para><function>close</function> returns 0 on success. On error, -1 is
+    returned, and <varname>errno</varname> is set appropriately. Possible error
+    codes are:</para>
+
+    <variablelist>
+      <varlistentry>
+	<term><errorcode>EBADF</errorcode></term>
+	<listitem>
+	  <para><parameter>fd</parameter> is not a valid open file descriptor.
+	  </para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+</refentry>

Documentation/DocBook/v4l/media-func-ioctl.xml

@@ -0,0 +1,116 @@
+<refentry id="media-func-ioctl">
+  <refmeta>
+    <refentrytitle>media ioctl()</refentrytitle>
+    &manvol;
+  </refmeta>
+
+  <refnamediv>
+    <refname>media-ioctl</refname>
+    <refpurpose>Control a media device</refpurpose>
+  </refnamediv>
+
+  <refsynopsisdiv>
+    <funcsynopsis>
+      <funcsynopsisinfo>#include &lt;sys/ioctl.h&gt;</funcsynopsisinfo>
+      <funcprototype>
+	<funcdef>int <function>ioctl</function></funcdef>
+	<paramdef>int <parameter>fd</parameter></paramdef>
+	<paramdef>int <parameter>request</parameter></paramdef>
+	<paramdef>void *<parameter>argp</parameter></paramdef>
+      </funcprototype>
+    </funcsynopsis>
+  </refsynopsisdiv>
+
+  <refsect1>
+    <title>Arguments</title>
+
+    <variablelist>
+      <varlistentry>
+	<term><parameter>fd</parameter></term>
+	<listitem>
+	  <para>&fd;</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>request</parameter></term>
+	<listitem>
+	  <para>Media ioctl request code as defined in the media.h header file,
+	  for example MEDIA_IOC_SETUP_LINK.</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>argp</parameter></term>
+	<listitem>
+	  <para>Pointer to a request-specific structure.</para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+
+  <refsect1>
+    <title>Description</title>
+    <para>The <function>ioctl()</function> function manipulates media device
+    parameters. The argument <parameter>fd</parameter> must be an open file
+    descriptor.</para>
+    <para>The ioctl <parameter>request</parameter> code specifies the media
+    function to be called. It has encoded in it whether the argument is an
+    input, output or read/write parameter, and the size of the argument
+    <parameter>argp</parameter> in bytes.</para>
+    <para>Macros and structures definitions specifying media ioctl requests and
+    their parameters are located in the media.h header file. All media ioctl
+    requests, their respective function and parameters are specified in
+    <xref linkend="media-user-func" />.</para>
+  </refsect1>
+
+  <refsect1>
+    <title>Return Value</title>
+
+    <para><function>ioctl()</function> returns <returnvalue>0</returnvalue> on
+    success. On failure, <returnvalue>-1</returnvalue> is returned, and the
+    <varname>errno</varname> variable is set appropriately. Generic error codes
+    are listed below, and request-specific error codes are listed in the
+    individual requests descriptions.</para>
+    <para>When an ioctl that takes an output or read/write parameter fails,
+    the parameter remains unmodified.</para>
+
+    <variablelist>
+      <varlistentry>
+	<term><errorcode>EBADF</errorcode></term>
+	<listitem>
+	  <para><parameter>fd</parameter> is not a valid open file descriptor.
+	  </para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><errorcode>EFAULT</errorcode></term>
+	<listitem>
+	  <para><parameter>argp</parameter> references an inaccessible memory
+	  area.</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><errorcode>EINVAL</errorcode></term>
+	<listitem>
+	  <para>The <parameter>request</parameter> or the data pointed to by
+	  <parameter>argp</parameter> is not valid. This is a very common error
+	  code, see the individual ioctl requests listed in
+	  <xref linkend="media-user-func" /> for actual causes.</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><errorcode>ENOMEM</errorcode></term>
+	<listitem>
+	  <para>Insufficient kernel memory was available to complete the
+	  request.</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><errorcode>ENOTTY</errorcode></term>
+	<listitem>
+	  <para><parameter>fd</parameter> is  not  associated  with  a character
+	  special device.</para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+</refentry>

Documentation/DocBook/v4l/media-func-open.xml

@@ -0,0 +1,94 @@
+<refentry id="media-func-open">
+  <refmeta>
+    <refentrytitle>media open()</refentrytitle>
+    &manvol;
+  </refmeta>
+
+  <refnamediv>
+    <refname>media-open</refname>
+    <refpurpose>Open a media device</refpurpose>
+  </refnamediv>
+
+  <refsynopsisdiv>
+    <funcsynopsis>
+      <funcsynopsisinfo>#include &lt;fcntl.h&gt;</funcsynopsisinfo>
+      <funcprototype>
+	<funcdef>int <function>open</function></funcdef>
+	<paramdef>const char *<parameter>device_name</parameter></paramdef>
+	<paramdef>int <parameter>flags</parameter></paramdef>
+      </funcprototype>
+    </funcsynopsis>
+  </refsynopsisdiv>
+
+  <refsect1>
+    <title>Arguments</title>
+
+    <variablelist>
+      <varlistentry>
+	<term><parameter>device_name</parameter></term>
+	<listitem>
+	  <para>Device to be opened.</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>flags</parameter></term>
+	<listitem>
+	  <para>Open flags. Access mode must be either <constant>O_RDONLY</constant>
+	  or <constant>O_RDWR</constant>. Other flags have no effect.</para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+  <refsect1>
+    <title>Description</title>
+    <para>To open a media device applications call <function>open()</function>
+    with the desired device name. The function has no side effects; the device
+    configuration remain unchanged.</para>
+    <para>When the device is opened in read-only mode, attemps to modify its
+    configuration will result in an error, and <varname>errno</varname> will be
+    set to <errorcode>EBADF</errorcode>.</para>
+  </refsect1>
+  <refsect1>
+    <title>Return Value</title>
+
+    <para><function>open</function> returns the new file descriptor on success.
+    On error, -1 is returned, and <varname>errno</varname> is set appropriately.
+    Possible error codes are:</para>
+
+    <variablelist>
+      <varlistentry>
+	<term><errorcode>EACCES</errorcode></term>
+	<listitem>
+	  <para>The requested access to the file is not allowed.</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><errorcode>EMFILE</errorcode></term>
+	<listitem>
+	  <para>The  process  already  has  the  maximum number of files open.
+	  </para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><errorcode>ENFILE</errorcode></term>
+	<listitem>
+	  <para>The system limit on the total number of open files has been
+	  reached.</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><errorcode>ENOMEM</errorcode></term>
+	<listitem>
+	  <para>Insufficient kernel memory was available.</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><errorcode>ENXIO</errorcode></term>
+	<listitem>
+	  <para>No device corresponding to this device special file exists.
+	  </para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+</refentry>

Documentation/DocBook/v4l/media-ioc-device-info.xml

@@ -0,0 +1,133 @@
+<refentry id="media-ioc-device-info">
+  <refmeta>
+    <refentrytitle>ioctl MEDIA_IOC_DEVICE_INFO</refentrytitle>
+    &manvol;
+  </refmeta>
+
+  <refnamediv>
+    <refname>MEDIA_IOC_DEVICE_INFO</refname>
+    <refpurpose>Query device information</refpurpose>
+  </refnamediv>
+
+  <refsynopsisdiv>
+    <funcsynopsis>
+      <funcprototype>
+	<funcdef>int <function>ioctl</function></funcdef>
+	<paramdef>int <parameter>fd</parameter></paramdef>
+	<paramdef>int <parameter>request</parameter></paramdef>
+	<paramdef>struct media_device_info *<parameter>argp</parameter></paramdef>
+      </funcprototype>
+    </funcsynopsis>
+  </refsynopsisdiv>
+
+  <refsect1>
+    <title>Arguments</title>
+
+    <variablelist>
+      <varlistentry>
+	<term><parameter>fd</parameter></term>
+	<listitem>
+	  <para>File descriptor returned by
+	  <link linkend='media-func-open'><function>open()</function></link>.</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>request</parameter></term>
+	<listitem>
+	  <para>MEDIA_IOC_DEVICE_INFO</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>argp</parameter></term>
+	<listitem>
+	  <para></para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+
+  <refsect1>
+    <title>Description</title>
+
+    <para>All media devices must support the <constant>MEDIA_IOC_DEVICE_INFO</constant>
+    ioctl. To query device information, applications call the ioctl with a
+    pointer to a &media-device-info;. The driver fills the structure and returns
+    the information to the application.
+    The ioctl never fails.</para>
+
+    <table pgwide="1" frame="none" id="media-device-info">
+      <title>struct <structname>media_device_info</structname></title>
+      <tgroup cols="3">
+	&cs-str;
+	<tbody valign="top">
+	  <row>
+	    <entry>char</entry>
+	    <entry><structfield>driver</structfield>[16]</entry>
+	    <entry><para>Name of the driver implementing the media API as a
+	    NUL-terminated ASCII string. The driver version is stored in the
+	    <structfield>driver_version</structfield> field.</para>
+	    <para>Driver specific applications can use this information to
+	    verify the driver identity. It is also useful to work around
+	    known bugs, or to identify drivers in error reports.</para></entry>
+	  </row>
+	  <row>
+	    <entry>char</entry>
+	    <entry><structfield>model</structfield>[32]</entry>
+	    <entry>Device model name as a NUL-terminated UTF-8 string. The
+	    device version is stored in the <structfield>device_version</structfield>
+	    field and is not be appended to the model name.</entry>
+	  </row>
+	  <row>
+	    <entry>char</entry>
+	    <entry><structfield>serial</structfield>[40]</entry>
+	    <entry>Serial number as a NUL-terminated ASCII string.</entry>
+	  </row>
+	  <row>
+	    <entry>char</entry>
+	    <entry><structfield>bus_info</structfield>[32]</entry>
+	    <entry>Location of the device in the system as a NUL-terminated
+	    ASCII string. This includes the bus type name (PCI, USB, ...) and a
+	    bus-specific identifier.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>media_version</structfield></entry>
+	    <entry>Media API version, formatted with the
+	    <constant>KERNEL_VERSION()</constant> macro.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>hw_revision</structfield></entry>
+	    <entry>Hardware device revision in a driver-specific format.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>media_version</structfield></entry>
+	    <entry>Media device driver version, formatted with the
+	    <constant>KERNEL_VERSION()</constant> macro. Together with the
+	    <structfield>driver</structfield> field this identifies a particular
+	    driver.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>reserved</structfield>[31]</entry>
+	    <entry>Reserved for future extensions. Drivers and applications must
+	    set this array to zero.</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+    <para>The <structfield>serial</structfield> and <structfield>bus_info</structfield>
+    fields can be used to distinguish between multiple instances of otherwise
+    identical hardware. The serial number takes precedence when provided and can
+    be assumed to be unique. If the serial number is an empty string, the
+    <structfield>bus_info</structfield> field can be used instead. The
+    <structfield>bus_info</structfield> field is guaranteed to be unique, but
+    can vary across reboots or device unplug/replug.</para>
+  </refsect1>
+
+  <refsect1>
+    <title>Return value</title>
+    <para>This function doesn't return specific error codes.</para>
+  </refsect1>
+</refentry>

Documentation/DocBook/v4l/media-ioc-enum-entities.xml

@@ -0,0 +1,308 @@
+<refentry id="media-ioc-enum-entities">
+  <refmeta>
+    <refentrytitle>ioctl MEDIA_IOC_ENUM_ENTITIES</refentrytitle>
+    &manvol;
+  </refmeta>
+
+  <refnamediv>
+    <refname>MEDIA_IOC_ENUM_ENTITIES</refname>
+    <refpurpose>Enumerate entities and their properties</refpurpose>
+  </refnamediv>
+
+  <refsynopsisdiv>
+    <funcsynopsis>
+      <funcprototype>
+	<funcdef>int <function>ioctl</function></funcdef>
+	<paramdef>int <parameter>fd</parameter></paramdef>
+	<paramdef>int <parameter>request</parameter></paramdef>
+	<paramdef>struct media_entity_desc *<parameter>argp</parameter></paramdef>
+      </funcprototype>
+    </funcsynopsis>
+  </refsynopsisdiv>
+
+  <refsect1>
+    <title>Arguments</title>
+
+    <variablelist>
+      <varlistentry>
+	<term><parameter>fd</parameter></term>
+	<listitem>
+	  <para>File descriptor returned by
+	  <link linkend='media-func-open'><function>open()</function></link>.</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>request</parameter></term>
+	<listitem>
+	  <para>MEDIA_IOC_ENUM_ENTITIES</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>argp</parameter></term>
+	<listitem>
+	  <para></para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+
+  <refsect1>
+    <title>Description</title>
+    <para>To query the attributes of an entity, applications set the id field
+    of a &media-entity-desc; structure and call the MEDIA_IOC_ENUM_ENTITIES
+    ioctl with a pointer to this structure. The driver fills the rest of the
+    structure or returns an &EINVAL; when the id is invalid.</para>
+    <para>Entities can be enumerated by or'ing the id with the
+    <constant>MEDIA_ENT_ID_FLAG_NEXT</constant> flag. The driver will return
+    information about the entity with the smallest id strictly larger than the
+    requested one ('next entity'), or the &EINVAL; if there is none.</para>
+    <para>Entity IDs can be non-contiguous. Applications must
+    <emphasis>not</emphasis> try to enumerate entities by calling
+    MEDIA_IOC_ENUM_ENTITIES with increasing id's until they get an error.</para>
+    <para>Two or more entities that share a common non-zero
+    <structfield>group_id</structfield> value are considered as logically
+    grouped. Groups are used to report
+    <itemizedlist>
+      <listitem><para>ALSA, VBI and video nodes that carry the same media
+      stream</para></listitem>
+      <listitem><para>lens and flash controllers associated with a sensor</para></listitem>
+    </itemizedlist>
+    </para>
+
+    <table pgwide="1" frame="none" id="media-entity-desc">
+      <title>struct <structname>media_entity_desc</structname></title>
+      <tgroup cols="5">
+	<colspec colname="c1" />
+	<colspec colname="c2" />
+	<colspec colname="c3" />
+	<colspec colname="c4" />
+	<colspec colname="c5" />
+	<tbody valign="top">
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>id</structfield></entry>
+	    <entry></entry>
+	    <entry></entry>
+	    <entry>Entity id, set by the application. When the id is or'ed with
+	    <constant>MEDIA_ENT_ID_FLAG_NEXT</constant>, the driver clears the
+	    flag and returns the first entity with a larger id.</entry>
+	  </row>
+	  <row>
+	    <entry>char</entry>
+	    <entry><structfield>name</structfield>[32]</entry>
+	    <entry></entry>
+	    <entry></entry>
+	    <entry>Entity name as an UTF-8 NULL-terminated string.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>type</structfield></entry>
+	    <entry></entry>
+	    <entry></entry>
+	    <entry>Entity type, see <xref linkend="media-entity-type" /> for details.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>revision</structfield></entry>
+	    <entry></entry>
+	    <entry></entry>
+	    <entry>Entity revision in a driver/hardware specific format.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>flags</structfield></entry>
+	    <entry></entry>
+	    <entry></entry>
+	    <entry>Entity flags, see <xref linkend="media-entity-flag" /> for details.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>group_id</structfield></entry>
+	    <entry></entry>
+	    <entry></entry>
+	    <entry>Entity group ID</entry>
+	  </row>
+	  <row>
+	    <entry>__u16</entry>
+	    <entry><structfield>pads</structfield></entry>
+	    <entry></entry>
+	    <entry></entry>
+	    <entry>Number of pads</entry>
+	  </row>
+	  <row>
+	    <entry>__u16</entry>
+	    <entry><structfield>links</structfield></entry>
+	    <entry></entry>
+	    <entry></entry>
+	    <entry>Total number of outbound links. Inbound links are not counted
+	    in this field.</entry>
+	  </row>
+	  <row>
+	    <entry>union</entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry>struct</entry>
+	    <entry><structfield>v4l</structfield></entry>
+	    <entry></entry>
+	    <entry>Valid for V4L sub-devices and nodes only.</entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry></entry>
+	    <entry>__u32</entry>
+	    <entry><structfield>major</structfield></entry>
+	    <entry>V4L device node major number. For V4L sub-devices with no
+	    device node, set by the driver to 0.</entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry></entry>
+	    <entry>__u32</entry>
+	    <entry><structfield>minor</structfield></entry>
+	    <entry>V4L device node minor number. For V4L sub-devices with no
+	    device node, set by the driver to 0.</entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry>struct</entry>
+	    <entry><structfield>fb</structfield></entry>
+	    <entry></entry>
+	    <entry>Valid for frame buffer nodes only.</entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry></entry>
+	    <entry>__u32</entry>
+	    <entry><structfield>major</structfield></entry>
+	    <entry>Frame buffer device node major number.</entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry></entry>
+	    <entry>__u32</entry>
+	    <entry><structfield>minor</structfield></entry>
+	    <entry>Frame buffer device node minor number.</entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry>struct</entry>
+	    <entry><structfield>alsa</structfield></entry>
+	    <entry></entry>
+	    <entry>Valid for ALSA devices only.</entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry></entry>
+	    <entry>__u32</entry>
+	    <entry><structfield>card</structfield></entry>
+	    <entry>ALSA card number</entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry></entry>
+	    <entry>__u32</entry>
+	    <entry><structfield>device</structfield></entry>
+	    <entry>ALSA device number</entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry></entry>
+	    <entry>__u32</entry>
+	    <entry><structfield>subdevice</structfield></entry>
+	    <entry>ALSA sub-device number</entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry>int</entry>
+	    <entry><structfield>dvb</structfield></entry>
+	    <entry></entry>
+	    <entry>DVB card number</entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry>__u8</entry>
+	    <entry><structfield>raw</structfield>[180]</entry>
+	    <entry></entry>
+	    <entry></entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+
+    <table frame="none" pgwide="1" id="media-entity-type">
+      <title>Media entity types</title>
+      <tgroup cols="2">
+        <colspec colname="c1"/>
+        <colspec colname="c2"/>
+	<tbody valign="top">
+	  <row>
+	    <entry><constant>MEDIA_ENT_T_DEVNODE</constant></entry>
+	    <entry>Unknown device node</entry>
+	  </row>
+	  <row>
+	    <entry><constant>MEDIA_ENT_T_DEVNODE_V4L</constant></entry>
+	    <entry>V4L video, radio or vbi device node</entry>
+	  </row>
+	  <row>
+	    <entry><constant>MEDIA_ENT_T_DEVNODE_FB</constant></entry>
+	    <entry>Frame buffer device node</entry>
+	  </row>
+	  <row>
+	    <entry><constant>MEDIA_ENT_T_DEVNODE_ALSA</constant></entry>
+	    <entry>ALSA card</entry>
+	  </row>
+	  <row>
+	    <entry><constant>MEDIA_ENT_T_DEVNODE_DVB</constant></entry>
+	    <entry>DVB card</entry>
+	  </row>
+	  <row>
+	    <entry><constant>MEDIA_ENT_T_V4L2_SUBDEV</constant></entry>
+	    <entry>Unknown V4L sub-device</entry>
+	  </row>
+	  <row>
+	    <entry><constant>MEDIA_ENT_T_V4L2_SUBDEV_SENSOR</constant></entry>
+	    <entry>Video sensor</entry>
+	  </row>
+	  <row>
+	    <entry><constant>MEDIA_ENT_T_V4L2_SUBDEV_FLASH</constant></entry>
+	    <entry>Flash controller</entry>
+	  </row>
+	  <row>
+	    <entry><constant>MEDIA_ENT_T_V4L2_SUBDEV_LENS</constant></entry>
+	    <entry>Lens controller</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+
+    <table frame="none" pgwide="1" id="media-entity-flag">
+      <title>Media entity flags</title>
+      <tgroup cols="2">
+        <colspec colname="c1"/>
+        <colspec colname="c2"/>
+	<tbody valign="top">
+	  <row>
+	    <entry><constant>MEDIA_ENT_FL_DEFAULT</constant></entry>
+	    <entry>Default entity for its type. Used to discover the default
+	    audio, VBI and video devices, the default camera sensor, ...</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+  </refsect1>
+
+  <refsect1>
+    &return-value;
+
+    <variablelist>
+      <varlistentry>
+	<term><errorcode>EINVAL</errorcode></term>
+	<listitem>
+	  <para>The &media-entity-desc; <structfield>id</structfield> references
+	  a non-existing entity.</para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+</refentry>

Documentation/DocBook/v4l/media-ioc-enum-links.xml

@@ -0,0 +1,207 @@
+<refentry id="media-ioc-enum-links">
+  <refmeta>
+    <refentrytitle>ioctl MEDIA_IOC_ENUM_LINKS</refentrytitle>
+    &manvol;
+  </refmeta>
+
+  <refnamediv>
+    <refname>MEDIA_IOC_ENUM_LINKS</refname>
+    <refpurpose>Enumerate all pads and links for a given entity</refpurpose>
+  </refnamediv>
+
+  <refsynopsisdiv>
+    <funcsynopsis>
+      <funcprototype>
+	<funcdef>int <function>ioctl</function></funcdef>
+	<paramdef>int <parameter>fd</parameter></paramdef>
+	<paramdef>int <parameter>request</parameter></paramdef>
+	<paramdef>struct media_links_enum *<parameter>argp</parameter></paramdef>
+      </funcprototype>
+    </funcsynopsis>
+  </refsynopsisdiv>
+
+  <refsect1>
+    <title>Arguments</title>
+
+    <variablelist>
+      <varlistentry>
+	<term><parameter>fd</parameter></term>
+	<listitem>
+	  <para>File descriptor returned by
+	  <link linkend='media-func-open'><function>open()</function></link>.</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>request</parameter></term>
+	<listitem>
+	  <para>MEDIA_IOC_ENUM_LINKS</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>argp</parameter></term>
+	<listitem>
+	  <para></para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+
+  <refsect1>
+    <title>Description</title>
+
+    <para>To enumerate pads and/or links for a given entity, applications set
+    the entity field of a &media-links-enum; structure and initialize the
+    &media-pad-desc; and &media-link-desc; structure arrays pointed by the
+    <structfield>pads</structfield> and <structfield>links</structfield> fields.
+    They then call the MEDIA_IOC_ENUM_LINKS ioctl with a pointer to this
+    structure.</para>
+    <para>If the <structfield>pads</structfield> field is not NULL, the driver
+    fills the <structfield>pads</structfield> array with information about the
+    entity's pads. The array must have enough room to store all the entity's
+    pads. The number of pads can be retrieved with the &MEDIA-IOC-ENUM-ENTITIES;
+    ioctl.</para>
+    <para>If the <structfield>links</structfield> field is not NULL, the driver
+    fills the <structfield>links</structfield> array with information about the
+    entity's outbound links. The array must have enough room to store all the
+    entity's outbound links. The number of outbound links can be retrieved with
+    the &MEDIA-IOC-ENUM-ENTITIES; ioctl.</para>
+    <para>Only forward links that originate at one of the entity's source pads
+    are returned during the enumeration process.</para>
+
+    <table pgwide="1" frame="none" id="media-links-enum">
+      <title>struct <structname>media_links_enum</structname></title>
+      <tgroup cols="3">
+        &cs-str;
+	<tbody valign="top">
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>entity</structfield></entry>
+	    <entry>Entity id, set by the application.</entry>
+	  </row>
+	  <row>
+	    <entry>struct &media-pad-desc;</entry>
+	    <entry>*<structfield>pads</structfield></entry>
+	    <entry>Pointer to a pads array allocated by the application. Ignored
+	    if NULL.</entry>
+	  </row>
+	  <row>
+	    <entry>struct &media-link-desc;</entry>
+	    <entry>*<structfield>links</structfield></entry>
+	    <entry>Pointer to a links array allocated by the application. Ignored
+	    if NULL.</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+
+    <table pgwide="1" frame="none" id="media-pad-desc">
+      <title>struct <structname>media_pad_desc</structname></title>
+      <tgroup cols="3">
+        &cs-str;
+	<tbody valign="top">
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>entity</structfield></entry>
+	    <entry>ID of the entity this pad belongs to.</entry>
+	  </row>
+	  <row>
+	    <entry>__u16</entry>
+	    <entry><structfield>index</structfield></entry>
+	    <entry>0-based pad index.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>flags</structfield></entry>
+	    <entry>Pad flags, see <xref linkend="media-pad-flag" /> for more details.</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+
+    <table frame="none" pgwide="1" id="media-pad-flag">
+      <title>Media pad flags</title>
+      <tgroup cols="2">
+        <colspec colname="c1"/>
+        <colspec colname="c2"/>
+	<tbody valign="top">
+	  <row>
+	    <entry><constant>MEDIA_PAD_FL_SINK</constant></entry>
+	    <entry>Input pad, relative to the entity. Input pads sink data and
+	    are targets of links.</entry>
+	  </row>
+	  <row>
+	    <entry><constant>MEDIA_PAD_FL_SOURCE</constant></entry>
+	    <entry>Output pad, relative to the entity. Output pads source data
+	    and are origins of links.</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+
+    <table pgwide="1" frame="none" id="media-link-desc">
+      <title>struct <structname>media_links_desc</structname></title>
+      <tgroup cols="3">
+        &cs-str;
+	<tbody valign="top">
+	  <row>
+	    <entry>struct &media-pad-desc;</entry>
+	    <entry><structfield>source</structfield></entry>
+	    <entry>Pad at the origin of this link.</entry>
+	  </row>
+	  <row>
+	    <entry>struct &media-pad-desc;</entry>
+	    <entry><structfield>sink</structfield></entry>
+	    <entry>Pad at the target of this link.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>flags</structfield></entry>
+	    <entry>Link flags, see <xref linkend="media-link-flag" /> for more details.</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+
+    <table frame="none" pgwide="1" id="media-link-flag">
+      <title>Media link flags</title>
+      <tgroup cols="2">
+        <colspec colname="c1"/>
+        <colspec colname="c2"/>
+	<tbody valign="top">
+	  <row>
+	    <entry><constant>MEDIA_LNK_FL_ENABLED</constant></entry>
+	    <entry>The link is enabled and can be used to transfer media data.
+	    When two or more links target a sink pad, only one of them can be
+	    enabled at a time.</entry>
+	  </row>
+	  <row>
+	    <entry><constant>MEDIA_LNK_FL_IMMUTABLE</constant></entry>
+	    <entry>The link enabled state can't be modified at runtime. An
+	    immutable link is always enabled.</entry>
+	  </row>
+	  <row>
+	    <entry><constant>MEDIA_LNK_FL_DYNAMIC</constant></entry>
+	    <entry>The link enabled state can be modified during streaming. This
+	    flag is set by drivers and is read-only for applications.</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+    <para>One and only one of <constant>MEDIA_PAD_FL_SINK</constant> and
+    <constant>MEDIA_PAD_FL_SOURCE</constant> must be set for every pad.</para>
+  </refsect1>
+
+  <refsect1>
+    &return-value;
+
+    <variablelist>
+      <varlistentry>
+	<term><errorcode>EINVAL</errorcode></term>
+	<listitem>
+	  <para>The &media-links-enum; <structfield>id</structfield> references
+	  a non-existing entity.</para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+</refentry>

Documentation/DocBook/v4l/media-ioc-setup-link.xml

@@ -0,0 +1,93 @@
+<refentry id="media-ioc-setup-link">
+  <refmeta>
+    <refentrytitle>ioctl MEDIA_IOC_SETUP_LINK</refentrytitle>
+    &manvol;
+  </refmeta>
+
+  <refnamediv>
+    <refname>MEDIA_IOC_SETUP_LINK</refname>
+    <refpurpose>Modify the properties of a link</refpurpose>
+  </refnamediv>
+
+  <refsynopsisdiv>
+    <funcsynopsis>
+      <funcprototype>
+	<funcdef>int <function>ioctl</function></funcdef>
+	<paramdef>int <parameter>fd</parameter></paramdef>
+	<paramdef>int <parameter>request</parameter></paramdef>
+	<paramdef>struct media_link_desc *<parameter>argp</parameter></paramdef>
+      </funcprototype>
+    </funcsynopsis>
+  </refsynopsisdiv>
+
+  <refsect1>
+    <title>Arguments</title>
+
+    <variablelist>
+      <varlistentry>
+	<term><parameter>fd</parameter></term>
+	<listitem>
+	  <para>File descriptor returned by
+	  <link linkend='media-func-open'><function>open()</function></link>.</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>request</parameter></term>
+	<listitem>
+	  <para>MEDIA_IOC_ENUM_LINKS</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>argp</parameter></term>
+	<listitem>
+	  <para></para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+
+  <refsect1>
+    <title>Description</title>
+
+    <para>To change link properties applications fill a &media-link-desc; with
+    link identification information (source and sink pad) and the new requested
+    link flags. They then call the MEDIA_IOC_SETUP_LINK ioctl with a pointer to
+    that structure.</para>
+    <para>The only configurable property is the <constant>ENABLED</constant>
+    link flag to enable/disable a link. Links marked with the
+    <constant>IMMUTABLE</constant> link flag can not be enabled or disabled.
+    </para>
+    <para>Link configuration has no side effect on other links. If an enabled
+    link at the sink pad prevents the link from being enabled, the driver
+    returns with an &EBUSY;.</para>
+    <para>Only links marked with the <constant>DYNAMIC</constant> link flag can
+    be enabled/disabled while streaming media data. Attempting to enable or
+    disable a streaming non-dynamic link will return an &EBUSY;.</para>
+    <para>If the specified link can't be found the driver returns with an
+    &EINVAL;.</para>
+  </refsect1>
+
+  <refsect1>
+    &return-value;
+
+    <variablelist>
+      <varlistentry>
+	<term><errorcode>EBUSY</errorcode></term>
+	<listitem>
+	  <para>The link properties can't be changed because the link is
+	  currently busy. This can be caused, for instance, by an active media
+	  stream (audio or video) on the link. The ioctl shouldn't be retried if
+	  no other action is performed before to fix the problem.</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><errorcode>EINVAL</errorcode></term>
+	<listitem>
+	  <para>The &media-link-desc; references a non-existing link, or the
+	  link is immutable and an attempt to modify its configuration was made.
+	  </para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+</refentry>

Documentation/DocBook/v4l/pixfmt-nv12m.xml

@@ -0,0 +1,154 @@
+    <refentry id="V4L2-PIX-FMT-NV12M">
+      <refmeta>
+	<refentrytitle>V4L2_PIX_FMT_NV12M ('NV12M')</refentrytitle>
+	&manvol;
+      </refmeta>
+      <refnamediv>
+	<refname> <constant>V4L2_PIX_FMT_NV12M</constant></refname>
+	<refpurpose>Variation of <constant>V4L2_PIX_FMT_NV12</constant> with planes
+	  non contiguous in memory. </refpurpose>
+      </refnamediv>
+      <refsect1>
+	<title>Description</title>
+
+	<para>This is a multi-planar, two-plane version of the YUV 4:2:0 format.
+The three components are separated into two sub-images or planes.
+<constant>V4L2_PIX_FMT_NV12M</constant> differs from <constant>V4L2_PIX_FMT_NV12
+</constant> in that the two planes are non-contiguous in memory, i.e. the chroma
+plane do not necessarily immediately follows the luma plane.
+The luminance data occupies the first plane. The Y plane has one byte per pixel.
+In the second plane there is a chrominance data with alternating chroma samples.
+The CbCr plane is the same width, in bytes, as the Y plane (and of the image),
+but is half as tall in pixels. Each CbCr pair belongs to four pixels. For example,
+Cb<subscript>0</subscript>/Cr<subscript>0</subscript> belongs to
+Y'<subscript>00</subscript>, Y'<subscript>01</subscript>,
+Y'<subscript>10</subscript>, Y'<subscript>11</subscript>. </para>
+
+	<para><constant>V4L2_PIX_FMT_NV12M</constant> is intended to be
+used only in drivers and applications that support the multi-planar API,
+described in <xref linkend="planar-apis"/>. </para>
+
+	<para>If the Y plane has pad bytes after each row, then the
+CbCr plane has as many pad bytes after its rows.</para>
+
+	<example>
+	  <title><constant>V4L2_PIX_FMT_NV12M</constant> 4 &times; 4 pixel image</title>
+
+	  <formalpara>
+	    <title>Byte Order.</title>
+	    <para>Each cell is one byte.
+		<informaltable frame="none">
+		<tgroup cols="5" align="center">
+		  <colspec align="left" colwidth="2*" />
+		  <tbody valign="top">
+		    <row>
+		      <entry>start0&nbsp;+&nbsp;0:</entry>
+		      <entry>Y'<subscript>00</subscript></entry>
+		      <entry>Y'<subscript>01</subscript></entry>
+		      <entry>Y'<subscript>02</subscript></entry>
+		      <entry>Y'<subscript>03</subscript></entry>
+		    </row>
+		    <row>
+		      <entry>start0&nbsp;+&nbsp;4:</entry>
+		      <entry>Y'<subscript>10</subscript></entry>
+		      <entry>Y'<subscript>11</subscript></entry>
+		      <entry>Y'<subscript>12</subscript></entry>
+		      <entry>Y'<subscript>13</subscript></entry>
+		    </row>
+		    <row>
+		      <entry>start0&nbsp;+&nbsp;8:</entry>
+		      <entry>Y'<subscript>20</subscript></entry>
+		      <entry>Y'<subscript>21</subscript></entry>
+		      <entry>Y'<subscript>22</subscript></entry>
+		      <entry>Y'<subscript>23</subscript></entry>
+		    </row>
+		    <row>
+		      <entry>start0&nbsp;+&nbsp;12:</entry>
+		      <entry>Y'<subscript>30</subscript></entry>
+		      <entry>Y'<subscript>31</subscript></entry>
+		      <entry>Y'<subscript>32</subscript></entry>
+		      <entry>Y'<subscript>33</subscript></entry>
+		    </row>
+		    <row>
+		      <entry></entry>
+		    </row>
+		    <row>
+		      <entry>start1&nbsp;+&nbsp;0:</entry>
+		      <entry>Cb<subscript>00</subscript></entry>
+		      <entry>Cr<subscript>00</subscript></entry>
+		      <entry>Cb<subscript>01</subscript></entry>
+		      <entry>Cr<subscript>01</subscript></entry>
+		    </row>
+		    <row>
+		      <entry>start1&nbsp;+&nbsp;4:</entry>
+		      <entry>Cb<subscript>10</subscript></entry>
+		      <entry>Cr<subscript>10</subscript></entry>
+		      <entry>Cb<subscript>11</subscript></entry>
+		      <entry>Cr<subscript>11</subscript></entry>
+		    </row>
+		  </tbody>
+		</tgroup>
+		</informaltable>
+	      </para>
+	  </formalpara>
+
+	  <formalpara>
+	    <title>Color Sample Location.</title>
+	    <para>
+		<informaltable frame="none">
+		<tgroup cols="7" align="center">
+		  <tbody valign="top">
+		    <row>
+		      <entry></entry>
+		      <entry>0</entry><entry></entry><entry>1</entry><entry></entry>
+		      <entry>2</entry><entry></entry><entry>3</entry>
+		    </row>
+		    <row>
+		      <entry>0</entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry><entry></entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry>
+		    </row>
+		    <row>
+		      <entry></entry>
+		      <entry></entry><entry>C</entry><entry></entry><entry></entry>
+		      <entry></entry><entry>C</entry><entry></entry>
+		    </row>
+		    <row>
+		      <entry>1</entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry><entry></entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry>
+		    </row>
+		    <row>
+		      <entry></entry>
+		    </row>
+		    <row>
+		      <entry>2</entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry><entry></entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry>
+		    </row>
+		    <row>
+		      <entry></entry>
+		      <entry></entry><entry>C</entry><entry></entry><entry></entry>
+		      <entry></entry><entry>C</entry><entry></entry>
+		    </row>
+		    <row>
+		      <entry>3</entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry><entry></entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry>
+		    </row>
+		  </tbody>
+		</tgroup>
+		</informaltable>
+	      </para>
+	  </formalpara>
+	</example>
+      </refsect1>
+    </refentry>
+
+  <!--
+Local Variables:
+mode: sgml
+sgml-parent-document: "pixfmt.sgml"
+indent-tabs-mode: nil
+End:
+  -->

Documentation/DocBook/v4l/pixfmt-nv12mt.xml

@@ -0,0 +1,74 @@
+    <refentry>
+      <refmeta>
+	<refentrytitle>V4L2_PIX_FMT_NV12MT ('TM12')</refentrytitle>
+	&manvol;
+      </refmeta>
+      <refnamediv>
+	<refname id="V4L2-PIX-FMT-NV12MT"><constant>V4L2_PIX_FMT_NV12MT
+</constant></refname>
+	<refpurpose>Formats with &frac12; horizontal and vertical
+chroma resolution. This format has two planes - one for luminance and one for
+chrominance. Chroma samples are interleaved. The difference to
+<constant>V4L2_PIX_FMT_NV12</constant> is the memory layout. Pixels are
+grouped in macroblocks of 64x32 size. The order of macroblocks in memory is
+also not standard.
+	</refpurpose>
+      </refnamediv>
+      <refsect1>
+	<title>Description</title>
+
+	<para>This is the two-plane versions of the YUV 4:2:0 format where data
+is grouped into 64x32 macroblocks. The three components are separated into two
+sub-images or planes. The Y plane has one byte per pixel and pixels are grouped
+into 64x32 macroblocks. The CbCr plane has the same width, in bytes, as the Y
+plane (and the image), but is half as tall in pixels. The chroma plane is also
+grouped into 64x32 macroblocks.</para>
+	<para>Width of the buffer has to be aligned to the multiple of 128, and
+height alignment is 32. Every four adjactent buffers - two horizontally and two
+vertically are grouped together and are located in memory in Z or flipped Z
+order. </para>
+	<para>Layout of macroblocks in memory is presented in the following
+figure.</para>
+	<para><figure id="nv12mt">
+	    <title><constant>V4L2_PIX_FMT_NV12MT</constant> macroblock Z shape
+memory layout</title>
+	    <mediaobject>
+	      <imageobject>
+		<imagedata fileref="nv12mt.gif" format="GIF" />
+	      </imageobject>
+	    </mediaobject>
+	</figure>
+	The requirement that width is multiple of 128 is implemented because,
+the Z shape cannot be cut in half horizontally. In case the vertical resolution
+of macroblocks is odd then the last row of macroblocks is arranged in a linear
+order.  </para>
+	<para>In case of chroma the layout is identical. Cb and Cr samples are
+interleaved. Height of the buffer is aligned to 32.
+	</para>
+	<example>
+	  <title>Memory layout of macroblocks in <constant>V4L2_PIX_FMT_NV12
+</constant> format pixel image - extreme case</title>
+	<para>
+	<figure id="nv12mt_ex">
+	    <title>Example <constant>V4L2_PIX_FMT_NV12MT</constant> memory
+layout of macroblocks</title>
+	    <mediaobject>
+	      <imageobject>
+		<imagedata fileref="nv12mt_example.gif" format="GIF" />
+	      </imageobject>
+	    </mediaobject>
+	</figure>
+	Memory layout of macroblocks of <constant>V4L2_PIX_FMT_NV12MT
+</constant> format in most extreme case.
+	</para>
+	</example>
+      </refsect1>
+    </refentry>
+
+  <!--
+Local Variables:
+mode: sgml
+sgml-parent-document: "pixfmt.sgml"
+indent-tabs-mode: nil
+End:
+  -->

Documentation/DocBook/v4l/pixfmt-srggb12.xml

@@ -0,0 +1,90 @@
+    <refentry>
+      <refmeta>
+	<refentrytitle>V4L2_PIX_FMT_SRGGB12 ('RG12'),
+	 V4L2_PIX_FMT_SGRBG12 ('BA12'),
+	 V4L2_PIX_FMT_SGBRG12 ('GB12'),
+	 V4L2_PIX_FMT_SBGGR12 ('BG12'),
+	 </refentrytitle>
+	&manvol;
+      </refmeta>
+      <refnamediv>
+	<refname id="V4L2-PIX-FMT-SRGGB12"><constant>V4L2_PIX_FMT_SRGGB12</constant></refname>
+	<refname id="V4L2-PIX-FMT-SGRBG12"><constant>V4L2_PIX_FMT_SGRBG12</constant></refname>
+	<refname id="V4L2-PIX-FMT-SGBRG12"><constant>V4L2_PIX_FMT_SGBRG12</constant></refname>
+	<refname id="V4L2-PIX-FMT-SBGGR12"><constant>V4L2_PIX_FMT_SBGGR12</constant></refname>
+	<refpurpose>12-bit Bayer formats expanded to 16 bits</refpurpose>
+      </refnamediv>
+      <refsect1>
+	<title>Description</title>
+
+	<para>The following four pixel formats are raw sRGB / Bayer formats with
+12 bits per colour. Each colour component is stored in a 16-bit word, with 6
+unused high bits filled with zeros. Each n-pixel row contains n/2 green samples
+and n/2 blue or red samples, with alternating red and blue rows. Bytes are
+stored in memory in little endian order. They are conventionally described
+as GRGR... BGBG..., RGRG... GBGB..., etc. Below is an example of one of these
+formats</para>
+
+    <example>
+      <title><constant>V4L2_PIX_FMT_SBGGR12</constant> 4 &times; 4
+pixel image</title>
+
+      <formalpara>
+	<title>Byte Order.</title>
+	<para>Each cell is one byte, high 6 bits in high bytes are 0.
+	  <informaltable frame="none">
+	    <tgroup cols="5" align="center">
+	      <colspec align="left" colwidth="2*" />
+	      <tbody valign="top">
+		<row>
+		  <entry>start&nbsp;+&nbsp;0:</entry>
+		  <entry>B<subscript>00low</subscript></entry>
+		  <entry>B<subscript>00high</subscript></entry>
+		  <entry>G<subscript>01low</subscript></entry>
+		  <entry>G<subscript>01high</subscript></entry>
+		  <entry>B<subscript>02low</subscript></entry>
+		  <entry>B<subscript>02high</subscript></entry>
+		  <entry>G<subscript>03low</subscript></entry>
+		  <entry>G<subscript>03high</subscript></entry>
+		</row>
+		<row>
+		  <entry>start&nbsp;+&nbsp;8:</entry>
+		  <entry>G<subscript>10low</subscript></entry>
+		  <entry>G<subscript>10high</subscript></entry>
+		  <entry>R<subscript>11low</subscript></entry>
+		  <entry>R<subscript>11high</subscript></entry>
+		  <entry>G<subscript>12low</subscript></entry>
+		  <entry>G<subscript>12high</subscript></entry>
+		  <entry>R<subscript>13low</subscript></entry>
+		  <entry>R<subscript>13high</subscript></entry>
+		</row>
+		<row>
+		  <entry>start&nbsp;+&nbsp;16:</entry>
+		  <entry>B<subscript>20low</subscript></entry>
+		  <entry>B<subscript>20high</subscript></entry>
+		  <entry>G<subscript>21low</subscript></entry>
+		  <entry>G<subscript>21high</subscript></entry>
+		  <entry>B<subscript>22low</subscript></entry>
+		  <entry>B<subscript>22high</subscript></entry>
+		  <entry>G<subscript>23low</subscript></entry>
+		  <entry>G<subscript>23high</subscript></entry>
+		</row>
+		<row>
+		  <entry>start&nbsp;+&nbsp;24:</entry>
+		  <entry>G<subscript>30low</subscript></entry>
+		  <entry>G<subscript>30high</subscript></entry>
+		  <entry>R<subscript>31low</subscript></entry>
+		  <entry>R<subscript>31high</subscript></entry>
+		  <entry>G<subscript>32low</subscript></entry>
+		  <entry>G<subscript>32high</subscript></entry>
+		  <entry>R<subscript>33low</subscript></entry>
+		  <entry>R<subscript>33high</subscript></entry>
+		</row>
+	      </tbody>
+	    </tgroup>
+	  </informaltable>
+	</para>
+      </formalpara>
+    </example>
+  </refsect1>
+</refentry>

Documentation/DocBook/v4l/pixfmt-yuv420m.xml

@@ -0,0 +1,162 @@
+    <refentry id="V4L2-PIX-FMT-YUV420M">
+      <refmeta>
+	<refentrytitle>V4L2_PIX_FMT_YUV420M ('YU12M')</refentrytitle>
+	&manvol;
+      </refmeta>
+      <refnamediv>
+	<refname> <constant>V4L2_PIX_FMT_YUV420M</constant></refname>
+	<refpurpose>Variation of <constant>V4L2_PIX_FMT_YUV420</constant>
+	  with planes non contiguous in memory. </refpurpose>
+      </refnamediv>
+
+      <refsect1>
+	<title>Description</title>
+
+	<para>This is a multi-planar format, as opposed to a packed format.
+The three components are separated into three sub- images or planes.
+
+The Y plane is first. The Y plane has one byte per pixel. The Cb data
+constitutes the second plane which is half the width and half
+the height of the Y plane (and of the image). Each Cb belongs to four
+pixels, a two-by-two square of the image. For example,
+Cb<subscript>0</subscript> belongs to Y'<subscript>00</subscript>,
+Y'<subscript>01</subscript>, Y'<subscript>10</subscript>, and
+Y'<subscript>11</subscript>. The Cr data, just like the Cb plane, is
+in the third plane. </para>
+
+	<para>If the Y plane has pad bytes after each row, then the Cb
+and Cr planes have half as many pad bytes after their rows. In other
+words, two Cx rows (including padding) is exactly as long as one Y row
+(including padding).</para>
+
+	<para><constant>V4L2_PIX_FMT_NV12M</constant> is intended to be
+used only in drivers and applications that support the multi-planar API,
+described in <xref linkend="planar-apis"/>. </para>
+
+	<example>
+	  <title><constant>V4L2_PIX_FMT_YVU420M</constant> 4 &times; 4
+pixel image</title>
+
+	  <formalpara>
+	    <title>Byte Order.</title>
+	    <para>Each cell is one byte.
+		<informaltable frame="none">
+		<tgroup cols="5" align="center">
+		  <colspec align="left" colwidth="2*" />
+		  <tbody valign="top">
+		    <row>
+		      <entry>start0&nbsp;+&nbsp;0:</entry>
+		      <entry>Y'<subscript>00</subscript></entry>
+		      <entry>Y'<subscript>01</subscript></entry>
+		      <entry>Y'<subscript>02</subscript></entry>
+		      <entry>Y'<subscript>03</subscript></entry>
+		    </row>
+		    <row>
+		      <entry>start0&nbsp;+&nbsp;4:</entry>
+		      <entry>Y'<subscript>10</subscript></entry>
+		      <entry>Y'<subscript>11</subscript></entry>
+		      <entry>Y'<subscript>12</subscript></entry>
+		      <entry>Y'<subscript>13</subscript></entry>
+		    </row>
+		    <row>
+		      <entry>start0&nbsp;+&nbsp;8:</entry>
+		      <entry>Y'<subscript>20</subscript></entry>
+		      <entry>Y'<subscript>21</subscript></entry>
+		      <entry>Y'<subscript>22</subscript></entry>
+		      <entry>Y'<subscript>23</subscript></entry>
+		    </row>
+		    <row>
+		      <entry>start0&nbsp;+&nbsp;12:</entry>
+		      <entry>Y'<subscript>30</subscript></entry>
+		      <entry>Y'<subscript>31</subscript></entry>
+		      <entry>Y'<subscript>32</subscript></entry>
+		      <entry>Y'<subscript>33</subscript></entry>
+		    </row>
+		    <row><entry></entry></row>
+		    <row>
+		      <entry>start1&nbsp;+&nbsp;0:</entry>
+		      <entry>Cb<subscript>00</subscript></entry>
+		      <entry>Cb<subscript>01</subscript></entry>
+		    </row>
+		    <row>
+		      <entry>start1&nbsp;+&nbsp;2:</entry>
+		      <entry>Cb<subscript>10</subscript></entry>
+		      <entry>Cb<subscript>11</subscript></entry>
+		    </row>
+		    <row><entry></entry></row>
+		    <row>
+		      <entry>start2&nbsp;+&nbsp;0:</entry>
+		      <entry>Cr<subscript>00</subscript></entry>
+		      <entry>Cr<subscript>01</subscript></entry>
+		    </row>
+		    <row>
+		      <entry>start2&nbsp;+&nbsp;2:</entry>
+		      <entry>Cr<subscript>10</subscript></entry>
+		      <entry>Cr<subscript>11</subscript></entry>
+		    </row>
+		  </tbody>
+		</tgroup>
+		</informaltable>
+	      </para>
+	  </formalpara>
+
+	  <formalpara>
+	    <title>Color Sample Location.</title>
+	    <para>
+		<informaltable frame="none">
+		<tgroup cols="7" align="center">
+		  <tbody valign="top">
+		    <row>
+		      <entry></entry>
+		      <entry>0</entry><entry></entry><entry>1</entry><entry></entry>
+		      <entry>2</entry><entry></entry><entry>3</entry>
+		    </row>
+		    <row>
+		      <entry>0</entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry><entry></entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry>
+		    </row>
+		    <row>
+		      <entry></entry>
+		      <entry></entry><entry>C</entry><entry></entry><entry></entry>
+		      <entry></entry><entry>C</entry><entry></entry>
+		    </row>
+		    <row>
+		      <entry>1</entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry><entry></entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry>
+		    </row>
+		    <row>
+		      <entry></entry>
+		    </row>
+		    <row>
+		      <entry>2</entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry><entry></entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry>
+		    </row>
+		    <row>
+		      <entry></entry>
+		      <entry></entry><entry>C</entry><entry></entry><entry></entry>
+		      <entry></entry><entry>C</entry><entry></entry>
+		    </row>
+		    <row>
+		      <entry>3</entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry><entry></entry>
+		      <entry>Y</entry><entry></entry><entry>Y</entry>
+		    </row>
+		  </tbody>
+		</tgroup>
+		</informaltable>
+	      </para>
+	  </formalpara>
+	</example>
+      </refsect1>
+    </refentry>
+
+  <!--
+Local Variables:
+mode: sgml
+sgml-parent-document: "pixfmt.sgml"
+indent-tabs-mode: nil
+End:
+  -->

Documentation/DocBook/v4l/pixfmt.xml

@@ -2,12 +2,16 @@

   <para>The V4L2 API was primarily designed for devices exchanging
 image data with applications. The
-<structname>v4l2_pix_format</structname> structure defines the format
-and layout of an image in memory. Image formats are negotiated with
-the &VIDIOC-S-FMT; ioctl. (The explanations here focus on video
+<structname>v4l2_pix_format</structname> and <structname>v4l2_pix_format_mplane
+</structname> structures define the format and layout of an image in memory.
+The former is used with the single-planar API, while the latter is used with the
+multi-planar version (see <xref linkend="planar-apis"/>). Image formats are
+negotiated with the &VIDIOC-S-FMT; ioctl. (The explanations here focus on video
 capturing and output, for overlay frame buffer formats see also
 &VIDIOC-G-FBUF;.)</para>

+<section>
+  <title>Single-planar format structure</title>
   <table pgwide="1" frame="none" id="v4l2-pix-format">
     <title>struct <structname>v4l2_pix_format</structname></title>
     <tgroup cols="3">
@@ -106,6 +110,98 @@ set this field to zero.</entry>
       </tbody>
     </tgroup>
   </table>
+</section>
+
+<section>
+  <title>Multi-planar format structures</title>
+  <para>The <structname>v4l2_plane_pix_format</structname> structures define
+    size and layout for each of the planes in a multi-planar format.
+    The <structname>v4l2_pix_format_mplane</structname> structure contains
+    information common to all planes (such as image width and height) and
+    an array of <structname>v4l2_plane_pix_format</structname> structures,
+    describing all planes of that format.</para>
+  <table pgwide="1" frame="none" id="v4l2-plane-pix-format">
+    <title>struct <structname>vl42_plane_pix_format</structname></title>
+    <tgroup cols="3">
+      &cs-str;
+      <tbody valign="top">
+        <row>
+          <entry>__u32</entry>
+          <entry><structfield>sizeimage</structfield></entry>
+          <entry>Maximum size in bytes required for image data in this plane.
+          </entry>
+        </row>
+        <row>
+          <entry>__u16</entry>
+          <entry><structfield>bytesperline</structfield></entry>
+          <entry>Distance in bytes between the leftmost pixels in two adjacent
+            lines.</entry>
+        </row>
+        <row>
+          <entry>__u16</entry>
+          <entry><structfield>reserved[7]</structfield></entry>
+          <entry>Reserved for future extensions. Should be zeroed by the
+           application.</entry>
+        </row>
+      </tbody>
+    </tgroup>
+  </table>
+  <table pgwide="1" frame="none" id="v4l2-pix-format-mplane">
+    <title>struct <structname>v4l2_pix_format_mplane</structname></title>
+    <tgroup cols="3">
+      &cs-str;
+      <tbody valign="top">
+        <row>
+          <entry>__u32</entry>
+          <entry><structfield>width</structfield></entry>
+          <entry>Image width in pixels.</entry>
+        </row>
+        <row>
+          <entry>__u32</entry>
+          <entry><structfield>height</structfield></entry>
+          <entry>Image height in pixels.</entry>
+        </row>
+        <row>
+          <entry>__u32</entry>
+          <entry><structfield>pixelformat</structfield></entry>
+          <entry>The pixel format. Both single- and multi-planar four character
+codes can be used.</entry>
+        </row>
+        <row>
+          <entry>&v4l2-field;</entry>
+          <entry><structfield>field</structfield></entry>
+          <entry>See &v4l2-pix-format;.</entry>
+        </row>
+        <row>
+          <entry>&v4l2-colorspace;</entry>
+          <entry><structfield>colorspace</structfield></entry>
+          <entry>See &v4l2-pix-format;.</entry>
+        </row>
+        <row>
+          <entry>&v4l2-plane-pix-format;</entry>
+          <entry><structfield>plane_fmt[VIDEO_MAX_PLANES]</structfield></entry>
+          <entry>An array of structures describing format of each plane this
+          pixel format consists of. The number of valid entries in this array
+          has to be put in the <structfield>num_planes</structfield>
+          field.</entry>
+        </row>
+        <row>
+          <entry>__u8</entry>
+          <entry><structfield>num_planes</structfield></entry>
+          <entry>Number of planes (i.e. separate memory buffers) for this format
+          and the number of valid entries in the
+          <structfield>plane_fmt</structfield> array.</entry>
+        </row>
+        <row>
+          <entry>__u8</entry>
+          <entry><structfield>reserved[11]</structfield></entry>
+          <entry>Reserved for future extensions. Should be zeroed by the
+           application.</entry>
+        </row>
+      </tbody>
+    </tgroup>
+  </table>
+</section>

   <section>
     <title>Standard Image Formats</title>
@@ -142,11 +238,19 @@ leftmost pixel of the second row from the top, and so on. The last row
 has just as many pad bytes after it as the other rows.</para>

     <para>In V4L2 each format has an identifier which looks like
-<constant>PIX_FMT_XXX</constant>, defined in the <filename>videodev2.h</filename>
-header file. These identifiers
-represent <link linkend="v4l2-fourcc">four character codes</link>
+<constant>PIX_FMT_XXX</constant>, defined in the <link
+linkend="videodev">videodev.h</link> header file. These identifiers
+represent <link linkend="v4l2-fourcc">four character (FourCC) codes</link>
 which are also listed below, however they are not the same as those
 used in the Windows world.</para>
+
+    <para>For some formats, data is stored in separate, discontiguous
+memory buffers. Those formats are identified by a separate set of FourCC codes
+and are referred to as "multi-planar formats". For example, a YUV422 frame is
+normally stored in one memory buffer, but it can also be placed in two or three
+separate buffers, with Y component in one buffer and CbCr components in another
+in the 2-planar version or with each component in its own buffer in the
+3-planar case. Those sub-buffers are referred to as "planes".</para>
   </section>

   <section id="colorspaces">
@@ -599,10 +703,13 @@ information.</para>
     &sub-vyuy;
     &sub-y41p;
     &sub-yuv420;
+    &sub-yuv420m;
     &sub-yuv410;
     &sub-yuv422p;
     &sub-yuv411p;
     &sub-nv12;
+    &sub-nv12m;
+    &sub-nv12mt;
     &sub-nv16;
   </section>


Documentation/DocBook/v4l/planar-apis.xml

@@ -0,0 +1,62 @@
+<section id="planar-apis">
+  <title>Single- and multi-planar APIs</title>
+
+  <para>Some devices require data for each input or output video frame
+  to be placed in discontiguous memory buffers. In such cases, one
+  video frame has to be addressed using more than one memory address, i.e. one
+  pointer per "plane". A plane is a sub-buffer of the current frame. For
+  examples of such formats see <xref linkend="pixfmt" />.</para>
+
+  <para>Initially, V4L2 API did not support multi-planar buffers and a set of
+  extensions has been introduced to handle them. Those extensions constitute
+  what is being referred to as the "multi-planar API".</para>
+
+  <para>Some of the V4L2 API calls and structures are interpreted differently,
+  depending on whether single- or multi-planar API is being used. An application
+  can choose whether to use one or the other by passing a corresponding buffer
+  type to its ioctl calls. Multi-planar versions of buffer types are suffixed
+  with an `_MPLANE' string. For a list of available multi-planar buffer types
+  see &v4l2-buf-type;.
+  </para>
+
+  <section>
+    <title>Multi-planar formats</title>
+    <para>Multi-planar API introduces new multi-planar formats. Those formats
+    use a separate set of FourCC codes. It is important to distinguish between
+    the multi-planar API and a multi-planar format. Multi-planar API calls can
+    handle all single-planar formats as well (as long as they are passed in
+    multi-planar API structures), while the single-planar API cannot
+    handle multi-planar formats.</para>
+  </section>
+
+  <section>
+    <title>Calls that distinguish between single and multi-planar APIs</title>
+    <variablelist>
+      <varlistentry>
+        <term>&VIDIOC-QUERYCAP;</term>
+        <listitem><para>Two additional multi-planar capabilities are added. They can
+        be set together with non-multi-planar ones for devices that handle
+        both single- and multi-planar formats.</para></listitem>
+      </varlistentry>
+      <varlistentry>
+        <term>&VIDIOC-G-FMT;, &VIDIOC-S-FMT;, &VIDIOC-TRY-FMT;</term>
+        <listitem><para>New structures for describing multi-planar formats are added:
+        &v4l2-pix-format-mplane; and &v4l2-plane-pix-format;. Drivers may
+        define new multi-planar formats, which have distinct FourCC codes from
+        the existing single-planar ones.</para>
+        </listitem>
+      </varlistentry>
+      <varlistentry>
+        <term>&VIDIOC-QBUF;, &VIDIOC-DQBUF;, &VIDIOC-QUERYBUF;</term>
+        <listitem><para>A new &v4l2-plane; structure for describing planes is added.
+        Arrays of this structure are passed in the new
+        <structfield>m.planes</structfield> field of &v4l2-buffer;.</para>
+        </listitem>
+      </varlistentry>
+      <varlistentry>
+        <term>&VIDIOC-REQBUFS;</term>
+        <listitem><para>Will allocate multi-planar buffers as requested.</para></listitem>
+      </varlistentry>
+    </variablelist>
+  </section>
+</section>

Documentation/DocBook/v4l/subdev-formats.xml

@@ -0,0 +1,2467 @@
+<section id="v4l2-mbus-format">
+  <title>Media Bus Formats</title>
+
+  <table pgwide="1" frame="none" id="v4l2-mbus-framefmt">
+    <title>struct <structname>v4l2_mbus_framefmt</structname></title>
+    <tgroup cols="3">
+      &cs-str;
+      <tbody valign="top">
+	<row>
+	  <entry>__u32</entry>
+	  <entry><structfield>width</structfield></entry>
+	  <entry>Image width, in pixels.</entry>
+	</row>
+	<row>
+	  <entry>__u32</entry>
+	  <entry><structfield>height</structfield></entry>
+	  <entry>Image height, in pixels.</entry>
+	</row>
+	<row>
+	  <entry>__u32</entry>
+	  <entry><structfield>code</structfield></entry>
+	  <entry>Format code, from &v4l2-mbus-pixelcode;.</entry>
+	</row>
+	<row>
+	  <entry>__u32</entry>
+	  <entry><structfield>field</structfield></entry>
+	  <entry>Field order, from &v4l2-field;. See
+	  <xref linkend="field-order" /> for details.</entry>
+	</row>
+	<row>
+	  <entry>__u32</entry>
+	  <entry><structfield>colorspace</structfield></entry>
+	  <entry>Image colorspace, from &v4l2-colorspace;. See
+	  <xref linkend="colorspaces" /> for details.</entry>
+	</row>
+	<row>
+	  <entry>__u32</entry>
+	  <entry><structfield>reserved</structfield>[7]</entry>
+	  <entry>Reserved for future extensions. Applications and drivers must
+	  set the array to zero.</entry>
+	</row>
+      </tbody>
+    </tgroup>
+  </table>
+
+  <section id="v4l2-mbus-pixelcode">
+    <title>Media Bus Pixel Codes</title>
+
+    <para>The media bus pixel codes describe image formats as flowing over
+    physical busses (both between separate physical components and inside SoC
+    devices). This should not be confused with the V4L2 pixel formats that
+    describe, using four character codes, image formats as stored in memory.
+    </para>
+
+    <para>While there is a relationship between image formats on busses and
+    image formats in memory (a raw Bayer image won't be magically converted to
+    JPEG just by storing it to memory), there is no one-to-one correspondance
+    between them.</para>
+
+    <section>
+      <title>Packed RGB Formats</title>
+
+      <para>Those formats transfer pixel data as red, green and blue components.
+      The format code is made of the following information.
+      <itemizedlist>
+	<listitem><para>The red, green and blue components order code, as encoded in a
+	pixel sample. Possible values are RGB and BGR.</para></listitem>
+	<listitem><para>The number of bits per component, for each component. The values
+	can be different for all components. Common values are 555 and 565.</para>
+	</listitem>
+	<listitem><para>The number of bus samples per pixel. Pixels that are wider than
+	the bus width must be transferred in multiple samples. Common values are
+	1 and 2.</para></listitem>
+	<listitem><para>The bus width.</para></listitem>
+	<listitem><para>For formats where the total number of bits per pixel is smaller
+	than the number of bus samples per pixel times the bus width, a padding
+	value stating if the bytes are padded in their most high order bits
+	(PADHI) or low order bits (PADLO).</para></listitem>
+	<listitem><para>For formats where the number of bus samples per pixel is larger
+	than 1, an endianness value stating if the pixel is transferred MSB first
+	(BE) or LSB first (LE).</para></listitem>
+      </itemizedlist>
+      </para>
+
+      <para>For instance, a format where pixels are encoded as 5-bits red, 5-bits
+      green and 5-bit blue values padded on the high bit, transferred as 2 8-bit
+      samples per pixel with the most significant bits (padding, red and half of
+      the green value) transferred first will be named
+      <constant>V4L2_MBUS_FMT_RGB555_2X8_PADHI_BE</constant>.
+      </para>
+
+      <para>The following tables list existing packet RGB formats.</para>
+
+      <table pgwide="0" frame="none" id="v4l2-mbus-pixelcode-rgb">
+	<title>RGB formats</title>
+	<tgroup cols="11">
+	  <colspec colname="id" align="left" />
+	  <colspec colname="code" align="center"/>
+	  <colspec colname="bit" />
+	  <colspec colnum="4" colname="b07" align="center" />
+	  <colspec colnum="5" colname="b06" align="center" />
+	  <colspec colnum="6" colname="b05" align="center" />
+	  <colspec colnum="7" colname="b04" align="center" />
+	  <colspec colnum="8" colname="b03" align="center" />
+	  <colspec colnum="9" colname="b02" align="center" />
+	  <colspec colnum="10" colname="b01" align="center" />
+	  <colspec colnum="11" colname="b00" align="center" />
+	  <spanspec namest="b07" nameend="b00" spanname="b0" />
+	  <thead>
+	    <row>
+	      <entry>Identifier</entry>
+	      <entry>Code</entry>
+	      <entry></entry>
+	      <entry spanname="b0">Data organization</entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>Bit</entry>
+	      <entry>7</entry>
+	      <entry>6</entry>
+	      <entry>5</entry>
+	      <entry>4</entry>
+	      <entry>3</entry>
+	      <entry>2</entry>
+	      <entry>1</entry>
+	      <entry>0</entry>
+	    </row>
+	  </thead>
+	  <tbody valign="top">
+	    <row id="V4L2-MBUS-FMT-RGB444-2X8-PADHI-BE">
+	      <entry>V4L2_MBUS_FMT_RGB444_2X8_PADHI_BE</entry>
+	      <entry>0x1001</entry>
+	      <entry></entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>r<subscript>3</subscript></entry>
+	      <entry>r<subscript>2</subscript></entry>
+	      <entry>r<subscript>1</subscript></entry>
+	      <entry>r<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>g<subscript>3</subscript></entry>
+	      <entry>g<subscript>2</subscript></entry>
+	      <entry>g<subscript>1</subscript></entry>
+	      <entry>g<subscript>0</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-RGB444-2X8-PADHI-LE">
+	      <entry>V4L2_MBUS_FMT_RGB444_2X8_PADHI_LE</entry>
+	      <entry>0x1002</entry>
+	      <entry></entry>
+	      <entry>g<subscript>3</subscript></entry>
+	      <entry>g<subscript>2</subscript></entry>
+	      <entry>g<subscript>1</subscript></entry>
+	      <entry>g<subscript>0</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>r<subscript>3</subscript></entry>
+	      <entry>r<subscript>2</subscript></entry>
+	      <entry>r<subscript>1</subscript></entry>
+	      <entry>r<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-RGB555-2X8-PADHI-BE">
+	      <entry>V4L2_MBUS_FMT_RGB555_2X8_PADHI_BE</entry>
+	      <entry>0x1003</entry>
+	      <entry></entry>
+	      <entry>0</entry>
+	      <entry>r<subscript>4</subscript></entry>
+	      <entry>r<subscript>3</subscript></entry>
+	      <entry>r<subscript>2</subscript></entry>
+	      <entry>r<subscript>1</subscript></entry>
+	      <entry>r<subscript>0</subscript></entry>
+	      <entry>g<subscript>4</subscript></entry>
+	      <entry>g<subscript>3</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>g<subscript>2</subscript></entry>
+	      <entry>g<subscript>1</subscript></entry>
+	      <entry>g<subscript>0</subscript></entry>
+	      <entry>b<subscript>4</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-RGB555-2X8-PADHI-LE">
+	      <entry>V4L2_MBUS_FMT_RGB555_2X8_PADHI_LE</entry>
+	      <entry>0x1004</entry>
+	      <entry></entry>
+	      <entry>g<subscript>2</subscript></entry>
+	      <entry>g<subscript>1</subscript></entry>
+	      <entry>g<subscript>0</subscript></entry>
+	      <entry>b<subscript>4</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>0</entry>
+	      <entry>r<subscript>4</subscript></entry>
+	      <entry>r<subscript>3</subscript></entry>
+	      <entry>r<subscript>2</subscript></entry>
+	      <entry>r<subscript>1</subscript></entry>
+	      <entry>r<subscript>0</subscript></entry>
+	      <entry>g<subscript>4</subscript></entry>
+	      <entry>g<subscript>3</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-BGR565-2X8-BE">
+	      <entry>V4L2_MBUS_FMT_BGR565_2X8_BE</entry>
+	      <entry>0x1005</entry>
+	      <entry></entry>
+	      <entry>b<subscript>4</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	      <entry>g<subscript>5</subscript></entry>
+	      <entry>g<subscript>4</subscript></entry>
+	      <entry>g<subscript>3</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>g<subscript>2</subscript></entry>
+	      <entry>g<subscript>1</subscript></entry>
+	      <entry>g<subscript>0</subscript></entry>
+	      <entry>r<subscript>4</subscript></entry>
+	      <entry>r<subscript>3</subscript></entry>
+	      <entry>r<subscript>2</subscript></entry>
+	      <entry>r<subscript>1</subscript></entry>
+	      <entry>r<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-BGR565-2X8-LE">
+	      <entry>V4L2_MBUS_FMT_BGR565_2X8_LE</entry>
+	      <entry>0x1006</entry>
+	      <entry></entry>
+	      <entry>g<subscript>2</subscript></entry>
+	      <entry>g<subscript>1</subscript></entry>
+	      <entry>g<subscript>0</subscript></entry>
+	      <entry>r<subscript>4</subscript></entry>
+	      <entry>r<subscript>3</subscript></entry>
+	      <entry>r<subscript>2</subscript></entry>
+	      <entry>r<subscript>1</subscript></entry>
+	      <entry>r<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>b<subscript>4</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	      <entry>g<subscript>5</subscript></entry>
+	      <entry>g<subscript>4</subscript></entry>
+	      <entry>g<subscript>3</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-RGB565-2X8-BE">
+	      <entry>V4L2_MBUS_FMT_RGB565_2X8_BE</entry>
+	      <entry>0x1007</entry>
+	      <entry></entry>
+	      <entry>r<subscript>4</subscript></entry>
+	      <entry>r<subscript>3</subscript></entry>
+	      <entry>r<subscript>2</subscript></entry>
+	      <entry>r<subscript>1</subscript></entry>
+	      <entry>r<subscript>0</subscript></entry>
+	      <entry>g<subscript>5</subscript></entry>
+	      <entry>g<subscript>4</subscript></entry>
+	      <entry>g<subscript>3</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>g<subscript>2</subscript></entry>
+	      <entry>g<subscript>1</subscript></entry>
+	      <entry>g<subscript>0</subscript></entry>
+	      <entry>b<subscript>4</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-RGB565-2X8-LE">
+	      <entry>V4L2_MBUS_FMT_RGB565_2X8_LE</entry>
+	      <entry>0x1008</entry>
+	      <entry></entry>
+	      <entry>g<subscript>2</subscript></entry>
+	      <entry>g<subscript>1</subscript></entry>
+	      <entry>g<subscript>0</subscript></entry>
+	      <entry>b<subscript>4</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>r<subscript>4</subscript></entry>
+	      <entry>r<subscript>3</subscript></entry>
+	      <entry>r<subscript>2</subscript></entry>
+	      <entry>r<subscript>1</subscript></entry>
+	      <entry>r<subscript>0</subscript></entry>
+	      <entry>g<subscript>5</subscript></entry>
+	      <entry>g<subscript>4</subscript></entry>
+	      <entry>g<subscript>3</subscript></entry>
+	    </row>
+	  </tbody>
+	</tgroup>
+      </table>
+    </section>
+
+    <section>
+      <title>Bayer Formats</title>
+
+      <para>Those formats transfer pixel data as red, green and blue components.
+      The format code is made of the following information.
+      <itemizedlist>
+	<listitem><para>The red, green and blue components order code, as encoded in a
+	pixel sample. The possible values are shown in <xref
+	linkend="bayer-patterns" />.</para></listitem>
+	<listitem><para>The number of bits per pixel component. All components are
+	transferred on the same number of bits. Common values are 8, 10 and 12.</para>
+	</listitem>
+	<listitem><para>If the pixel components are DPCM-compressed, a mention of the
+	DPCM compression and the number of bits per compressed pixel component.</para>
+	</listitem>
+	<listitem><para>The number of bus samples per pixel. Pixels that are wider than
+	the bus width must be transferred in multiple samples. Common values are
+	1 and 2.</para></listitem>
+	<listitem><para>The bus width.</para></listitem>
+	<listitem><para>For formats where the total number of bits per pixel is smaller
+	than the number of bus samples per pixel times the bus width, a padding
+	value stating if the bytes are padded in their most high order bits
+	(PADHI) or low order bits (PADLO).</para></listitem>
+	<listitem><para>For formats where the number of bus samples per pixel is larger
+	than 1, an endianness value stating if the pixel is transferred MSB first
+	(BE) or LSB first (LE).</para></listitem>
+      </itemizedlist>
+      </para>
+
+      <para>For instance, a format with uncompressed 10-bit Bayer components
+      arranged in a red, green, green, blue pattern transferred as 2 8-bit
+      samples per pixel with the least significant bits transferred first will
+      be named <constant>V4L2_MBUS_FMT_SRGGB10_2X8_PADHI_LE</constant>.
+      </para>
+
+      <figure id="bayer-patterns">
+	<title>Bayer Patterns</title>
+	<mediaobject>
+	  <imageobject>
+	    <imagedata fileref="bayer.pdf" format="PS" />
+	  </imageobject>
+	  <imageobject>
+	    <imagedata fileref="bayer.png" format="PNG" />
+	  </imageobject>
+	  <textobject>
+	    <phrase>Bayer filter color patterns</phrase>
+	  </textobject>
+	</mediaobject>
+      </figure>
+
+      <para>The following table lists existing packet Bayer formats. The data
+      organization is given as an example for the first pixel only.</para>
+
+      <table pgwide="0" frame="none" id="v4l2-mbus-pixelcode-bayer">
+	<title>Bayer Formats</title>
+	<tgroup cols="15">
+	  <colspec colname="id" align="left" />
+	  <colspec colname="code" align="center"/>
+	  <colspec colname="bit" />
+	  <colspec colnum="4" colname="b11" align="center" />
+	  <colspec colnum="5" colname="b10" align="center" />
+	  <colspec colnum="6" colname="b09" align="center" />
+	  <colspec colnum="7" colname="b08" align="center" />
+	  <colspec colnum="8" colname="b07" align="center" />
+	  <colspec colnum="9" colname="b06" align="center" />
+	  <colspec colnum="10" colname="b05" align="center" />
+	  <colspec colnum="11" colname="b04" align="center" />
+	  <colspec colnum="12" colname="b03" align="center" />
+	  <colspec colnum="13" colname="b02" align="center" />
+	  <colspec colnum="14" colname="b01" align="center" />
+	  <colspec colnum="15" colname="b00" align="center" />
+	  <spanspec namest="b11" nameend="b00" spanname="b0" />
+	  <thead>
+	    <row>
+	      <entry>Identifier</entry>
+	      <entry>Code</entry>
+	      <entry></entry>
+	      <entry spanname="b0">Data organization</entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>Bit</entry>
+	      <entry>11</entry>
+	      <entry>10</entry>
+	      <entry>9</entry>
+	      <entry>8</entry>
+	      <entry>7</entry>
+	      <entry>6</entry>
+	      <entry>5</entry>
+	      <entry>4</entry>
+	      <entry>3</entry>
+	      <entry>2</entry>
+	      <entry>1</entry>
+	      <entry>0</entry>
+	    </row>
+	  </thead>
+	  <tbody valign="top">
+	    <row id="V4L2-MBUS-FMT-SBGGR8-1X8">
+	      <entry>V4L2_MBUS_FMT_SBGGR8_1X8</entry>
+	      <entry>0x3001</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>b<subscript>7</subscript></entry>
+	      <entry>b<subscript>6</subscript></entry>
+	      <entry>b<subscript>5</subscript></entry>
+	      <entry>b<subscript>4</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SGRBG8-1X8">
+	      <entry>V4L2_MBUS_FMT_SGRBG8_1X8</entry>
+	      <entry>0x3002</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>g<subscript>7</subscript></entry>
+	      <entry>g<subscript>6</subscript></entry>
+	      <entry>g<subscript>5</subscript></entry>
+	      <entry>g<subscript>4</subscript></entry>
+	      <entry>g<subscript>3</subscript></entry>
+	      <entry>g<subscript>2</subscript></entry>
+	      <entry>g<subscript>1</subscript></entry>
+	      <entry>g<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SBGGR10-DPCM8-1X8">
+	      <entry>V4L2_MBUS_FMT_SBGGR10_DPCM8_1X8</entry>
+	      <entry>0x300b</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>b<subscript>7</subscript></entry>
+	      <entry>b<subscript>6</subscript></entry>
+	      <entry>b<subscript>5</subscript></entry>
+	      <entry>b<subscript>4</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SGBRG10-DPCM8-1X8">
+	      <entry>V4L2_MBUS_FMT_SGBRG10_DPCM8_1X8</entry>
+	      <entry>0x300c</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>g<subscript>7</subscript></entry>
+	      <entry>g<subscript>6</subscript></entry>
+	      <entry>g<subscript>5</subscript></entry>
+	      <entry>g<subscript>4</subscript></entry>
+	      <entry>g<subscript>3</subscript></entry>
+	      <entry>g<subscript>2</subscript></entry>
+	      <entry>g<subscript>1</subscript></entry>
+	      <entry>g<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SGRBG10-DPCM8-1X8">
+	      <entry>V4L2_MBUS_FMT_SGRBG10_DPCM8_1X8</entry>
+	      <entry>0x3009</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>g<subscript>7</subscript></entry>
+	      <entry>g<subscript>6</subscript></entry>
+	      <entry>g<subscript>5</subscript></entry>
+	      <entry>g<subscript>4</subscript></entry>
+	      <entry>g<subscript>3</subscript></entry>
+	      <entry>g<subscript>2</subscript></entry>
+	      <entry>g<subscript>1</subscript></entry>
+	      <entry>g<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SRGGB10-DPCM8-1X8">
+	      <entry>V4L2_MBUS_FMT_SRGGB10_DPCM8_1X8</entry>
+	      <entry>0x300d</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>r<subscript>7</subscript></entry>
+	      <entry>r<subscript>6</subscript></entry>
+	      <entry>r<subscript>5</subscript></entry>
+	      <entry>r<subscript>4</subscript></entry>
+	      <entry>r<subscript>3</subscript></entry>
+	      <entry>r<subscript>2</subscript></entry>
+	      <entry>r<subscript>1</subscript></entry>
+	      <entry>r<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SBGGR10-2X8-PADHI-BE">
+	      <entry>V4L2_MBUS_FMT_SBGGR10_2X8_PADHI_BE</entry>
+	      <entry>0x3003</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>b<subscript>9</subscript></entry>
+	      <entry>b<subscript>8</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>b<subscript>7</subscript></entry>
+	      <entry>b<subscript>6</subscript></entry>
+	      <entry>b<subscript>5</subscript></entry>
+	      <entry>b<subscript>4</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SBGGR10-2X8-PADHI-LE">
+	      <entry>V4L2_MBUS_FMT_SBGGR10_2X8_PADHI_LE</entry>
+	      <entry>0x3004</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>b<subscript>7</subscript></entry>
+	      <entry>b<subscript>6</subscript></entry>
+	      <entry>b<subscript>5</subscript></entry>
+	      <entry>b<subscript>4</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>b<subscript>9</subscript></entry>
+	      <entry>b<subscript>8</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SBGGR10-2X8-PADLO-BE">
+	      <entry>V4L2_MBUS_FMT_SBGGR10_2X8_PADLO_BE</entry>
+	      <entry>0x3005</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>b<subscript>9</subscript></entry>
+	      <entry>b<subscript>8</subscript></entry>
+	      <entry>b<subscript>7</subscript></entry>
+	      <entry>b<subscript>6</subscript></entry>
+	      <entry>b<subscript>5</subscript></entry>
+	      <entry>b<subscript>4</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SBGGR10-2X8-PADLO-LE">
+	      <entry>V4L2_MBUS_FMT_SBGGR10_2X8_PADLO_LE</entry>
+	      <entry>0x3006</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	      <entry>0</entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>b<subscript>9</subscript></entry>
+	      <entry>b<subscript>8</subscript></entry>
+	      <entry>b<subscript>7</subscript></entry>
+	      <entry>b<subscript>6</subscript></entry>
+	      <entry>b<subscript>5</subscript></entry>
+	      <entry>b<subscript>4</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SBGGR10-1X10">
+	      <entry>V4L2_MBUS_FMT_SBGGR10_1X10</entry>
+	      <entry>0x3007</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>b<subscript>9</subscript></entry>
+	      <entry>b<subscript>8</subscript></entry>
+	      <entry>b<subscript>7</subscript></entry>
+	      <entry>b<subscript>6</subscript></entry>
+	      <entry>b<subscript>5</subscript></entry>
+	      <entry>b<subscript>4</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SGBRG10-1X10">
+	      <entry>V4L2_MBUS_FMT_SGBRG10_1X10</entry>
+	      <entry>0x300e</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>g<subscript>9</subscript></entry>
+	      <entry>g<subscript>8</subscript></entry>
+	      <entry>g<subscript>7</subscript></entry>
+	      <entry>g<subscript>6</subscript></entry>
+	      <entry>g<subscript>5</subscript></entry>
+	      <entry>g<subscript>4</subscript></entry>
+	      <entry>g<subscript>3</subscript></entry>
+	      <entry>g<subscript>2</subscript></entry>
+	      <entry>g<subscript>1</subscript></entry>
+	      <entry>g<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SGRBG10-1X10">
+	      <entry>V4L2_MBUS_FMT_SGRBG10_1X10</entry>
+	      <entry>0x300a</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>g<subscript>9</subscript></entry>
+	      <entry>g<subscript>8</subscript></entry>
+	      <entry>g<subscript>7</subscript></entry>
+	      <entry>g<subscript>6</subscript></entry>
+	      <entry>g<subscript>5</subscript></entry>
+	      <entry>g<subscript>4</subscript></entry>
+	      <entry>g<subscript>3</subscript></entry>
+	      <entry>g<subscript>2</subscript></entry>
+	      <entry>g<subscript>1</subscript></entry>
+	      <entry>g<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SRGGB10-1X10">
+	      <entry>V4L2_MBUS_FMT_SRGGB10_1X10</entry>
+	      <entry>0x300f</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>r<subscript>9</subscript></entry>
+	      <entry>r<subscript>8</subscript></entry>
+	      <entry>r<subscript>7</subscript></entry>
+	      <entry>r<subscript>6</subscript></entry>
+	      <entry>r<subscript>5</subscript></entry>
+	      <entry>r<subscript>4</subscript></entry>
+	      <entry>r<subscript>3</subscript></entry>
+	      <entry>r<subscript>2</subscript></entry>
+	      <entry>r<subscript>1</subscript></entry>
+	      <entry>r<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SBGGR12-1X12">
+	      <entry>V4L2_MBUS_FMT_SBGGR12_1X12</entry>
+	      <entry>0x3008</entry>
+	      <entry></entry>
+	      <entry>b<subscript>11</subscript></entry>
+	      <entry>b<subscript>10</subscript></entry>
+	      <entry>b<subscript>9</subscript></entry>
+	      <entry>b<subscript>8</subscript></entry>
+	      <entry>b<subscript>7</subscript></entry>
+	      <entry>b<subscript>6</subscript></entry>
+	      <entry>b<subscript>5</subscript></entry>
+	      <entry>b<subscript>4</subscript></entry>
+	      <entry>b<subscript>3</subscript></entry>
+	      <entry>b<subscript>2</subscript></entry>
+	      <entry>b<subscript>1</subscript></entry>
+	      <entry>b<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SGBRG12-1X12">
+	      <entry>V4L2_MBUS_FMT_SGBRG12_1X12</entry>
+	      <entry>0x3010</entry>
+	      <entry></entry>
+	      <entry>g<subscript>11</subscript></entry>
+	      <entry>g<subscript>10</subscript></entry>
+	      <entry>g<subscript>9</subscript></entry>
+	      <entry>g<subscript>8</subscript></entry>
+	      <entry>g<subscript>7</subscript></entry>
+	      <entry>g<subscript>6</subscript></entry>
+	      <entry>g<subscript>5</subscript></entry>
+	      <entry>g<subscript>4</subscript></entry>
+	      <entry>g<subscript>3</subscript></entry>
+	      <entry>g<subscript>2</subscript></entry>
+	      <entry>g<subscript>1</subscript></entry>
+	      <entry>g<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SGRBG12-1X12">
+	      <entry>V4L2_MBUS_FMT_SGRBG12_1X12</entry>
+	      <entry>0x3011</entry>
+	      <entry></entry>
+	      <entry>g<subscript>11</subscript></entry>
+	      <entry>g<subscript>10</subscript></entry>
+	      <entry>g<subscript>9</subscript></entry>
+	      <entry>g<subscript>8</subscript></entry>
+	      <entry>g<subscript>7</subscript></entry>
+	      <entry>g<subscript>6</subscript></entry>
+	      <entry>g<subscript>5</subscript></entry>
+	      <entry>g<subscript>4</subscript></entry>
+	      <entry>g<subscript>3</subscript></entry>
+	      <entry>g<subscript>2</subscript></entry>
+	      <entry>g<subscript>1</subscript></entry>
+	      <entry>g<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-SRGGB12-1X12">
+	      <entry>V4L2_MBUS_FMT_SRGGB12_1X12</entry>
+	      <entry>0x3012</entry>
+	      <entry></entry>
+	      <entry>r<subscript>11</subscript></entry>
+	      <entry>r<subscript>10</subscript></entry>
+	      <entry>r<subscript>9</subscript></entry>
+	      <entry>r<subscript>8</subscript></entry>
+	      <entry>r<subscript>7</subscript></entry>
+	      <entry>r<subscript>6</subscript></entry>
+	      <entry>r<subscript>5</subscript></entry>
+	      <entry>r<subscript>4</subscript></entry>
+	      <entry>r<subscript>3</subscript></entry>
+	      <entry>r<subscript>2</subscript></entry>
+	      <entry>r<subscript>1</subscript></entry>
+	      <entry>r<subscript>0</subscript></entry>
+	    </row>
+	  </tbody>
+	</tgroup>
+      </table>
+    </section>
+
+    <section>
+      <title>Packed YUV Formats</title>
+
+      <para>Those data formats transfer pixel data as (possibly downsampled) Y, U
+      and V components. The format code is made of the following information.
+      <itemizedlist>
+	<listitem><para>The Y, U and V components order code, as transferred on the
+	bus. Possible values are YUYV, UYVY, YVYU and VYUY.</para></listitem>
+	<listitem><para>The number of bits per pixel component. All components are
+	transferred on the same number of bits. Common values are 8, 10 and 12.</para>
+	</listitem>
+	<listitem><para>The number of bus samples per pixel. Pixels that are wider than
+	the bus width must be transferred in multiple samples. Common values are
+	1, 1.5 (encoded as 1_5) and 2.</para></listitem>
+	<listitem><para>The bus width. When the bus width is larger than the number of
+	bits per pixel component, several components are packed in a single bus
+	sample. The components are ordered as specified by the order code, with
+	components on the left of the code transferred in the high order bits.
+	Common values are 8 and 16.</para>
+	</listitem>
+      </itemizedlist>
+      </para>
+
+      <para>For instance, a format where pixels are encoded as 8-bit YUV values
+      downsampled to 4:2:2 and transferred as 2 8-bit bus samples per pixel in the
+      U, Y, V, Y order will be named <constant>V4L2_MBUS_FMT_UYVY8_2X8</constant>.
+      </para>
+
+      <para>The following table lisst existing packet YUV formats.</para>
+
+      <table pgwide="0" frame="none" id="v4l2-mbus-pixelcode-yuv8">
+	<title>YUV Formats</title>
+	<tgroup cols="23">
+	  <colspec colname="id" align="left" />
+	  <colspec colname="code" align="center"/>
+	  <colspec colname="bit" />
+	  <colspec colnum="4" colname="b19" align="center" />
+	  <colspec colnum="5" colname="b18" align="center" />
+	  <colspec colnum="6" colname="b17" align="center" />
+	  <colspec colnum="7" colname="b16" align="center" />
+	  <colspec colnum="8" colname="b15" align="center" />
+	  <colspec colnum="9" colname="b14" align="center" />
+	  <colspec colnum="10" colname="b13" align="center" />
+	  <colspec colnum="11" colname="b12" align="center" />
+	  <colspec colnum="12" colname="b11" align="center" />
+	  <colspec colnum="13" colname="b10" align="center" />
+	  <colspec colnum="14" colname="b09" align="center" />
+	  <colspec colnum="15" colname="b08" align="center" />
+	  <colspec colnum="16" colname="b07" align="center" />
+	  <colspec colnum="17" colname="b06" align="center" />
+	  <colspec colnum="18" colname="b05" align="center" />
+	  <colspec colnum="19" colname="b04" align="center" />
+	  <colspec colnum="20" colname="b03" align="center" />
+	  <colspec colnum="21" colname="b02" align="center" />
+	  <colspec colnum="22" colname="b01" align="center" />
+	  <colspec colnum="23" colname="b00" align="center" />
+	  <spanspec namest="b19" nameend="b00" spanname="b0" />
+	  <thead>
+	    <row>
+	      <entry>Identifier</entry>
+	      <entry>Code</entry>
+	      <entry></entry>
+	      <entry spanname="b0">Data organization</entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>Bit</entry>
+	      <entry>19</entry>
+	      <entry>18</entry>
+	      <entry>17</entry>
+	      <entry>16</entry>
+	      <entry>15</entry>
+	      <entry>14</entry>
+	      <entry>13</entry>
+	      <entry>12</entry>
+	      <entry>11</entry>
+	      <entry>10</entry>
+	      <entry>9</entry>
+	      <entry>8</entry>
+	      <entry>7</entry>
+	      <entry>6</entry>
+	      <entry>5</entry>
+	      <entry>4</entry>
+	      <entry>3</entry>
+	      <entry>2</entry>
+	      <entry>1</entry>
+	      <entry>0</entry>
+	    </row>
+	  </thead>
+	  <tbody valign="top">
+	    <row id="V4L2-MBUS-FMT-Y8-1X8">
+	      <entry>V4L2_MBUS_FMT_Y8_1X8</entry>
+	      <entry>0x2001</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-UYVY8-1_5X8">
+	      <entry>V4L2_MBUS_FMT_UYVY8_1_5X8</entry>
+	      <entry>0x2002</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-VYUY8-1_5X8">
+	      <entry>V4L2_MBUS_FMT_VYUY8_1_5X8</entry>
+	      <entry>0x2003</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-YUYV8-1_5X8">
+	      <entry>V4L2_MBUS_FMT_YUYV8_1_5X8</entry>
+	      <entry>0x2004</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-YVYU8-1_5X8">
+	      <entry>V4L2_MBUS_FMT_YVYU8_1_5X8</entry>
+	      <entry>0x2005</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-UYVY8-2X8">
+	      <entry>V4L2_MBUS_FMT_UYVY8_2X8</entry>
+	      <entry>0x2006</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-VYUY8-2X8">
+	      <entry>V4L2_MBUS_FMT_VYUY8_2X8</entry>
+	      <entry>0x2007</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-YUYV8-2X8">
+	      <entry>V4L2_MBUS_FMT_YUYV8_2X8</entry>
+	      <entry>0x2008</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-YVYU8-2X8">
+	      <entry>V4L2_MBUS_FMT_YVYU8_2X8</entry>
+	      <entry>0x2009</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-Y10-1X10">
+	      <entry>V4L2_MBUS_FMT_Y10_1X10</entry>
+	      <entry>0x200a</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>9</subscript></entry>
+	      <entry>y<subscript>8</subscript></entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-YUYV10-2X10">
+	      <entry>V4L2_MBUS_FMT_YUYV10_2X10</entry>
+	      <entry>0x200b</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>9</subscript></entry>
+	      <entry>y<subscript>8</subscript></entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>u<subscript>9</subscript></entry>
+	      <entry>u<subscript>8</subscript></entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>9</subscript></entry>
+	      <entry>y<subscript>8</subscript></entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>v<subscript>9</subscript></entry>
+	      <entry>v<subscript>8</subscript></entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-YVYU10-2X10">
+	      <entry>V4L2_MBUS_FMT_YVYU10_2X10</entry>
+	      <entry>0x200c</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>9</subscript></entry>
+	      <entry>y<subscript>8</subscript></entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>v<subscript>9</subscript></entry>
+	      <entry>v<subscript>8</subscript></entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>9</subscript></entry>
+	      <entry>y<subscript>8</subscript></entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>u<subscript>9</subscript></entry>
+	      <entry>u<subscript>8</subscript></entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-UYVY8-1X16">
+	      <entry>V4L2_MBUS_FMT_UYVY8_1X16</entry>
+	      <entry>0x200f</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-VYUY8-1X16">
+	      <entry>V4L2_MBUS_FMT_VYUY8_1X16</entry>
+	      <entry>0x2010</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-YUYV8-1X16">
+	      <entry>V4L2_MBUS_FMT_YUYV8_1X16</entry>
+	      <entry>0x2011</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-YVYU8-1X16">
+	      <entry>V4L2_MBUS_FMT_YVYU8_1X16</entry>
+	      <entry>0x2012</entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>-</entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-YUYV10-1X20">
+	      <entry>V4L2_MBUS_FMT_YUYV10_1X20</entry>
+	      <entry>0x200d</entry>
+	      <entry></entry>
+	      <entry>y<subscript>9</subscript></entry>
+	      <entry>y<subscript>8</subscript></entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	      <entry>u<subscript>9</subscript></entry>
+	      <entry>u<subscript>8</subscript></entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>y<subscript>9</subscript></entry>
+	      <entry>y<subscript>8</subscript></entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	      <entry>v<subscript>9</subscript></entry>
+	      <entry>v<subscript>8</subscript></entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	    </row>
+	    <row id="V4L2-MBUS-FMT-YVYU10-1X20">
+	      <entry>V4L2_MBUS_FMT_YVYU10_1X20</entry>
+	      <entry>0x200e</entry>
+	      <entry></entry>
+	      <entry>y<subscript>9</subscript></entry>
+	      <entry>y<subscript>8</subscript></entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	      <entry>v<subscript>9</subscript></entry>
+	      <entry>v<subscript>8</subscript></entry>
+	      <entry>v<subscript>7</subscript></entry>
+	      <entry>v<subscript>6</subscript></entry>
+	      <entry>v<subscript>5</subscript></entry>
+	      <entry>v<subscript>4</subscript></entry>
+	      <entry>v<subscript>3</subscript></entry>
+	      <entry>v<subscript>2</subscript></entry>
+	      <entry>v<subscript>1</subscript></entry>
+	      <entry>v<subscript>0</subscript></entry>
+	    </row>
+	    <row>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry></entry>
+	      <entry>y<subscript>9</subscript></entry>
+	      <entry>y<subscript>8</subscript></entry>
+	      <entry>y<subscript>7</subscript></entry>
+	      <entry>y<subscript>6</subscript></entry>
+	      <entry>y<subscript>5</subscript></entry>
+	      <entry>y<subscript>4</subscript></entry>
+	      <entry>y<subscript>3</subscript></entry>
+	      <entry>y<subscript>2</subscript></entry>
+	      <entry>y<subscript>1</subscript></entry>
+	      <entry>y<subscript>0</subscript></entry>
+	      <entry>u<subscript>9</subscript></entry>
+	      <entry>u<subscript>8</subscript></entry>
+	      <entry>u<subscript>7</subscript></entry>
+	      <entry>u<subscript>6</subscript></entry>
+	      <entry>u<subscript>5</subscript></entry>
+	      <entry>u<subscript>4</subscript></entry>
+	      <entry>u<subscript>3</subscript></entry>
+	      <entry>u<subscript>2</subscript></entry>
+	      <entry>u<subscript>1</subscript></entry>
+	      <entry>u<subscript>0</subscript></entry>
+	    </row>
+	  </tbody>
+	</tgroup>
+      </table>
+    </section>
+  </section>
+</section>

Documentation/DocBook/v4l/v4l2.xml

@@ -85,6 +85,17 @@ Remote Controller chapter.</contrib>
 	  </address>
 	</affiliation>
       </author>
+
+      <author>
+      	<firstname>Pawel</firstname>
+	<surname>Osciak</surname>
+	<contrib>Designed and documented the multi-planar API.</contrib>
+	<affiliation>
+	  <address>
+	    <email>pawel AT osciak.com</email>
+	  </address>
+	</affiliation>
+      </author>
     </authorgroup>

     <copyright>
@@ -102,7 +113,8 @@ Remote Controller chapter.</contrib>
       <year>2010</year>
       <year>2011</year>
       <holder>Bill Dirks, Michael H. Schimek, Hans Verkuil, Martin
-Rubli, Andy Walls, Muralidharan Karicheri, Mauro Carvalho Chehab</holder>
+Rubli, Andy Walls, Muralidharan Karicheri, Mauro Carvalho Chehab,
+	Pawel Osciak</holder>
     </copyright>
     <legalnotice>
     <para>Except when explicitly stated as GPL, programming examples within
@@ -115,6 +127,13 @@ structs, ioctls) must be noted in more detail in the history chapter
 (compat.xml), along with the possible impact on existing drivers and
 applications. -->

+      <revision>
+	<revnumber>2.6.39</revnumber>
+	<date>2011-03-01</date>
+	<authorinitials>mcc, po</authorinitials>
+	<revremark>Removed VIDIOC_*_OLD from videodev2.h header and update it to reflect latest changes. Added the <link linkend="planar-apis">multi-planar API</link>.</revremark>
+      </revision>
+
       <revision>
 	<revnumber>2.6.37</revnumber>
 	<date>2010-08-06</date>
@@ -382,7 +401,7 @@ and discussions on the V4L mailing list.</revremark>
 </partinfo>

 <title>Video for Linux Two API Specification</title>
- <subtitle>Revision 2.6.38</subtitle>
+ <subtitle>Revision 2.6.39</subtitle>

   <chapter id="common">
     &sub-common;
@@ -411,6 +430,7 @@ and discussions on the V4L mailing list.</revremark>
     <section id="radio"> &sub-dev-radio; </section>
     <section id="rds"> &sub-dev-rds; </section>
     <section id="event"> &sub-dev-event; </section>
+    <section id="subdev"> &sub-dev-subdev; </section>
   </chapter>

   <chapter id="driver">
@@ -478,6 +498,12 @@ and discussions on the V4L mailing list.</revremark>
     &sub-reqbufs;
     &sub-s-hw-freq-seek;
     &sub-streamon;
+    &sub-subdev-enum-frame-interval;
+    &sub-subdev-enum-frame-size;
+    &sub-subdev-enum-mbus-code;
+    &sub-subdev-g-crop;
+    &sub-subdev-g-fmt;
+    &sub-subdev-g-frame-interval;
     &sub-subscribe-event;
     <!-- End of ioctls. -->
     &sub-mmap;

Documentation/DocBook/v4l/videodev2.h.xml

@@ -71,6 +71,7 @@
  * Moved from videodev.h
  */
 #define VIDEO_MAX_FRAME               32
+#define VIDEO_MAX_PLANES               8

 #ifndef __KERNEL__

@@ -158,9 +159,23 @@ enum <link linkend="v4l2-buf-type">v4l2_buf_type</link> {
         /* Experimental */
         V4L2_BUF_TYPE_VIDEO_OUTPUT_OVERLAY = 8,
 #endif
+        V4L2_BUF_TYPE_VIDEO_CAPTURE_MPLANE = 9,
+        V4L2_BUF_TYPE_VIDEO_OUTPUT_MPLANE  = 10,
         V4L2_BUF_TYPE_PRIVATE              = 0x80,
 };

+#define V4L2_TYPE_IS_MULTIPLANAR(type)                  \
+        ((type) == V4L2_BUF_TYPE_VIDEO_CAPTURE_MPLANE   \
+         || (type) == V4L2_BUF_TYPE_VIDEO_OUTPUT_MPLANE)
+
+#define V4L2_TYPE_IS_OUTPUT(type)                               \
+        ((type) == V4L2_BUF_TYPE_VIDEO_OUTPUT                   \
+         || (type) == V4L2_BUF_TYPE_VIDEO_OUTPUT_MPLANE         \
+         || (type) == V4L2_BUF_TYPE_VIDEO_OVERLAY               \
+         || (type) == V4L2_BUF_TYPE_VIDEO_OUTPUT_OVERLAY        \
+         || (type) == V4L2_BUF_TYPE_VBI_OUTPUT                  \
+         || (type) == V4L2_BUF_TYPE_SLICED_VBI_OUTPUT)
+
 enum <link linkend="v4l2-tuner-type">v4l2_tuner_type</link> {
         V4L2_TUNER_RADIO             = 1,
         V4L2_TUNER_ANALOG_TV         = 2,
@@ -246,6 +261,11 @@ struct <link linkend="v4l2-capability">v4l2_capability</link> {
 #define V4L2_CAP_HW_FREQ_SEEK           0x00000400  /* Can do hardware frequency seek  */
 #define V4L2_CAP_RDS_OUTPUT             0x00000800  /* Is an RDS encoder */

+/* Is a video capture device that supports multiplanar formats */
+#define V4L2_CAP_VIDEO_CAPTURE_MPLANE   0x00001000
+/* Is a video output device that supports multiplanar formats */
+#define V4L2_CAP_VIDEO_OUTPUT_MPLANE    0x00002000
+
 #define V4L2_CAP_TUNER                  0x00010000  /* has a tuner */
 #define V4L2_CAP_AUDIO                  0x00020000  /* has audio support */
 #define V4L2_CAP_RADIO                  0x00040000  /* is a radio device */
@@ -320,6 +340,13 @@ struct <link linkend="v4l2-pix-format">v4l2_pix_format</link> {
 #define <link linkend="V4L2-PIX-FMT-NV16">V4L2_PIX_FMT_NV16</link>    v4l2_fourcc('N', 'V', '1', '6') /* 16  Y/CbCr 4:2:2  */
 #define <link linkend="V4L2-PIX-FMT-NV61">V4L2_PIX_FMT_NV61</link>    v4l2_fourcc('N', 'V', '6', '1') /* 16  Y/CrCb 4:2:2  */

+/* two non contiguous planes - one Y, one Cr + Cb interleaved  */
+#define <link linkend="V4L2-PIX-FMT-NV12M">V4L2_PIX_FMT_NV12M</link>   v4l2_fourcc('N', 'M', '1', '2') /* 12  Y/CbCr 4:2:0  */
+#define <link linkend="V4L2-PIX-FMT-NV12MT">V4L2_PIX_FMT_NV12MT</link>  v4l2_fourcc('T', 'M', '1', '2') /* 12  Y/CbCr 4:2:0 64x32 macroblocks */
+
+/* three non contiguous planes - Y, Cb, Cr */
+#define <link linkend="V4L2-PIX-FMT-YUV420M">V4L2_PIX_FMT_YUV420M</link> v4l2_fourcc('Y', 'M', '1', '2') /* 12  YUV420 planar */
+
 /* Bayer formats - see http://www.siliconimaging.com/RGB%20Bayer.htm */
 #define <link linkend="V4L2-PIX-FMT-SBGGR8">V4L2_PIX_FMT_SBGGR8</link>  v4l2_fourcc('B', 'A', '8', '1') /*  8  BGBG.. GRGR.. */
 #define <link linkend="V4L2-PIX-FMT-SGBRG8">V4L2_PIX_FMT_SGBRG8</link>  v4l2_fourcc('G', 'B', 'R', 'G') /*  8  GBGB.. RGRG.. */
@@ -518,6 +545,62 @@ struct <link linkend="v4l2-requestbuffers">v4l2_requestbuffers</link> {
         __u32                   reserved[2];
 };

+/**
+ * struct <link linkend="v4l2-plane">v4l2_plane</link> - plane info for multi-planar buffers
+ * @bytesused:          number of bytes occupied by data in the plane (payload)
+ * @length:             size of this plane (NOT the payload) in bytes
+ * @mem_offset:         when memory in the associated struct <link linkend="v4l2-buffer">v4l2_buffer</link> is
+ *                      V4L2_MEMORY_MMAP, equals the offset from the start of
+ *                      the device memory for this plane (or is a "cookie" that
+ *                      should be passed to mmap() called on the video node)
+ * @userptr:            when memory is V4L2_MEMORY_USERPTR, a userspace pointer
+ *                      pointing to this plane
+ * @data_offset:        offset in the plane to the start of data; usually 0,
+ *                      unless there is a header in front of the data
+ *
+ * Multi-planar buffers consist of one or more planes, e.g. an YCbCr buffer
+ * with two planes can have one plane for Y, and another for interleaved CbCr
+ * components. Each plane can reside in a separate memory buffer, or even in
+ * a completely separate memory node (e.g. in embedded devices).
+ */
+struct <link linkend="v4l2-plane">v4l2_plane</link> {
+        __u32                   bytesused;
+        __u32                   length;
+        union {
+                __u32           mem_offset;
+                unsigned long   userptr;
+        } m;
+        __u32                   data_offset;
+        __u32                   reserved[11];
+};
+
+/**
+ * struct <link linkend="v4l2-buffer">v4l2_buffer</link> - video buffer info
+ * @index:      id number of the buffer
+ * @type:       buffer type (type == *_MPLANE for multiplanar buffers)
+ * @bytesused:  number of bytes occupied by data in the buffer (payload);
+ *              unused (set to 0) for multiplanar buffers
+ * @flags:      buffer informational flags
+ * @field:      field order of the image in the buffer
+ * @timestamp:  frame timestamp
+ * @timecode:   frame timecode
+ * @sequence:   sequence count of this frame
+ * @memory:     the method, in which the actual video data is passed
+ * @offset:     for non-multiplanar buffers with memory == V4L2_MEMORY_MMAP;
+ *              offset from the start of the device memory for this plane,
+ *              (or a "cookie" that should be passed to mmap() as offset)
+ * @userptr:    for non-multiplanar buffers with memory == V4L2_MEMORY_USERPTR;
+ *              a userspace pointer pointing to this buffer
+ * @planes:     for multiplanar buffers; userspace pointer to the array of plane
+ *              info structs for this buffer
+ * @length:     size in bytes of the buffer (NOT its payload) for single-plane
+ *              buffers (when type != *_MPLANE); number of elements in the
+ *              planes array for multi-plane buffers
+ * @input:      input number from which the video data has has been captured
+ *
+ * Contains data exchanged by application and driver using one of the Streaming
+ * I/O methods.
+ */
 struct <link linkend="v4l2-buffer">v4l2_buffer</link> {
         __u32                   index;
         enum <link linkend="v4l2-buf-type">v4l2_buf_type</link>      type;
@@ -533,6 +616,7 @@ struct <link linkend="v4l2-buffer">v4l2_buffer</link> {
         union {
                 __u32           offset;
                 unsigned long   userptr;
+                struct <link linkend="v4l2-plane">v4l2_plane</link> *planes;
         } m;
         __u32                   length;
         __u32                   input;
@@ -1623,12 +1707,56 @@ struct <link linkend="v4l2-mpeg-vbi-fmt-ivtv">v4l2_mpeg_vbi_fmt_ivtv</link> {
  *      A G G R E G A T E   S T R U C T U R E S
  */

-/*      Stream data format
+/**
+ * struct <link linkend="v4l2-plane-pix-format">v4l2_plane_pix_format</link> - additional, per-plane format definition
+ * @sizeimage:          maximum size in bytes required for data, for which
+ *                      this plane will be used
+ * @bytesperline:       distance in bytes between the leftmost pixels in two
+ *                      adjacent lines
+ */
+struct <link linkend="v4l2-plane-pix-format">v4l2_plane_pix_format</link> {
+        __u32           sizeimage;
+        __u16           bytesperline;
+        __u16           reserved[7];
+} __attribute__ ((packed));
+
+/**
+ * struct <link linkend="v4l2-pix-format-mplane">v4l2_pix_format_mplane</link> - multiplanar format definition
+ * @width:              image width in pixels
+ * @height:             image height in pixels
+ * @pixelformat:        little endian four character code (fourcc)
+ * @field:              field order (for interlaced video)
+ * @colorspace:         supplemental to pixelformat
+ * @plane_fmt:          per-plane information
+ * @num_planes:         number of planes for this format
+ */
+struct <link linkend="v4l2-pix-format-mplane">v4l2_pix_format_mplane</link> {
+        __u32                           width;
+        __u32                           height;
+        __u32                           pixelformat;
+        enum <link linkend="v4l2-field">v4l2_field</link>                 field;
+        enum <link linkend="v4l2-colorspace">v4l2_colorspace</link>            colorspace;
+
+        struct <link linkend="v4l2-plane-pix-format">v4l2_plane_pix_format</link>    plane_fmt[VIDEO_MAX_PLANES];
+        __u8                            num_planes;
+        __u8                            reserved[11];
+} __attribute__ ((packed));
+
+/**
+ * struct <link linkend="v4l2-format">v4l2_format</link> - stream data format
+ * @type:       type of the data stream
+ * @pix:        definition of an image format
+ * @pix_mp:     definition of a multiplanar image format
+ * @win:        definition of an overlaid image
+ * @vbi:        raw VBI capture or output parameters
+ * @sliced:     sliced VBI capture or output parameters
+ * @raw_data:   placeholder for future extensions and custom formats
  */
 struct <link linkend="v4l2-format">v4l2_format</link> {
         enum <link linkend="v4l2-buf-type">v4l2_buf_type</link> type;
         union {
                 struct <link linkend="v4l2-pix-format">v4l2_pix_format</link>          pix;     /* V4L2_BUF_TYPE_VIDEO_CAPTURE */
+                struct <link linkend="v4l2-pix-format-mplane">v4l2_pix_format_mplane</link>   pix_mp;  /* V4L2_BUF_TYPE_VIDEO_CAPTURE_MPLANE */
                 struct <link linkend="v4l2-window">v4l2_window</link>              win;     /* V4L2_BUF_TYPE_VIDEO_OVERLAY */
                 struct <link linkend="v4l2-vbi-format">v4l2_vbi_format</link>          vbi;     /* V4L2_BUF_TYPE_VBI_CAPTURE */
                 struct <link linkend="v4l2-sliced-vbi-format">v4l2_sliced_vbi_format</link>   sliced;  /* V4L2_BUF_TYPE_SLICED_VBI_CAPTURE */
@@ -1636,7 +1764,6 @@ struct <link linkend="v4l2-format">v4l2_format</link> {
         } fmt;
 };

-
 /*      Stream type-dependent parameters
  */
 struct <link linkend="v4l2-streamparm">v4l2_streamparm</link> {
@@ -1809,16 +1936,6 @@ struct <link linkend="v4l2-dbg-chip-ident">v4l2_dbg_chip_ident</link> {
 /* Reminder: when adding new ioctls please add support for them to
    drivers/media/video/v4l2-compat-ioctl32.c as well! */

-#ifdef __OLD_VIDIOC_
-/* for compatibility, will go away some day */
-#define VIDIOC_OVERLAY_OLD      _IOWR('V', 14, int)
-#define VIDIOC_S_PARM_OLD        _IOW('V', 22, struct <link linkend="v4l2-streamparm">v4l2_streamparm</link>)
-#define VIDIOC_S_CTRL_OLD        _IOW('V', 28, struct <link linkend="v4l2-control">v4l2_control</link>)
-#define VIDIOC_G_AUDIO_OLD      _IOWR('V', 33, struct <link linkend="v4l2-audio">v4l2_audio</link>)
-#define VIDIOC_G_AUDOUT_OLD     _IOWR('V', 49, struct <link linkend="v4l2-audioout">v4l2_audioout</link>)
-#define VIDIOC_CROPCAP_OLD       _IOR('V', 58, struct <link linkend="v4l2-cropcap">v4l2_cropcap</link>)
-#endif
-
 #define BASE_VIDIOC_PRIVATE     192             /* 192-255 are private */

 #endif /* __LINUX_VIDEODEV2_H */

Documentation/DocBook/v4l/vidioc-enum-fmt.xml

@@ -76,7 +76,9 @@ pixelformat</structfield> field.</entry>
 	    <entry>Type of the data stream, set by the application.
 Only these types are valid here:
 <constant>V4L2_BUF_TYPE_VIDEO_CAPTURE</constant>,
+<constant>V4L2_BUF_TYPE_VIDEO_CAPTURE_MPLANE</constant>,
 <constant>V4L2_BUF_TYPE_VIDEO_OUTPUT</constant>,
+<constant>V4L2_BUF_TYPE_VIDEO_OUTPUT_MPLANE</constant>,
 <constant>V4L2_BUF_TYPE_VIDEO_OVERLAY</constant>, and custom (driver
 defined) types with code <constant>V4L2_BUF_TYPE_PRIVATE</constant>
 and higher.</entry>

Documentation/DocBook/v4l/vidioc-g-fmt.xml

@@ -60,11 +60,13 @@ application.</para>
 <structfield>type</structfield> field of a struct
 <structname>v4l2_format</structname> to the respective buffer (stream)
 type. For example video capture devices use
-<constant>V4L2_BUF_TYPE_VIDEO_CAPTURE</constant>. When the application
+<constant>V4L2_BUF_TYPE_VIDEO_CAPTURE</constant> or
+<constant>V4L2_BUF_TYPE_VIDEO_CAPTURE_MPLANE</constant>. When the application
 calls the <constant>VIDIOC_G_FMT</constant> ioctl with a pointer to
 this structure the driver fills the respective member of the
 <structfield>fmt</structfield> union. In case of video capture devices
-that is the &v4l2-pix-format; <structfield>pix</structfield> member.
+that is either the &v4l2-pix-format; <structfield>pix</structfield> or
+the &v4l2-pix-format-mplane; <structfield>pix_mp</structfield> member.
 When the requested buffer type is not supported drivers return an
 &EINVAL;.</para>

@@ -131,6 +133,15 @@ this ioctl.</para>
 	    <entry>Definition of an image format, see <xref
 		linkend="pixfmt" />, used by video capture and output
 devices.</entry>
+	  </row>
+	  <row>
+	    <entry></entry>
+	    <entry>&v4l2-pix-format-mplane;</entry>
+	    <entry><structfield>pix_mp</structfield></entry>
+	    <entry>Definition of an image format, see <xref
+		linkend="pixfmt" />, used by video capture and output
+devices that support the <link linkend="planar-apis">multi-planar
+version of the API</link>.</entry>
 	  </row>
 	  <row>
 	    <entry></entry>

Documentation/DocBook/v4l/vidioc-qbuf.xml

@@ -64,7 +64,8 @@ zero to the number of buffers allocated with &VIDIOC-REQBUFS;
 contents of the struct <structname>v4l2_buffer</structname> returned
 by a &VIDIOC-QUERYBUF; ioctl will do as well. When the buffer is
 intended for output (<structfield>type</structfield> is
-<constant>V4L2_BUF_TYPE_VIDEO_OUTPUT</constant> or
+<constant>V4L2_BUF_TYPE_VIDEO_OUTPUT</constant>,
+<constant>V4L2_BUF_TYPE_VIDEO_OUTPUT_MPLANE</constant>, or
 <constant>V4L2_BUF_TYPE_VBI_OUTPUT</constant>) applications must also
 initialize the <structfield>bytesused</structfield>,
 <structfield>field</structfield> and
@@ -75,7 +76,11 @@ supports capturing from specific video inputs and you want to specify a video
 input, then <structfield>flags</structfield> should be set to
 <constant>V4L2_BUF_FLAG_INPUT</constant> and the field
 <structfield>input</structfield> must be initialized to the desired input.
-The <structfield>reserved</structfield> field must be set to 0.
+The <structfield>reserved</structfield> field must be set to 0. When using
+the <link linkend="planar-apis">multi-planar API</link>, the
+<structfield>m.planes</structfield> field must contain a userspace pointer
+to a filled-in array of &v4l2-plane; and the <structfield>length</structfield>
+field must be set to the number of elements in that array.
 </para>

     <para>To enqueue a <link linkend="mmap">memory mapped</link>
@@ -93,10 +98,13 @@ structure the driver sets the
 buffer applications set the <structfield>memory</structfield>
 field to <constant>V4L2_MEMORY_USERPTR</constant>, the
 <structfield>m.userptr</structfield> field to the address of the
-buffer and <structfield>length</structfield> to its size.
-When <constant>VIDIOC_QBUF</constant> is called with a pointer to this
-structure the driver sets the <constant>V4L2_BUF_FLAG_QUEUED</constant>
-flag and clears the <constant>V4L2_BUF_FLAG_MAPPED</constant> and
+buffer and <structfield>length</structfield> to its size. When the multi-planar
+API is used, <structfield>m.userptr</structfield> and
+<structfield>length</structfield> members of the passed array of &v4l2-plane;
+have to be used instead. When <constant>VIDIOC_QBUF</constant> is called with
+a pointer to this structure the driver sets the
+<constant>V4L2_BUF_FLAG_QUEUED</constant> flag and clears the
+<constant>V4L2_BUF_FLAG_MAPPED</constant> and
 <constant>V4L2_BUF_FLAG_DONE</constant> flags in the
 <structfield>flags</structfield> field, or it returns an error code.
 This ioctl locks the memory pages of the buffer in physical memory,
@@ -115,7 +123,9 @@ remaining fields or returns an error code. The driver may also set
 <constant>V4L2_BUF_FLAG_ERROR</constant> in the <structfield>flags</structfield>
 field. It indicates a non-critical (recoverable) streaming error. In such case
 the application may continue as normal, but should be aware that data in the
-dequeued buffer might be corrupted.</para>
+dequeued buffer might be corrupted. When using the multi-planar API, the
+planes array does not have to be passed; the <structfield>m.planes</structfield>
+member must be set to NULL in that case.</para>

     <para>By default <constant>VIDIOC_DQBUF</constant> blocks when no
 buffer is in the outgoing queue. When the

Documentation/DocBook/v4l/vidioc-querybuf.xml

@@ -61,6 +61,10 @@ buffer at any time after buffers have been allocated with the
 to the number of buffers allocated with &VIDIOC-REQBUFS;
     (&v4l2-requestbuffers; <structfield>count</structfield>) minus one.
 The <structfield>reserved</structfield> field should to set to 0.
+When using the <link linkend="planar-apis">multi-planar API</link>, the
+<structfield>m.planes</structfield> field must contain a userspace pointer to an
+array of &v4l2-plane; and the <structfield>length</structfield> field has
+to be set to the number of elements in that array.
 After calling <constant>VIDIOC_QUERYBUF</constant> with a pointer to
     this structure drivers return an error code or fill the rest of
 the structure.</para>
@@ -70,11 +74,13 @@ the structure.</para>
 <constant>V4L2_BUF_FLAG_QUEUED</constant> and
 <constant>V4L2_BUF_FLAG_DONE</constant> flags will be valid. The
 <structfield>memory</structfield> field will be set to the current
-I/O method, the <structfield>m.offset</structfield>
+I/O method. For the single-planar API, the <structfield>m.offset</structfield>
 contains the offset of the buffer from the start of the device memory,
-the <structfield>length</structfield> field its size. The driver may
-or may not set the remaining fields and flags, they are meaningless in
-this context.</para>
+the <structfield>length</structfield> field its size. For the multi-planar API,
+fields <structfield>m.mem_offset</structfield> and
+<structfield>length</structfield> in the <structfield>m.planes</structfield>
+array elements will be used instead. The driver may or may not set the remaining
+fields and flags, they are meaningless in this context.</para>

     <para>The <structname>v4l2_buffer</structname> structure is
     specified in <xref linkend="buffer" />.</para>

Documentation/DocBook/v4l/vidioc-querycap.xml

@@ -142,15 +142,29 @@ this array to zero.</entry>
 	  <row>
 	    <entry><constant>V4L2_CAP_VIDEO_CAPTURE</constant></entry>
 	    <entry>0x00000001</entry>
-	    <entry>The device supports the <link
+	    <entry>The device supports the single-planar API through the <link
 linkend="capture">Video Capture</link> interface.</entry>
 	  </row>
+	  <row>
+	    <entry><constant>V4L2_CAP_VIDEO_CAPTURE_MPLANE</constant></entry>
+	    <entry>0x00001000</entry>
+	    <entry>The device supports the
+	    <link linkend="planar-apis">multi-planar API</link> through the
+	    <link linkend="capture">Video Capture</link> interface.</entry>
+	  </row>
 	  <row>
 	    <entry><constant>V4L2_CAP_VIDEO_OUTPUT</constant></entry>
 	    <entry>0x00000002</entry>
-	    <entry>The device supports the <link
+	    <entry>The device supports the single-planar API through the <link
 linkend="output">Video Output</link> interface.</entry>
 	  </row>
+	  <row>
+	    <entry><constant>V4L2_CAP_VIDEO_OUTPUT_MPLANE</constant></entry>
+	    <entry>0x00002000</entry>
+	    <entry>The device supports the
+	    <link linkend="planar-apis">multi-planar API</link> through the
+	    <link linkend="output">Video Output</link> interface.</entry>
+	  </row>
 	  <row>
 	    <entry><constant>V4L2_CAP_VIDEO_OVERLAY</constant></entry>
 	    <entry>0x00000004</entry>

Documentation/DocBook/v4l/vidioc-streamon.xml

@@ -93,6 +93,15 @@ synchronize with other events.</para>
 been allocated (memory mapping) or enqueued (output) yet.</para>
 	</listitem>
       </varlistentry>
+      <varlistentry>
+	<term><errorcode>EPIPE</errorcode></term>
+	<listitem>
+	  <para>The driver implements <link
+	  linkend="pad-level-formats">pad-level format configuration</link> and
+	  the pipeline configuration is invalid.
+	  </para>
+	</listitem>
+      </varlistentry>
     </variablelist>
   </refsect1>
 </refentry>

Documentation/DocBook/v4l/vidioc-subdev-enum-frame-interval.xml

@@ -0,0 +1,152 @@
+<refentry id="vidioc-subdev-enum-frame-interval">
+  <refmeta>
+    <refentrytitle>ioctl VIDIOC_SUBDEV_ENUM_FRAME_INTERVAL</refentrytitle>
+    &manvol;
+  </refmeta>
+
+  <refnamediv>
+    <refname>VIDIOC_SUBDEV_ENUM_FRAME_INTERVAL</refname>
+    <refpurpose>Enumerate frame intervals</refpurpose>
+  </refnamediv>
+
+  <refsynopsisdiv>
+    <funcsynopsis>
+      <funcprototype>
+	<funcdef>int <function>ioctl</function></funcdef>
+	<paramdef>int <parameter>fd</parameter></paramdef>
+	<paramdef>int <parameter>request</parameter></paramdef>
+	<paramdef>struct v4l2_subdev_frame_interval_enum *
+	<parameter>argp</parameter></paramdef>
+      </funcprototype>
+    </funcsynopsis>
+  </refsynopsisdiv>
+
+  <refsect1>
+    <title>Arguments</title>
+
+    <variablelist>
+      <varlistentry>
+	<term><parameter>fd</parameter></term>
+	<listitem>
+	  <para>&fd;</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>request</parameter></term>
+	<listitem>
+	  <para>VIDIOC_SUBDEV_ENUM_FRAME_INTERVAL</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>argp</parameter></term>
+	<listitem>
+	  <para></para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+
+  <refsect1>
+    <title>Description</title>
+
+    <note>
+      <title>Experimental</title>
+      <para>This is an <link linkend="experimental">experimental</link>
+      interface and may change in the future.</para>
+    </note>
+
+    <para>This ioctl lets applications enumerate available frame intervals on a
+    given sub-device pad. Frame intervals only makes sense for sub-devices that
+    can control the frame period on their own. This includes, for instance,
+    image sensors and TV tuners.</para>
+
+    <para>For the common use case of image sensors, the frame intervals
+    available on the sub-device output pad depend on the frame format and size
+    on the same pad. Applications must thus specify the desired format and size
+    when enumerating frame intervals.</para>
+
+    <para>To enumerate frame intervals applications initialize the
+    <structfield>index</structfield>, <structfield>pad</structfield>,
+    <structfield>code</structfield>, <structfield>width</structfield> and
+    <structfield>height</structfield> fields of
+    &v4l2-subdev-frame-interval-enum; and call the
+    <constant>VIDIOC_SUBDEV_ENUM_FRAME_INTERVAL</constant> ioctl with a pointer
+    to this structure. Drivers fill the rest of the structure or return
+    an &EINVAL; if one of the input fields is invalid. All frame intervals are
+    enumerable by beginning at index zero and incrementing by one until
+    <errorcode>EINVAL</errorcode> is returned.</para>
+
+    <para>Available frame intervals may depend on the current 'try' formats
+    at other pads of the sub-device, as well as on the current active links. See
+    &VIDIOC-SUBDEV-G-FMT; for more information about the try formats.</para>
+
+    <para>Sub-devices that support the frame interval enumeration ioctl should
+    implemented it on a single pad only. Its behaviour when supported on
+    multiple pads of the same sub-device is not defined.</para>
+
+    <table pgwide="1" frame="none" id="v4l2-subdev-frame-interval-enum">
+      <title>struct <structname>v4l2_subdev_frame_interval_enum</structname></title>
+      <tgroup cols="3">
+	&cs-str;
+	<tbody valign="top">
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>index</structfield></entry>
+	    <entry>Number of the format in the enumeration, set by the
+	    application.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>pad</structfield></entry>
+	    <entry>Pad number as reported by the media controller API.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>code</structfield></entry>
+	    <entry>The media bus format code, as defined in
+	    <xref linkend="v4l2-mbus-format" />.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>width</structfield></entry>
+	    <entry>Frame width, in pixels.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>height</structfield></entry>
+	    <entry>Frame height, in pixels.</entry>
+	  </row>
+	  <row>
+	    <entry>&v4l2-fract;</entry>
+	    <entry><structfield>interval</structfield></entry>
+	    <entry>Period, in seconds, between consecutive video frames.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>reserved</structfield>[9]</entry>
+	    <entry>Reserved for future extensions. Applications and drivers must
+	    set the array to zero.</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+  </refsect1>
+
+  <refsect1>
+    &return-value;
+
+    <variablelist>
+      <varlistentry>
+	<term><errorcode>EINVAL</errorcode></term>
+	<listitem>
+	  <para>The &v4l2-subdev-frame-interval-enum;
+	  <structfield>pad</structfield> references a non-existing pad, one of
+	  the <structfield>code</structfield>, <structfield>width</structfield>
+	  or <structfield>height</structfield> fields are invalid for the given
+	  pad or the <structfield>index</structfield> field is out of bounds.
+	  </para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+</refentry>

Documentation/DocBook/v4l/vidioc-subdev-enum-frame-size.xml

@@ -0,0 +1,154 @@
+<refentry id="vidioc-subdev-enum-frame-size">
+  <refmeta>
+    <refentrytitle>ioctl VIDIOC_SUBDEV_ENUM_FRAME_SIZE</refentrytitle>
+    &manvol;
+  </refmeta>
+
+  <refnamediv>
+    <refname>VIDIOC_SUBDEV_ENUM_FRAME_SIZE</refname>
+    <refpurpose>Enumerate media bus frame sizes</refpurpose>
+  </refnamediv>
+
+  <refsynopsisdiv>
+    <funcsynopsis>
+      <funcprototype>
+	<funcdef>int <function>ioctl</function></funcdef>
+	<paramdef>int <parameter>fd</parameter></paramdef>
+	<paramdef>int <parameter>request</parameter></paramdef>
+	<paramdef>struct v4l2_subdev_frame_size_enum *
+	<parameter>argp</parameter></paramdef>
+      </funcprototype>
+    </funcsynopsis>
+  </refsynopsisdiv>
+
+  <refsect1>
+    <title>Arguments</title>
+
+    <variablelist>
+      <varlistentry>
+	<term><parameter>fd</parameter></term>
+	<listitem>
+	  <para>&fd;</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>request</parameter></term>
+	<listitem>
+	  <para>VIDIOC_SUBDEV_ENUM_FRAME_SIZE</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>argp</parameter></term>
+	<listitem>
+	  <para></para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+
+  <refsect1>
+    <title>Description</title>
+
+    <note>
+      <title>Experimental</title>
+      <para>This is an <link linkend="experimental">experimental</link>
+      interface and may change in the future.</para>
+    </note>
+
+    <para>This ioctl allows applications to enumerate all frame sizes
+    supported by a sub-device on the given pad for the given media bus format.
+    Supported formats can be retrieved with the &VIDIOC-SUBDEV-ENUM-MBUS-CODE;
+    ioctl.</para>
+
+    <para>To enumerate frame sizes applications initialize the
+    <structfield>pad</structfield>, <structfield>code</structfield> and
+    <structfield>index</structfield> fields of the
+    &v4l2-subdev-mbus-code-enum; and call the
+    <constant>VIDIOC_SUBDEV_ENUM_FRAME_SIZE</constant> ioctl with a pointer to
+    the structure. Drivers fill the minimum and maximum frame sizes or return
+    an &EINVAL; if one of the input parameters is invalid.</para>
+
+    <para>Sub-devices that only support discrete frame sizes (such as most
+    sensors) will return one or more frame sizes with identical minimum and
+    maximum values.</para>
+
+    <para>Not all possible sizes in given [minimum, maximum] ranges need to be
+    supported. For instance, a scaler that uses a fixed-point scaling ratio
+    might not be able to produce every frame size between the minimum and
+    maximum values. Applications must use the &VIDIOC-SUBDEV-S-FMT; ioctl to
+    try the sub-device for an exact supported frame size.</para>
+
+    <para>Available frame sizes may depend on the current 'try' formats at other
+    pads of the sub-device, as well as on the current active links and the
+    current values of V4L2 controls. See &VIDIOC-SUBDEV-G-FMT; for more
+    information about try formats.</para>
+
+    <table pgwide="1" frame="none" id="v4l2-subdev-frame-size-enum">
+      <title>struct <structname>v4l2_subdev_frame_size_enum</structname></title>
+      <tgroup cols="3">
+	&cs-str;
+	<tbody valign="top">
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>index</structfield></entry>
+	    <entry>Number of the format in the enumeration, set by the
+	    application.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>pad</structfield></entry>
+	    <entry>Pad number as reported by the media controller API.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>code</structfield></entry>
+	    <entry>The media bus format code, as defined in
+	    <xref linkend="v4l2-mbus-format" />.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>min_width</structfield></entry>
+	    <entry>Minimum frame width, in pixels.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>max_width</structfield></entry>
+	    <entry>Maximum frame width, in pixels.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>min_height</structfield></entry>
+	    <entry>Minimum frame height, in pixels.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>max_height</structfield></entry>
+	    <entry>Maximum frame height, in pixels.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>reserved</structfield>[9]</entry>
+	    <entry>Reserved for future extensions. Applications and drivers must
+	    set the array to zero.</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+  </refsect1>
+
+  <refsect1>
+    &return-value;
+
+    <variablelist>
+      <varlistentry>
+	<term><errorcode>EINVAL</errorcode></term>
+	<listitem>
+	  <para>The &v4l2-subdev-frame-size-enum; <structfield>pad</structfield>
+	  references a non-existing pad, the <structfield>code</structfield> is
+	  invalid for the given pad or the <structfield>index</structfield>
+	  field is out of bounds.</para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+</refentry>

Documentation/DocBook/v4l/vidioc-subdev-enum-mbus-code.xml

@@ -0,0 +1,119 @@
+<refentry id="vidioc-subdev-enum-mbus-code">
+  <refmeta>
+    <refentrytitle>ioctl VIDIOC_SUBDEV_ENUM_MBUS_CODE</refentrytitle>
+    &manvol;
+  </refmeta>
+
+  <refnamediv>
+    <refname>VIDIOC_SUBDEV_ENUM_MBUS_CODE</refname>
+    <refpurpose>Enumerate media bus formats</refpurpose>
+  </refnamediv>
+
+  <refsynopsisdiv>
+    <funcsynopsis>
+      <funcprototype>
+	<funcdef>int <function>ioctl</function></funcdef>
+	<paramdef>int <parameter>fd</parameter></paramdef>
+	<paramdef>int <parameter>request</parameter></paramdef>
+	<paramdef>struct v4l2_subdev_mbus_code_enum *
+	<parameter>argp</parameter></paramdef>
+      </funcprototype>
+    </funcsynopsis>
+  </refsynopsisdiv>
+
+  <refsect1>
+    <title>Arguments</title>
+
+    <variablelist>
+      <varlistentry>
+	<term><parameter>fd</parameter></term>
+	<listitem>
+	  <para>&fd;</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>request</parameter></term>
+	<listitem>
+	  <para>VIDIOC_SUBDEV_ENUM_MBUS_CODE</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>argp</parameter></term>
+	<listitem>
+	  <para></para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+
+  <refsect1>
+    <title>Description</title>
+
+    <note>
+      <title>Experimental</title>
+      <para>This is an <link linkend="experimental">experimental</link>
+      interface and may change in the future.</para>
+    </note>
+
+    <para>To enumerate media bus formats available at a given sub-device pad
+    applications initialize the <structfield>pad</structfield> and
+    <structfield>index</structfield> fields of &v4l2-subdev-mbus-code-enum; and
+    call the <constant>VIDIOC_SUBDEV_ENUM_MBUS_CODE</constant> ioctl with a
+    pointer to this structure. Drivers fill the rest of the structure or return
+    an &EINVAL; if either the <structfield>pad</structfield> or
+    <structfield>index</structfield> are invalid. All media bus formats are
+    enumerable by beginning at index zero and incrementing by one until
+    <errorcode>EINVAL</errorcode> is returned.</para>
+
+    <para>Available media bus formats may depend on the current 'try' formats
+    at other pads of the sub-device, as well as on the current active links. See
+    &VIDIOC-SUBDEV-G-FMT; for more information about the try formats.</para>
+
+    <table pgwide="1" frame="none" id="v4l2-subdev-mbus-code-enum">
+      <title>struct <structname>v4l2_subdev_mbus_code_enum</structname></title>
+      <tgroup cols="3">
+	&cs-str;
+	<tbody valign="top">
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>pad</structfield></entry>
+	    <entry>Pad number as reported by the media controller API.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>index</structfield></entry>
+	    <entry>Number of the format in the enumeration, set by the
+	    application.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>code</structfield></entry>
+	    <entry>The media bus format code, as defined in
+	    <xref linkend="v4l2-mbus-format" />.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>reserved</structfield>[9]</entry>
+	    <entry>Reserved for future extensions. Applications and drivers must
+	    set the array to zero.</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+  </refsect1>
+
+  <refsect1>
+    &return-value;
+
+    <variablelist>
+      <varlistentry>
+	<term><errorcode>EINVAL</errorcode></term>
+	<listitem>
+	  <para>The &v4l2-subdev-mbus-code-enum; <structfield>pad</structfield>
+	  references a non-existing pad, or the <structfield>index</structfield>
+	  field is out of bounds.</para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+</refentry>

Documentation/DocBook/v4l/vidioc-subdev-g-crop.xml

@@ -0,0 +1,155 @@
+<refentry id="vidioc-subdev-g-crop">
+  <refmeta>
+    <refentrytitle>ioctl VIDIOC_SUBDEV_G_CROP, VIDIOC_SUBDEV_S_CROP</refentrytitle>
+    &manvol;
+  </refmeta>
+
+  <refnamediv>
+    <refname>VIDIOC_SUBDEV_G_CROP</refname>
+    <refname>VIDIOC_SUBDEV_S_CROP</refname>
+    <refpurpose>Get or set the crop rectangle on a subdev pad</refpurpose>
+  </refnamediv>
+
+  <refsynopsisdiv>
+    <funcsynopsis>
+      <funcprototype>
+	<funcdef>int <function>ioctl</function></funcdef>
+	<paramdef>int <parameter>fd</parameter></paramdef>
+	<paramdef>int <parameter>request</parameter></paramdef>
+	<paramdef>struct v4l2_subdev_crop *<parameter>argp</parameter></paramdef>
+      </funcprototype>
+    </funcsynopsis>
+    <funcsynopsis>
+      <funcprototype>
+	<funcdef>int <function>ioctl</function></funcdef>
+	<paramdef>int <parameter>fd</parameter></paramdef>
+	<paramdef>int <parameter>request</parameter></paramdef>
+	<paramdef>const struct v4l2_subdev_crop *<parameter>argp</parameter></paramdef>
+      </funcprototype>
+    </funcsynopsis>
+  </refsynopsisdiv>
+
+  <refsect1>
+    <title>Arguments</title>
+
+    <variablelist>
+      <varlistentry>
+	<term><parameter>fd</parameter></term>
+	<listitem>
+	  <para>&fd;</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>request</parameter></term>
+	<listitem>
+	  <para>VIDIOC_SUBDEV_G_CROP, VIDIOC_SUBDEV_S_CROP</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>argp</parameter></term>
+	<listitem>
+	  <para></para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+
+  <refsect1>
+    <title>Description</title>
+
+    <note>
+      <title>Experimental</title>
+      <para>This is an <link linkend="experimental">experimental</link>
+      interface and may change in the future.</para>
+    </note>
+
+    <para>To retrieve the current crop rectangle applications set the
+    <structfield>pad</structfield> field of a &v4l2-subdev-crop; to the
+    desired pad number as reported by the media API and the
+    <structfield>which</structfield> field to
+    <constant>V4L2_SUBDEV_FORMAT_ACTIVE</constant>. They then call the
+    <constant>VIDIOC_SUBDEV_G_CROP</constant> ioctl with a pointer to this
+    structure. The driver fills the members of the <structfield>rect</structfield>
+    field or returns &EINVAL; if the input arguments are invalid, or if cropping
+    is not supported on the given pad.</para>
+
+    <para>To change the current crop rectangle applications set both the
+    <structfield>pad</structfield> and <structfield>which</structfield> fields
+    and all members of the <structfield>rect</structfield> field. They then call
+    the <constant>VIDIOC_SUBDEV_S_CROP</constant> ioctl with a pointer to this
+    structure. The driver verifies the requested crop rectangle, adjusts it
+    based on the hardware capabilities and configures the device. Upon return
+    the &v4l2-subdev-crop; contains the current format as would be returned
+    by a <constant>VIDIOC_SUBDEV_G_CROP</constant> call.</para>
+
+    <para>Applications can query the device capabilities by setting the
+    <structfield>which</structfield> to
+    <constant>V4L2_SUBDEV_FORMAT_TRY</constant>. When set, 'try' crop
+    rectangles are not applied to the device by the driver, but are mangled
+    exactly as active crop rectangles and stored in the sub-device file handle.
+    Two applications querying the same sub-device would thus not interact with
+    each other.</para>
+
+    <para>Drivers must not return an error solely because the requested crop
+    rectangle doesn't match the device capabilities. They must instead modify
+    the rectangle to match what the hardware can provide. The modified format
+    should be as close as possible to the original request.</para>
+
+    <table pgwide="1" frame="none" id="v4l2-subdev-crop">
+      <title>struct <structname>v4l2_subdev_crop</structname></title>
+      <tgroup cols="3">
+        &cs-str;
+	<tbody valign="top">
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>pad</structfield></entry>
+	    <entry>Pad number as reported by the media framework.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>which</structfield></entry>
+	    <entry>Crop rectangle to get or set, from
+	    &v4l2-subdev-format-whence;.</entry>
+	  </row>
+	  <row>
+	    <entry>&v4l2-rect;</entry>
+	    <entry><structfield>rect</structfield></entry>
+	    <entry>Crop rectangle boundaries, in pixels.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>reserved</structfield>[8]</entry>
+	    <entry>Reserved for future extensions. Applications and drivers must
+	    set the array to zero.</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+  </refsect1>
+
+  <refsect1>
+    &return-value;
+
+    <variablelist>
+      <varlistentry>
+	<term><errorcode>EBUSY</errorcode></term>
+	<listitem>
+	  <para>The crop rectangle can't be changed because the pad is currently
+	  busy. This can be caused, for instance, by an active video stream on
+	  the pad. The ioctl must not be retried without performing another
+	  action to fix the problem first. Only returned by
+	  <constant>VIDIOC_SUBDEV_S_CROP</constant></para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><errorcode>EINVAL</errorcode></term>
+	<listitem>
+	  <para>The &v4l2-subdev-crop; <structfield>pad</structfield>
+	  references a non-existing pad, the <structfield>which</structfield>
+	  field references a non-existing format, or cropping is not supported
+	  on the given subdev pad.</para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+</refentry>

Documentation/DocBook/v4l/vidioc-subdev-g-fmt.xml

@@ -0,0 +1,180 @@
+<refentry id="vidioc-subdev-g-fmt">
+  <refmeta>
+    <refentrytitle>ioctl VIDIOC_SUBDEV_G_FMT, VIDIOC_SUBDEV_S_FMT</refentrytitle>
+    &manvol;
+  </refmeta>
+
+  <refnamediv>
+    <refname>VIDIOC_SUBDEV_G_FMT</refname>
+    <refname>VIDIOC_SUBDEV_S_FMT</refname>
+    <refpurpose>Get or set the data format on a subdev pad</refpurpose>
+  </refnamediv>
+
+  <refsynopsisdiv>
+    <funcsynopsis>
+      <funcprototype>
+	<funcdef>int <function>ioctl</function></funcdef>
+	<paramdef>int <parameter>fd</parameter></paramdef>
+	<paramdef>int <parameter>request</parameter></paramdef>
+	<paramdef>struct v4l2_subdev_format *<parameter>argp</parameter>
+	</paramdef>
+      </funcprototype>
+    </funcsynopsis>
+  </refsynopsisdiv>
+
+  <refsect1>
+    <title>Arguments</title>
+
+    <variablelist>
+      <varlistentry>
+	<term><parameter>fd</parameter></term>
+	<listitem>
+	  <para>&fd;</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>request</parameter></term>
+	<listitem>
+	  <para>VIDIOC_SUBDEV_G_FMT, VIDIOC_SUBDEV_S_FMT</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>argp</parameter></term>
+	<listitem>
+	  <para></para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+
+  <refsect1>
+    <title>Description</title>
+
+    <note>
+      <title>Experimental</title>
+      <para>This is an <link linkend="experimental">experimental</link>
+      interface and may change in the future.</para>
+    </note>
+
+    <para>These ioctls are used to negotiate the frame format at specific
+    subdev pads in the image pipeline.</para>
+
+    <para>To retrieve the current format applications set the
+    <structfield>pad</structfield> field of a &v4l2-subdev-format; to the
+    desired pad number as reported by the media API and the
+    <structfield>which</structfield> field to
+    <constant>V4L2_SUBDEV_FORMAT_ACTIVE</constant>. When they call the
+    <constant>VIDIOC_SUBDEV_G_FMT</constant> ioctl with a pointer to this
+    structure the driver fills the members of the <structfield>format</structfield>
+    field.</para>
+
+    <para>To change the current format applications set both the
+    <structfield>pad</structfield> and <structfield>which</structfield> fields
+    and all members of the <structfield>format</structfield> field. When they
+    call the <constant>VIDIOC_SUBDEV_S_FMT</constant> ioctl with a pointer to this
+    structure the driver verifies the requested format, adjusts it based on the
+    hardware capabilities and configures the device. Upon return the
+    &v4l2-subdev-format; contains the current format as would be returned by a
+    <constant>VIDIOC_SUBDEV_G_FMT</constant> call.</para>
+
+    <para>Applications can query the device capabilities by setting the
+    <structfield>which</structfield> to
+    <constant>V4L2_SUBDEV_FORMAT_TRY</constant>. When set, 'try' formats are not
+    applied to the device by the driver, but are changed exactly as active
+    formats and stored in the sub-device file handle. Two applications querying
+    the same sub-device would thus not interact with each other.</para>
+
+    <para>For instance, to try a format at the output pad of a sub-device,
+    applications would first set the try format at the sub-device input with the
+    <constant>VIDIOC_SUBDEV_S_FMT</constant> ioctl. They would then either
+    retrieve the default format at the output pad with the
+    <constant>VIDIOC_SUBDEV_G_FMT</constant> ioctl, or set the desired output
+    pad format with the <constant>VIDIOC_SUBDEV_S_FMT</constant> ioctl and check
+    the returned value.</para>
+
+    <para>Try formats do not depend on active formats, but can depend on the
+    current links configuration or sub-device controls value. For instance, a
+    low-pass noise filter might crop pixels at the frame boundaries, modifying
+    its output frame size.</para>
+
+    <para>Drivers must not return an error solely because the requested format
+    doesn't match the device capabilities. They must instead modify the format
+    to match what the hardware can provide. The modified format should be as
+    close as possible to the original request.</para>
+
+    <table pgwide="1" frame="none" id="v4l2-subdev-format">
+      <title>struct <structname>v4l2_subdev_format</structname></title>
+      <tgroup cols="3">
+        &cs-str;
+	<tbody valign="top">
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>pad</structfield></entry>
+	    <entry>Pad number as reported by the media controller API.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>which</structfield></entry>
+	    <entry>Format to modified, from &v4l2-subdev-format-whence;.</entry>
+	  </row>
+	  <row>
+	    <entry>&v4l2-mbus-framefmt;</entry>
+	    <entry><structfield>format</structfield></entry>
+	    <entry>Definition of an image format, see <xref
+	    linkend="v4l2-mbus-framefmt" /> for details.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>reserved</structfield>[8]</entry>
+	    <entry>Reserved for future extensions. Applications and drivers must
+	    set the array to zero.</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+
+    <table pgwide="1" frame="none" id="v4l2-subdev-format-whence">
+      <title>enum <structname>v4l2_subdev_format_whence</structname></title>
+      <tgroup cols="3">
+        &cs-def;
+	<tbody valign="top">
+	  <row>
+	    <entry>V4L2_SUBDEV_FORMAT_TRY</entry>
+	    <entry>0</entry>
+	    <entry>Try formats, used for querying device capabilities.</entry>
+	  </row>
+	  <row>
+	    <entry>V4L2_SUBDEV_FORMAT_ACTIVE</entry>
+	    <entry>1</entry>
+	    <entry>Active formats, applied to the hardware.</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+  </refsect1>
+
+  <refsect1>
+    &return-value;
+
+    <variablelist>
+      <varlistentry>
+	<term><errorcode>EBUSY</errorcode></term>
+	<listitem>
+	  <para>The format can't be changed because the pad is currently busy.
+	  This can be caused, for instance, by an active video stream on the
+	  pad. The ioctl must not be retried without performing another action
+	  to fix the problem first. Only returned by
+	  <constant>VIDIOC_SUBDEV_S_FMT</constant></para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><errorcode>EINVAL</errorcode></term>
+	<listitem>
+	  <para>The &v4l2-subdev-format; <structfield>pad</structfield>
+	  references a non-existing pad, or the <structfield>which</structfield>
+	  field references a non-existing format.</para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+</refentry>

Documentation/DocBook/v4l/vidioc-subdev-g-frame-interval.xml

@@ -0,0 +1,141 @@
+<refentry id="vidioc-subdev-g-frame-interval">
+  <refmeta>
+    <refentrytitle>ioctl VIDIOC_SUBDEV_G_FRAME_INTERVAL, VIDIOC_SUBDEV_S_FRAME_INTERVAL</refentrytitle>
+    &manvol;
+  </refmeta>
+
+  <refnamediv>
+    <refname>VIDIOC_SUBDEV_G_FRAME_INTERVAL</refname>
+    <refname>VIDIOC_SUBDEV_S_FRAME_INTERVAL</refname>
+    <refpurpose>Get or set the frame interval on a subdev pad</refpurpose>
+  </refnamediv>
+
+  <refsynopsisdiv>
+    <funcsynopsis>
+      <funcprototype>
+	<funcdef>int <function>ioctl</function></funcdef>
+	<paramdef>int <parameter>fd</parameter></paramdef>
+	<paramdef>int <parameter>request</parameter></paramdef>
+	<paramdef>struct v4l2_subdev_frame_interval *<parameter>argp</parameter>
+	</paramdef>
+      </funcprototype>
+    </funcsynopsis>
+  </refsynopsisdiv>
+
+  <refsect1>
+    <title>Arguments</title>
+
+    <variablelist>
+      <varlistentry>
+	<term><parameter>fd</parameter></term>
+	<listitem>
+	  <para>&fd;</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>request</parameter></term>
+	<listitem>
+	  <para>VIDIOC_SUBDEV_G_FRAME_INTERVAL, VIDIOC_SUBDEV_S_FRAME_INTERVAL</para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><parameter>argp</parameter></term>
+	<listitem>
+	  <para></para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+
+  <refsect1>
+    <title>Description</title>
+
+    <note>
+      <title>Experimental</title>
+      <para>This is an <link linkend="experimental">experimental</link>
+      interface and may change in the future.</para>
+    </note>
+
+    <para>These ioctls are used to get and set the frame interval at specific
+    subdev pads in the image pipeline. The frame interval only makes sense for
+    sub-devices that can control the frame period on their own. This includes,
+    for instance, image sensors and TV tuners. Sub-devices that don't support
+    frame intervals must not implement these ioctls.</para>
+
+    <para>To retrieve the current frame interval applications set the
+    <structfield>pad</structfield> field of a &v4l2-subdev-frame-interval; to
+    the desired pad number as reported by the media controller API. When they
+    call the <constant>VIDIOC_SUBDEV_G_FRAME_INTERVAL</constant> ioctl with a
+    pointer to this structure the driver fills the members of the
+    <structfield>interval</structfield> field.</para>
+
+    <para>To change the current frame interval applications set both the
+    <structfield>pad</structfield> field and all members of the
+    <structfield>interval</structfield> field. When they call the
+    <constant>VIDIOC_SUBDEV_S_FRAME_INTERVAL</constant> ioctl with a pointer to
+    this structure the driver verifies the requested interval, adjusts it based
+    on the hardware capabilities and configures the device. Upon return the
+    &v4l2-subdev-frame-interval; contains the current frame interval as would be
+    returned by a <constant>VIDIOC_SUBDEV_G_FRAME_INTERVAL</constant> call.
+    </para>
+
+    <para>Drivers must not return an error solely because the requested interval
+    doesn't match the device capabilities. They must instead modify the interval
+    to match what the hardware can provide. The modified interval should be as
+    close as possible to the original request.</para>
+
+    <para>Sub-devices that support the frame interval ioctls should implement
+    them on a single pad only. Their behaviour when supported on multiple pads
+    of the same sub-device is not defined.</para>
+
+    <table pgwide="1" frame="none" id="v4l2-subdev-frame-interval">
+      <title>struct <structname>v4l2_subdev_frame_interval</structname></title>
+      <tgroup cols="3">
+        &cs-str;
+	<tbody valign="top">
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>pad</structfield></entry>
+	    <entry>Pad number as reported by the media controller API.</entry>
+	  </row>
+	  <row>
+	    <entry>&v4l2-fract;</entry>
+	    <entry><structfield>interval</structfield></entry>
+	    <entry>Period, in seconds, between consecutive video frames.</entry>
+	  </row>
+	  <row>
+	    <entry>__u32</entry>
+	    <entry><structfield>reserved</structfield>[9]</entry>
+	    <entry>Reserved for future extensions. Applications and drivers must
+	    set the array to zero.</entry>
+	  </row>
+	</tbody>
+      </tgroup>
+    </table>
+  </refsect1>
+
+  <refsect1>
+    &return-value;
+
+    <variablelist>
+      <varlistentry>
+	<term><errorcode>EBUSY</errorcode></term>
+	<listitem>
+	  <para>The frame interval can't be changed because the pad is currently
+	  busy. This can be caused, for instance, by an active video stream on
+	  the pad. The ioctl must not be retried without performing another
+	  action to fix the problem first. Only returned by
+	  <constant>VIDIOC_SUBDEV_S_FRAME_INTERVAL</constant></para>
+	</listitem>
+      </varlistentry>
+      <varlistentry>
+	<term><errorcode>EINVAL</errorcode></term>
+	<listitem>
+	  <para>The &v4l2-subdev-frame-interval; <structfield>pad</structfield>
+	  references a non-existing pad, or the pad doesn't support frame
+	  intervals.</para>
+	</listitem>
+      </varlistentry>
+    </variablelist>
+  </refsect1>
+</refentry>

Documentation/acpi/apei/output_format.txt

@@ -92,6 +92,11 @@ vendor_id: <integer>, device_id: <integer>
 class_code: <integer>]
 [serial number: <integer>, <integer>]
 [bridge: secondary_status: <integer>, control: <integer>]
+[aer_status: <integer>, aer_mask: <integer>
+<aer status string>
+[aer_uncor_severity: <integer>]
+aer_layer=<aer layer string>, aer_agent=<aer agent string>
+aer_tlp_header: <integer> <integer> <integer> <integer>]

 <pcie port type string>* := PCIe end point | legacy PCI end point | \
 unknown | unknown | root port | upstream switch port | \
@@ -99,6 +104,26 @@ downstream switch port | PCIe to PCI/PCI-X bridge | \
 PCI/PCI-X to PCIe bridge | root complex integrated endpoint device | \
 root complex event collector

+if section severity is fatal or recoverable
+<aer status string># :=
+unknown | unknown | unknown | unknown | Data Link Protocol | \
+unknown | unknown | unknown | unknown | unknown | unknown | unknown | \
+Poisoned TLP | Flow Control Protocol | Completion Timeout | \
+Completer Abort | Unexpected Completion | Receiver Overflow | \
+Malformed TLP | ECRC | Unsupported Request
+else
+<aer status string># :=
+Receiver Error | unknown | unknown | unknown | unknown | unknown | \
+Bad TLP | Bad DLLP | RELAY_NUM Rollover | unknown | unknown | unknown | \
+Replay Timer Timeout | Advisory Non-Fatal
+fi
+
+<aer layer string> :=
+Physical Layer | Data Link Layer | Transaction Layer
+
+<aer agent string> :=
+Receiver ID | Requester ID | Completer ID | Transmitter ID
+
 Where, [] designate corresponding content is optional

 All <field string> description with * has the following format:

Documentation/block/biodoc.txt

@@ -963,11 +963,6 @@ elevator_dispatch_fn*		fills the dispatch queue with ready requests.

 elevator_add_req_fn*		called to add a new request into the scheduler

-elevator_queue_empty_fn		returns true if the merge queue is empty.
-				Drivers shouldn't use this, but rather check
-				if elv_next_request is NULL (without losing the
-				request if one exists!)
-
 elevator_former_req_fn
 elevator_latter_req_fn		These return the request before or after the
 				one specified in disk sort order. Used by the

Documentation/cgroups/blkio-controller.txt

@@ -140,7 +140,7 @@ Proportional weight policy files
 	- Specifies per cgroup weight. This is default weight of the group
 	  on all the devices until and unless overridden by per device rule.
 	  (See blkio.weight_device).
-	  Currently allowed range of weights is from 100 to 1000.
+	  Currently allowed range of weights is from 10 to 1000.

 - blkio.weight_device
 	- One can specify per cgroup per device rules using this interface.
@@ -343,34 +343,6 @@ Common files among various policies

 CFQ sysfs tunable
 =================
-/sys/block/<disk>/queue/iosched/group_isolation
------------------------------------------------
-
-If group_isolation=1, it provides stronger isolation between groups at the
-expense of throughput. By default group_isolation is 0. In general that
-means that if group_isolation=0, expect fairness for sequential workload
-only. Set group_isolation=1 to see fairness for random IO workload also.
-
-Generally CFQ will put random seeky workload in sync-noidle category. CFQ
-will disable idling on these queues and it does a collective idling on group
-of such queues. Generally these are slow moving queues and if there is a
-sync-noidle service tree in each group, that group gets exclusive access to
-disk for certain period. That means it will bring the throughput down if
-group does not have enough IO to drive deeper queue depths and utilize disk
-capacity to the fullest in the slice allocated to it. But the flip side is
-that even a random reader should get better latencies and overall throughput
-if there are lots of sequential readers/sync-idle workload running in the
-system.
-
-If group_isolation=0, then CFQ automatically moves all the random seeky queues
-in the root group. That means there will be no service differentiation for
-that kind of workload. This leads to better throughput as we do collective
-idling on root sync-noidle tree.
-
-By default one should run with group_isolation=0. If that is not sufficient
-and one wants stronger isolation between groups, then set group_isolation=1
-but this will come at cost of reduced throughput.
-
 /sys/block/<disk>/queue/iosched/slice_idle
 ------------------------------------------
 On a faster hardware CFQ can be slow, especially with sequential workload.

Documentation/development-process/1.Intro

@@ -56,13 +56,13 @@ information on kernel development.

 1.2: WHAT THIS DOCUMENT IS ABOUT

-The Linux kernel, at over 6 million lines of code and well over 1000 active
-contributors, is one of the largest and most active free software projects
-in existence.  Since its humble beginning in 1991, this kernel has evolved
-into a best-of-breed operating system component which runs on pocket-sized
-digital music players, desktop PCs, the largest supercomputers in
-existence, and all types of systems in between.  It is a robust, efficient,
-and scalable solution for almost any situation.
+The Linux kernel, at over 8 million lines of code and well over 1000
+contributors to each release, is one of the largest and most active free
+software projects in existence.  Since its humble beginning in 1991, this
+kernel has evolved into a best-of-breed operating system component which
+runs on pocket-sized digital music players, desktop PCs, the largest
+supercomputers in existence, and all types of systems in between.  It is a
+robust, efficient, and scalable solution for almost any situation.

 With the growth of Linux has come an increase in the number of developers
 (and companies) wishing to participate in its development.  Hardware
@@ -115,7 +115,7 @@ This document was written by Jonathan Corbet, corbet@lwn.net.  It has been
 improved by comments from Johannes Berg, James Berry, Alex Chiang, Roland
 Dreier, Randy Dunlap, Jake Edge, Jiri Kosina, Matt Mackall, Arthur Marsh,
 Amanda McPherson, Andrew Morton, Andrew Price, Tsugikazu Shibata, and
-Jochen Voß.
+Jochen Voß.

 This work was supported by the Linux Foundation; thanks especially to
 Amanda McPherson, who saw the value of this effort and made it all happen.
@@ -221,7 +221,7 @@ include:
 - Everything that was said above about code review applies doubly to
   closed-source code.  Since this code is not available at all, it cannot
   have been reviewed by the community and will, beyond doubt, have serious
-  problems.
+  problems.

 Makers of embedded systems, in particular, may be tempted to disregard much
 of what has been said in this section in the belief that they are shipping

Documentation/development-process/2.Process

@@ -14,16 +14,15 @@ The kernel developers use a loosely time-based release process, with a new
 major kernel release happening every two or three months.  The recent
 release history looks like this:

-	2.6.26	July 13, 2008
-	2.6.25	April 16, 2008
-	2.6.24	January 24, 2008
-	2.6.23	October 9, 2007
-	2.6.22	July 8, 2007
-	2.6.21	April 25, 2007
-	2.6.20	February 4, 2007
+	2.6.38	March 14, 2011
+	2.6.37	January 4, 2011
+	2.6.36	October 20, 2010
+	2.6.35	August 1, 2010
+	2.6.34	May 15, 2010
+	2.6.33	February 24, 2010

 Every 2.6.x release is a major kernel release with new features, internal
-API changes, and more.  A typical 2.6 release can contain over 10,000
+API changes, and more.  A typical 2.6 release can contain nearly 10,000
 changesets with changes to several hundred thousand lines of code.  2.6 is
 thus the leading edge of Linux kernel development; the kernel uses a
 rolling development model which is continually integrating major changes.
@@ -42,13 +41,13 @@ merge window do not come out of thin air; they have been collected, tested,
 and staged ahead of time.  How that process works will be described in
 detail later on).

-The merge window lasts for two weeks.  At the end of this time, Linus
-Torvalds will declare that the window is closed and release the first of
-the "rc" kernels.  For the kernel which is destined to be 2.6.26, for
-example, the release which happens at the end of the merge window will be
-called 2.6.26-rc1.  The -rc1 release is the signal that the time to merge
-new features has passed, and that the time to stabilize the next kernel has
-begun.
+The merge window lasts for approximately two weeks.  At the end of this
+time, Linus Torvalds will declare that the window is closed and release the
+first of the "rc" kernels.  For the kernel which is destined to be 2.6.40,
+for example, the release which happens at the end of the merge window will
+be called 2.6.40-rc1.  The -rc1 release is the signal that the time to
+merge new features has passed, and that the time to stabilize the next
+kernel has begun.

 Over the next six to ten weeks, only patches which fix problems should be
 submitted to the mainline.  On occasion a more significant change will be
@@ -66,20 +65,19 @@ will get up to somewhere between -rc6 and -rc9 before the kernel is
 considered to be sufficiently stable and the final 2.6.x release is made.
 At that point the whole process starts over again.

-As an example, here is how the 2.6.25 development cycle went (all dates in
-2008):
-
-	January 24	2.6.24 stable release
-	February 10	2.6.25-rc1, merge window closes
-	February 15	2.6.25-rc2
-	February 24	2.6.25-rc3
-	March 4	 	2.6.25-rc4
-	March 9		2.6.25-rc5
-	March 16	2.6.25-rc6
-	March 25	2.6.25-rc7
-	April 1		2.6.25-rc8
-	April 11	2.6.25-rc9
-	April 16	2.6.25 stable release
+As an example, here is how the 2.6.38 development cycle went (all dates in
+2011):
+
+	January 4	2.6.37 stable release
+	January 18	2.6.38-rc1, merge window closes
+	January 21	2.6.38-rc2
+	February 1	2.6.38-rc3
+	February 7	2.6.38-rc4
+	February 15	2.6.38-rc5
+	February 21	2.6.38-rc6
+	March 1		2.6.38-rc7
+	March 7		2.6.38-rc8
+	March 14	2.6.38 stable release

 How do the developers decide when to close the development cycle and create
 the stable release?  The most significant metric used is the list of
@@ -87,7 +85,7 @@ regressions from previous releases.  No bugs are welcome, but those which
 break systems which worked in the past are considered to be especially
 serious.  For this reason, patches which cause regressions are looked upon
 unfavorably and are quite likely to be reverted during the stabilization
-period.
+period.

 The developers' goal is to fix all known regressions before the stable
 release is made.  In the real world, this kind of perfection is hard to
@@ -99,26 +97,34 @@ kernels go out with a handful of known regressions though, hopefully, none
 of them are serious.

 Once a stable release is made, its ongoing maintenance is passed off to the
-"stable team," currently comprised of Greg Kroah-Hartman and Chris Wright.
-The stable team will release occasional updates to the stable release using
-the 2.6.x.y numbering scheme.  To be considered for an update release, a
-patch must (1) fix a significant bug, and (2) already be merged into the
-mainline for the next development kernel.  Continuing our 2.6.25 example,
-the history (as of this writing) is:
-
-	May 1		2.6.25.1
-	May 6		2.6.25.2
-	May 9		2.6.25.3
-	May 15		2.6.25.4
-	June 7		2.6.25.5
-	June 9		2.6.25.6
-	June 16		2.6.25.7
-	June 21		2.6.25.8
-	June 24		2.6.25.9
-
-Stable updates for a given kernel are made for approximately six months;
-after that, the maintenance of stable releases is solely the responsibility
-of the distributors which have shipped that particular kernel.
+"stable team," currently consisting of Greg Kroah-Hartman.  The stable team
+will release occasional updates to the stable release using the 2.6.x.y
+numbering scheme.  To be considered for an update release, a patch must (1)
+fix a significant bug, and (2) already be merged into the mainline for the
+next development kernel.  Kernels will typically receive stable updates for
+a little more than one development cycle past their initial release.  So,
+for example, the 2.6.36 kernel's history looked like:
+
+	October 10	2.6.36 stable release
+	November 22	2.6.36.1
+	December 9	2.6.36.2
+	January 7	2.6.36.3
+	February 17	2.6.36.4
+
+2.6.36.4 was the final stable update for the 2.6.36 release.
+
+Some kernels are designated "long term" kernels; they will receive support
+for a longer period.  As of this writing, the current long term kernels
+and their maintainers are:
+
+	2.6.27	Willy Tarreau		(Deep-frozen stable kernel)
+	2.6.32	Greg Kroah-Hartman
+	2.6.35	Andi Kleen		(Embedded flag kernel)
+
+The selection of a kernel for long-term support is purely a matter of a
+maintainer having the need and the time to maintain that release.  There
+are no known plans for long-term support for any specific upcoming
+release.


 2.2: THE LIFECYCLE OF A PATCH
@@ -130,7 +136,7 @@ each patch implements a change which is desirable to have in the mainline.
 This process can happen quickly for minor fixes, or, in the case of large
 and controversial changes, go on for years.  Much developer frustration
 comes from a lack of understanding of this process or from attempts to
-circumvent it.
+circumvent it.

 In the hopes of reducing that frustration, this document will describe how
 a patch gets into the kernel.  What follows below is an introduction which
@@ -193,8 +199,8 @@ involved.
 2.3: HOW PATCHES GET INTO THE KERNEL

 There is exactly one person who can merge patches into the mainline kernel
-repository: Linus Torvalds.  But, of the over 12,000 patches which went
-into the 2.6.25 kernel, only 250 (around 2%) were directly chosen by Linus
+repository: Linus Torvalds.  But, of the over 9,500 patches which went
+into the 2.6.38 kernel, only 112 (around 1.3%) were directly chosen by Linus
 himself.  The kernel project has long since grown to a size where no single
 developer could possibly inspect and select every patch unassisted.  The
 way the kernel developers have addressed this growth is through the use of
@@ -229,7 +235,7 @@ first in trees dedicated to network device drivers, wireless networking,
 etc.  This chain of repositories can be arbitrarily long, though it rarely
 exceeds two or three links.  Since each maintainer in the chain trusts
 those managing lower-level trees, this process is known as the "chain of
-trust."
+trust."

 Clearly, in a system like this, getting patches into the kernel depends on
 finding the right maintainer.  Sending patches directly to Linus is not
@@ -254,7 +260,7 @@ The answer comes in the form of -next trees, where subsystem trees are
 collected for testing and review.  The older of these trees, maintained by
 Andrew Morton, is called "-mm" (for memory management, which is how it got
 started).  The -mm tree integrates patches from a long list of subsystem
-trees; it also has some patches aimed at helping with debugging.
+trees; it also has some patches aimed at helping with debugging.

 Beyond that, -mm contains a significant collection of patches which have
 been selected by Andrew directly.  These patches may have been posted on a
@@ -264,8 +270,8 @@ subsystem tree of last resort; if there is no other obvious path for a
 patch into the mainline, it is likely to end up in -mm.  Miscellaneous
 patches which accumulate in -mm will eventually either be forwarded on to
 an appropriate subsystem tree or be sent directly to Linus.  In a typical
-development cycle, approximately 10% of the patches going into the mainline
-get there via -mm.
+development cycle, approximately 5-10% of the patches going into the
+mainline get there via -mm.

 The current -mm patch is available in the "mmotm" (-mm of the moment)
 directory at:
@@ -275,7 +281,7 @@ directory at:
 Use of the MMOTM tree is likely to be a frustrating experience, though;
 there is a definite chance that it will not even compile.

-The other -next tree, started more recently, is linux-next, maintained by
+The primary tree for next-cycle patch merging is linux-next, maintained by
 Stephen Rothwell.  The linux-next tree is, by design, a snapshot of what
 the mainline is expected to look like after the next merge window closes.
 Linux-next trees are announced on the linux-kernel and linux-next mailing
@@ -287,25 +293,14 @@ Some information about linux-next has been gathered at:

 	http://linux.f-seidel.de/linux-next/pmwiki/

-How the linux-next tree will fit into the development process is still
-changing.  As of this writing, the first full development cycle involving
-linux-next (2.6.26) is coming to an end; thus far, it has proved to be a
-valuable resource for finding and fixing integration problems before the
-beginning of the merge window.  See http://lwn.net/Articles/287155/ for
-more information on how linux-next has worked to set up the 2.6.27 merge
-window.
-
-Some developers have begun to suggest that linux-next should be used as the
-target for future development as well.  The linux-next tree does tend to be
-far ahead of the mainline and is more representative of the tree into which
-any new work will be merged.  The downside to this idea is that the
-volatility of linux-next tends to make it a difficult development target.
-See http://lwn.net/Articles/289013/ for more information on this topic, and
-stay tuned; much is still in flux where linux-next is involved.
+Linux-next has become an integral part of the kernel development process;
+all patches merged during a given merge window should really have found
+their way into linux-next some time before the merge window opens.
+

 2.4.1: STAGING TREES

-The kernel source tree now contains the drivers/staging/ directory, where
+The kernel source tree contains the drivers/staging/ directory, where
 many sub-directories for drivers or filesystems that are on their way to
 being added to the kernel tree live.  They remain in drivers/staging while
 they still need more work; once complete, they can be moved into the
@@ -313,15 +308,23 @@ kernel proper.  This is a way to keep track of drivers that aren't
 up to Linux kernel coding or quality standards, but people may want to use
 them and track development.

-Greg Kroah-Hartman currently (as of 2.6.36) maintains the staging tree.
-Drivers that still need work are sent to him, with each driver having
-its own subdirectory in drivers/staging/.  Along with the driver source
-files, a TODO file should be present in the directory as well.  The TODO
-file lists the pending work that the driver needs for acceptance into
-the kernel proper, as well as a list of people that should be Cc'd for any
-patches to the driver.  Staging drivers that don't currently build should
-have their config entries depend upon CONFIG_BROKEN.  Once they can
-be successfully built without outside patches, CONFIG_BROKEN can be removed.
+Greg Kroah-Hartman currently maintains the staging tree.  Drivers that
+still need work are sent to him, with each driver having its own
+subdirectory in drivers/staging/.  Along with the driver source files, a
+TODO file should be present in the directory as well.  The TODO file lists
+the pending work that the driver needs for acceptance into the kernel
+proper, as well as a list of people that should be Cc'd for any patches to
+the driver.  Current rules require that drivers contributed to staging
+must, at a minimum, compile properly.
+
+Staging can be a relatively easy way to get new drivers into the mainline
+where, with luck, they will come to the attention of other developers and
+improve quickly.  Entry into staging is not the end of the story, though;
+code in staging which is not seeing regular progress will eventually be
+removed.  Distributors also tend to be relatively reluctant to enable
+staging drivers.  So staging is, at best, a stop on the way toward becoming
+a proper mainline driver.
+

 2.5: TOOLS

@@ -347,11 +350,7 @@ page at:

 	http://git-scm.com/

-That page has pointers to documentation and tutorials.  One should be
-aware, in particular, of the Kernel Hacker's Guide to git, which has
-information specific to kernel development:
-
-	http://linux.yyz.us/git-howto.html
+That page has pointers to documentation and tutorials.

 Among the kernel developers who do not use git, the most popular choice is
 almost certainly Mercurial:
@@ -408,7 +407,7 @@ There are a few hints which can help with linux-kernel survival:
   important to filter on both the topic of interest (though note that
   long-running conversations can drift away from the original subject
   without changing the email subject line) and the people who are
-  participating.
+  participating.

 - Do not feed the trolls.  If somebody is trying to stir up an angry
   response, ignore them.

Documentation/development-process/3.Early-stage

@@ -110,8 +110,8 @@ the kernel community's standards.  Some examples include:

  - The AppArmor security module made use of internal virtual filesystem
    data structures in ways which were considered to be unsafe and
-   unreliable.  This code has since been significantly reworked, but
-   remains outside of the mainline.
+   unreliable.  This concern (among others) kept AppArmor out of the
+   mainline for years.

 In each of these cases, a great deal of pain and extra work could have been
 avoided with some early discussion with the kernel developers.
@@ -138,6 +138,19 @@ patches, and who, if anybody, is attaching Signed-off-by lines to those
 patches.  Those are the people who will be best placed to help with a new
 development project.

+The task of finding the right maintainer is sometimes challenging enough
+that the kernel developers have added a script to ease the process:
+
+	.../scripts/get_maintainer.pl
+
+This script will return the current maintainer(s) for a given file or
+directory when given the "-f" option.  If passed a patch on the
+command line, it will list the maintainers who should probably receive
+copies of the patch.  There are a number of options regulating how hard
+get_maintainer.pl will search for maintainers; please be careful about
+using the more aggressive options as you may end up including developers
+who have no real interest in the code you are modifying.
+
 If all else fails, talking to Andrew Morton can be an effective way to
 track down a maintainer for a specific piece of code.

@@ -155,11 +168,15 @@ reaction, but, instead, little or no reaction at all.  The sad truth of the
 matter is (1) kernel developers tend to be busy, (2) there is no shortage
 of people with grand plans and little code (or even prospect of code) to
 back them up, and (3) nobody is obligated to review or comment on ideas
-posted by others.  If a request-for-comments posting yields little in the
-way of comments, do not assume that it means there is no interest in the
-project.  Unfortunately, you also cannot assume that there are no problems
-with your idea.  The best thing to do in this situation is to proceed,
-keeping the community informed as you go.
+posted by others.  Beyond that, high-level designs often hide problems
+which are only reviewed when somebody actually tries to implement those
+designs; for that reason, kernel developers would rather see the code.
+
+If a request-for-comments posting yields little in the way of comments, do
+not assume that it means there is no interest in the project.
+Unfortunately, you also cannot assume that there are no problems with your
+idea.  The best thing to do in this situation is to proceed, keeping the
+community informed as you go.


 3.5: GETTING OFFICIAL BUY-IN

Documentation/development-process/4.Coding

@@ -131,6 +131,11 @@ classic time/space tradeoff taught in beginning data structures classes
 often does not apply to contemporary hardware.  Space *is* time, in that a
 larger program will run slower than one which is more compact.

+More recent compilers take an increasingly active role in deciding whether
+a given function should actually be inlined or not.  So the liberal
+placement of "inline" keywords may not just be excessive; it could also be
+irrelevant.
+

 * Locking

@@ -285,6 +290,13 @@ be found at https://sparse.wiki.kernel.org/index.php/Main_Page if your
 distributor does not package it); it can then be run on the code by adding
 "C=1" to your make command.

+The "Coccinelle" tool (http://coccinelle.lip6.fr/) is able to find a wide
+variety of potential coding problems; it can also propose fixes for those
+problems.  Quite a few "semantic patches" for the kernel have been packaged
+under the scripts/coccinelle directory; running "make coccicheck" will run
+through those semantic patches and report on any problems found.  See
+Documentation/coccinelle.txt for more information.
+
 Other kinds of portability errors are best found by compiling your code for
 other architectures.  If you do not happen to have an S/390 system or a
 Blackfin development board handy, you can still perform the compilation
@@ -308,7 +320,9 @@ The first piece of documentation for any patch is its associated
 changelog.  Log entries should describe the problem being solved, the form
 of the solution, the people who worked on the patch, any relevant
 effects on performance, and anything else that might be needed to
-understand the patch.
+understand the patch.  Be sure that the changelog says *why* the patch is
+worth applying; a surprising number of developers fail to provide that
+information.

 Any code which adds a new user-space interface - including new sysfs or
 /proc files - should include documentation of that interface which enables
@@ -321,7 +335,7 @@ boot-time parameters.  Any patch which adds new parameters should add the
 appropriate entries to this file.

 Any new configuration options must be accompanied by help text which
-clearly explains the options and when the user might want to select them.
+clearly explains the options and when the user might want to select them.

 Internal API information for many subsystems is documented by way of
 specially-formatted comments; these comments can be extracted and formatted
@@ -372,7 +386,8 @@ which is broken by the change.  For a widely-used function, this duty can
 lead to literally hundreds or thousands of changes - many of which are
 likely to conflict with work being done by other developers.  Needless to
 say, this can be a large job, so it is best to be sure that the
-justification is solid.
+justification is solid.  Note that the Coccinelle tool can help with
+wide-ranging API changes.

 When making an incompatible API change, one should, whenever possible,
 ensure that code which has not been updated is caught by the compiler.

Documentation/development-process/5.Posting

@@ -60,12 +60,15 @@ even in the short term.

 Patches must be prepared against a specific version of the kernel.  As a
 general rule, a patch should be based on the current mainline as found in
-Linus's git tree.  It may become necessary to make versions against -mm,
-linux-next, or a subsystem tree, though, to facilitate wider testing and
-review.  Depending on the area of your patch and what is going on
-elsewhere, basing a patch against these other trees can require a
-significant amount of work resolving conflicts and dealing with API
-changes.
+Linus's git tree.  When basing on mainline, start with a well-known release
+point - a stable or -rc release - rather than branching off the mainline at
+an arbitrary spot.
+
+It may become necessary to make versions against -mm, linux-next, or a
+subsystem tree, though, to facilitate wider testing and review.  Depending
+on the area of your patch and what is going on elsewhere, basing a patch
+against these other trees can require a significant amount of work
+resolving conflicts and dealing with API changes.

 Only the most simple changes should be formatted as a single patch;
 everything else should be made as a logical series of changes.  Splitting
@@ -100,11 +103,11 @@ rules of thumb, however, which can help considerably:
    result is a broken kernel, you will make life harder for developers and
    users who are engaging in the noble work of tracking down problems.

- - Do not overdo it, though.  One developer recently posted a set of edits
+ - Do not overdo it, though.  One developer once posted a set of edits
    to a single file as 500 separate patches - an act which did not make him
    the most popular person on the kernel mailing list.  A single patch can
    be reasonably large as long as it still contains a single *logical*
-   change.
+   change.

  - It can be tempting to add a whole new infrastructure with a series of
    patches, but to leave that infrastructure unused until the final patch
@@ -162,7 +165,8 @@ To that end, the summary line should describe the effects of and motivation
 for the change as well as possible given the one-line constraint.  The
 detailed description can then amplify on those topics and provide any
 needed additional information.  If the patch fixes a bug, cite the commit
-which introduced the bug if possible.  If a problem is associated with
+which introduced the bug if possible (and please provide both the commit ID
+and the title when citing commits).  If a problem is associated with
 specific log or compiler output, include that output to help others
 searching for a solution to the same problem.  If the change is meant to
 support other changes coming in later patch, say so.  If internal APIs are
@@ -230,7 +234,7 @@ take care of:
    which have had gratuitous white-space changes or line wrapping performed
    by the mail client will not apply at the other end, and often will not
    be examined in any detail.  If there is any doubt at all, mail the patch
-   to yourself and convince yourself that it shows up intact.
+   to yourself and convince yourself that it shows up intact.

    Documentation/email-clients.txt has some helpful hints on making
    specific mail clients work for sending patches.
@@ -287,7 +291,7 @@ something like:

 where "nn" is the ordinal number of the patch, "mm" is the total number of
 patches in the series, and "subsys" is the name of the affected subsystem.
-Clearly, nn/mm can be omitted for a single, standalone patch.
+Clearly, nn/mm can be omitted for a single, standalone patch.

 If you have a significant series of patches, it is customary to send an
 introductory description as part zero.  This convention is not universally
@@ -299,5 +303,5 @@ In general, the second and following parts of a multi-part patch should be
 sent as a reply to the first part so that they all thread together at the
 receiving end.  Tools like git and quilt have commands to mail out a set of
 patches with the proper threading.  If you have a long series, though, and
-are using git, please provide the --no-chain-reply-to option to avoid
+are using git, please stay away from the --chain-reply-to option to avoid
 creating exceptionally deep nesting.

Documentation/development-process/6.Followthrough

@@ -66,6 +66,11 @@ be easy to become blinded by your own solution to a problem to the point
 that you don't realize that something is fundamentally wrong or, perhaps,
 you're not even solving the right problem.

+Andrew Morton has suggested that every review comment which does not result
+in a code change should result in an additional code comment instead; that
+can help future reviewers avoid the questions which came up the first time
+around.
+
 One fatal mistake is to ignore review comments in the hope that they will
 go away.  They will not go away.  If you repost code without having
 responded to the comments you got the time before, you're likely to find
@@ -100,7 +105,7 @@ entry into a subsystem maintainer's tree.  How that works varies from one
 subsystem to the next; each maintainer has his or her own way of doing
 things.  In particular, there may be more than one tree - one, perhaps,
 dedicated to patches planned for the next merge window, and another for
-longer-term work.
+longer-term work.

 For patches applying to areas for which there is no obvious subsystem tree
 (memory management patches, for example), the default tree often ends up
@@ -109,11 +114,10 @@ through the -mm tree.

 Inclusion into a subsystem tree can bring a higher level of visibility to a
 patch.  Now other developers working with that tree will get the patch by
-default.  Subsystem trees typically feed into -mm and linux-next as well,
-making their contents visible to the development community as a whole.  At
-this point, there's a good chance that you will get more comments from a
-new set of reviewers; these comments need to be answered as in the previous
-round.
+default.  Subsystem trees typically feed linux-next as well, making their
+contents visible to the development community as a whole.  At this point,
+there's a good chance that you will get more comments from a new set of
+reviewers; these comments need to be answered as in the previous round.

 What may also happen at this point, depending on the nature of your patch,
 is that conflicts with work being done by others turn up.  In the worst

Documentation/development-process/7.AdvancedTopics

@@ -119,7 +119,7 @@ can affect your ability to get trees pulled in the future.  Quoting Linus:
 	to trust things *without* then having to go and check every
 	individual change by hand.

-(http://lwn.net/Articles/224135/).
+(http://lwn.net/Articles/224135/).

 To avoid this kind of situation, ensure that all patches within a given
 branch stick closely to the associated topic; a "driver fixes" branch
@@ -138,7 +138,7 @@ When requesting a pull, be sure to give all the relevant information: where
 your tree is, what branch to pull, and what changes will result from the
 pull.  The git request-pull command can be helpful in this regard; it will
 format the request as other developers expect, and will also check to be
-sure that you have remembered to push those changes to the public server.
+sure that you have remembered to push those changes to the public server.


 7.2: REVIEWING PATCHES

Documentation/device-mapper/dm-flakey.txt

@@ -0,0 +1,17 @@
+dm-flakey
+=========
+
+This target is the same as the linear target except that it returns I/O
+errors periodically.  It's been found useful in simulating failing
+devices for testing purposes.
+
+Starting from the time the table is loaded, the device is available for
+<up interval> seconds, then returns errors for <down interval> seconds,
+and then this cycle repeats.
+
+Parameters: <dev path> <offset> <up interval> <down interval>
+    <dev path>: Full pathname to the underlying block-device, or a
+                "major:minor" device-number.
+    <offset>: Starting sector within the device.
+    <up interval>: Number of seconds device is available.
+    <down interval>: Number of seconds device returns errors.

Documentation/devicetree/bindings/fb/sm501fb.txt

@@ -0,0 +1,34 @@
+* SM SM501
+
+The SM SM501 is a LCD controller, with proper hardware, it can also
+drive DVI monitors.
+
+Required properties:
+- compatible : should be "smi,sm501".
+- reg : contain two entries:
+    - First entry: System Configuration register
+    - Second entry: IO space (Display Controller register)
+- interrupts : SMI interrupt to the cpu should be described here.
+- interrupt-parent : the phandle for the interrupt controller that
+  services interrupts for this device.
+
+Optional properties:
+- mode : select a video mode:
+    <xres>x<yres>[-<bpp>][@<refresh>]
+- edid : verbatim EDID data block describing attached display.
+  Data from the detailed timing descriptor will be used to
+  program the display controller.
+- little-endian: availiable on big endian systems, to
+  set different foreign endian.
+- big-endian: availiable on little endian systems, to
+  set different foreign endian.
+
+Example for MPC5200:
+	display@1,0 {
+		compatible = "smi,sm501";
+		reg = <1 0x00000000 0x00800000
+		       1 0x03e00000 0x00200000>;
+		interrupts = <1 1 3>;
+		mode = "640x480-32@60";
+		edid = [edid-data];
+	};

Documentation/devicetree/bindings/hwmon/ads1015.txt

@@ -0,0 +1,73 @@
+ADS1015 (I2C)
+
+This device is a 12-bit A-D converter with 4 inputs.
+
+The inputs can be used single ended or in certain differential combinations.
+
+For configuration all possible combinations are mapped to 8 channels:
+  0: Voltage over AIN0 and AIN1.
+  1: Voltage over AIN0 and AIN3.
+  2: Voltage over AIN1 and AIN3.
+  3: Voltage over AIN2 and AIN3.
+  4: Voltage over AIN0 and GND.
+  5: Voltage over AIN1 and GND.
+  6: Voltage over AIN2 and GND.
+  7: Voltage over AIN3 and GND.
+
+Each channel can be configured individually:
+ - pga is the programmable gain amplifier (values are full scale)
+    0: +/- 6.144 V
+    1: +/- 4.096 V
+    2: +/- 2.048 V (default)
+    3: +/- 1.024 V
+    4: +/- 0.512 V
+    5: +/- 0.256 V
+ - data_rate in samples per second
+    0: 128
+    1: 250
+    2: 490
+    3: 920
+    4: 1600 (default)
+    5: 2400
+    6: 3300
+
+1) The /ads1015 node
+
+  Required properties:
+
+   - compatible : must be "ti,ads1015"
+   - reg : I2C bus address of the device
+   - #address-cells : must be <1>
+   - #size-cells : must be <0>
+
+  The node contains child nodes for each channel that the platform uses.
+
+  Example ADS1015 node:
+
+    ads1015@49 {
+	    compatible = "ti,ads1015";
+	    reg = <0x49>;
+	    #address-cells = <1>;
+	    #size-cells = <0>;
+
+	    [ child node definitions... ]
+    }
+
+2) channel nodes
+
+  Required properties:
+
+   - reg : the channel number
+
+  Optional properties:
+
+   - ti,gain : the programmable gain amplifier setting
+   - ti,datarate : the converter data rate
+
+  Example ADS1015 channel node:
+
+    channel@4 {
+	    reg = <4>;
+	    ti,gain = <3>;
+	    ti,datarate = <5>;
+    };

Documentation/devicetree/bindings/open-pic.txt

@@ -0,0 +1,98 @@
+* Open PIC Binding
+
+This binding specifies what properties must be available in the device tree
+representation of an Open PIC compliant interrupt controller.  This binding is
+based on the binding defined for Open PIC in [1] and is a superset of that
+binding.
+
+Required properties:
+
+  NOTE: Many of these descriptions were paraphrased here from [1] to aid
+        readability.
+
+    - compatible: Specifies the compatibility list for the PIC.  The type
+      shall be <string> and the value shall include "open-pic".
+
+    - reg: Specifies the base physical address(s) and size(s) of this
+      PIC's addressable register space.  The type shall be <prop-encoded-array>.
+
+    - interrupt-controller: The presence of this property identifies the node
+      as an Open PIC.  No property value shall be defined.
+
+    - #interrupt-cells: Specifies the number of cells needed to encode an
+      interrupt source.  The type shall be a <u32> and the value shall be 2.
+
+    - #address-cells: Specifies the number of cells needed to encode an
+      address.  The type shall be <u32> and the value shall be 0.  As such,
+      'interrupt-map' nodes do not have to specify a parent unit address.
+
+Optional properties:
+
+    - pic-no-reset: The presence of this property indicates that the PIC
+      shall not be reset during runtime initialization.  No property value shall
+      be defined.  The presence of this property also mandates that any
+      initialization related to interrupt sources shall be limited to sources
+      explicitly referenced in the device tree.
+
+* Interrupt Specifier Definition
+
+  Interrupt specifiers consists of 2 cells encoded as
+  follows:
+
+    - <1st-cell>: The interrupt-number that identifies the interrupt source.
+
+    - <2nd-cell>: The level-sense information, encoded as follows:
+                    0 = low-to-high edge triggered
+                    1 = active low level-sensitive
+                    2 = active high level-sensitive
+                    3 = high-to-low edge triggered
+
+* Examples
+
+Example 1:
+
+	/*
+	 * An Open PIC interrupt controller
+	 */
+	mpic: pic@40000 {
+		// This is an interrupt controller node.
+		interrupt-controller;
+
+		// No address cells so that 'interrupt-map' nodes which reference
+		// this Open PIC node do not need a parent address specifier.
+		#address-cells = <0>;
+
+		// Two cells to encode interrupt sources.
+		#interrupt-cells = <2>;
+
+		// Offset address of 0x40000 and size of 0x40000.
+		reg = <0x40000 0x40000>;
+
+		// Compatible with Open PIC.
+		compatible = "open-pic";
+
+		// The PIC shall not be reset.
+		pic-no-reset;
+	};
+
+Example 2:
+
+	/*
+	 * An interrupt generating device that is wired to an Open PIC.
+	 */
+	serial0: serial@4500 {
+		// Interrupt source '42' that is active high level-sensitive.
+		// Note that there are only two cells as specified in the interrupt
+		// parent's '#interrupt-cells' property.
+		interrupts = <42 2>;
+
+		// The interrupt controller that this device is wired to.
+		interrupt-parent = <&mpic>;
+	};
+
+* References
+
+[1] Power.org (TM) Standard for Embedded Power Architecture (TM) Platform
+    Requirements (ePAPR), Version 1.0, July 2008.
+    (http://www.power.org/resources/downloads/Power_ePAPR_APPROVED_v1.0.pdf)
+

Documentation/dvb/get_dvb_firmware

@@ -556,6 +556,9 @@ sub ngene {
     my $hash1 = "d798d5a757121174f0dbc5f2833c0c85";
     my $file2 = "ngene_17.fw";
     my $hash2 = "26b687136e127b8ac24b81e0eeafc20b";
+    my $url2 = "http://l4m-daten.de/downloads/firmware/dvb-s2/linux/all/";
+    my $file3 = "ngene_18.fw";
+    my $hash3 = "ebce3ea769a53e3e0b0197c3b3f127e3";

     checkstandard();

@@ -565,7 +568,10 @@ sub ngene {
     wgetfile($file2, $url . $file2);
     verify($file2, $hash2);

-    "$file1, $file2";
+    wgetfile($file3, $url2 . $file3);
+    verify($file3, $hash3);
+
+    "$file1, $file2, $file3";
 }

 sub az6027{

Documentation/dvb/lmedm04.txt

@@ -4,7 +4,7 @@ following file(s) to this directory.
 for DM04+/QQBOX LME2510C (Sharp 7395 Tuner)
 -------------------------------------------

-The Sharp 7395 driver can be found in windows/system32/driver
+The Sharp 7395 driver can be found in windows/system32/drivers

 US2A0D.sys (dated 17 Mar 2009)

@@ -44,7 +44,7 @@ and run


 Other LG firmware can be extracted manually from US280D.sys
-only found in windows/system32/driver.
+only found in windows/system32/drivers

 dd if=US280D.sys ibs=1 skip=42360 count=3924 of=dvb-usb-lme2510-lg.fw

@@ -55,4 +55,16 @@ dd if=US280D.sys ibs=1 skip=35200 count=3850 of=dvb-usb-lme2510c-lg.fw

 ---------------------------------------------------------------------

+The Sharp 0194 tuner driver can be found in windows/system32/drivers
+
+US290D.sys (dated 09 Apr 2009)
+
+For LME2510
+dd if=US290D.sys ibs=1 skip=36856 count=3976 of=dvb-usb-lme2510-s0194.fw
+
+
+For LME2510C
+dd if=US290D.sys ibs=1 skip=33152 count=3697 of=dvb-usb-lme2510c-s0194.fw
+
+
 Copy the firmware file(s) to /lib/firmware

Documentation/dynamic-debug-howto.txt

@@ -6,7 +6,7 @@ This document describes how to use the dynamic debug (ddebug) feature.

 Dynamic debug is designed to allow you to dynamically enable/disable kernel
 code to obtain additional kernel information. Currently, if
-CONFIG_DYNAMIC_DEBUG is set, then all pr_debug()/dev_debug() calls can be
+CONFIG_DYNAMIC_DEBUG is set, then all pr_debug()/dev_dbg() calls can be
 dynamically enabled per-callsite.

 Dynamic debug has even more useful features:
@@ -26,7 +26,7 @@ Dynamic debug has even more useful features:
 Controlling dynamic debug Behaviour
 ===================================

-The behaviour of pr_debug()/dev_debug()s are controlled via writing to a
+The behaviour of pr_debug()/dev_dbg()s are controlled via writing to a
 control file in the 'debugfs' filesystem. Thus, you must first mount the debugfs
 filesystem, in order to make use of this feature. Subsequently, we refer to the
 control file as: <debugfs>/dynamic_debug/control. For example, if you want to

Documentation/fb/sm501.txt

@@ -0,0 +1,10 @@
+Configuration:
+
+You can pass the following kernel command line options to sm501 videoframebuffer:
+
+	sm501fb.bpp=	SM501 Display driver:
+			Specifiy bits-per-pixel if not specified by 'mode'
+
+	sm501fb.mode=	SM501 Display driver:
+			Specify resolution as
+			"<xres>x<yres>[-<bpp>][@<refresh>]"

Documentation/feature-removal-schedule.txt

@@ -108,42 +108,6 @@ Who:	Pavel Machek <pavel@ucw.cz>

 ---------------------------

-What:	Video4Linux obsolete drivers using V4L1 API
-When:	kernel 2.6.39
-Files:	drivers/staging/se401/* drivers/staging/usbvideo/*
-Check:	drivers/staging/se401/se401.c drivers/staging/usbvideo/usbvideo.c
-Why:	There are some drivers still using V4L1 API, despite all efforts we've done
-	to migrate. Those drivers are for obsolete hardware that the old maintainer
-	didn't care (or not have the hardware anymore), and that no other developer
-	could find any hardware to buy. They probably have no practical usage today,
-	and people with such old hardware could probably keep using an older version
-	of the kernel. Those drivers will be moved to staging on 2.6.38 and, if nobody
-	cares enough to port and test them with V4L2 API, they'll be removed on 2.6.39.
-Who:	Mauro Carvalho Chehab <mchehab@infradead.org>
-
----------------------------
-
-What:	Video4Linux: Remove obsolete ioctl's
-When:	kernel 2.6.39
-Files:	include/media/videodev2.h
-Why:	Some ioctl's were defined wrong on 2.6.2 and 2.6.6, using the wrong
-	type of R/W arguments. They were fixed, but the old ioctl names are
-	still there, maintained to avoid breaking binary compatibility:
-	  #define VIDIOC_OVERLAY_OLD   	_IOWR('V', 14, int)
-	  #define VIDIOC_S_PARM_OLD	_IOW('V', 22, struct v4l2_streamparm)
-	  #define VIDIOC_S_CTRL_OLD	_IOW('V', 28, struct v4l2_control)
-	  #define VIDIOC_G_AUDIO_OLD	_IOWR('V', 33, struct v4l2_audio)
-	  #define VIDIOC_G_AUDOUT_OLD	_IOWR('V', 49, struct v4l2_audioout)
-	  #define VIDIOC_CROPCAP_OLD	_IOR('V', 58, struct v4l2_cropcap)
-	There's no sense on preserving those forever, as it is very doubtful
-	that someone would try to use a such old binary with a modern kernel.
-	Removing them will allow us to remove some magic done at the V4L ioctl
-	handler.
-
-Who:	Mauro Carvalho Chehab <mchehab@infradead.org>
-
----------------------------
-
 What:	sys_sysctl
 When:	September 2010
 Option: CONFIG_SYSCTL_SYSCALL
@@ -270,14 +234,6 @@ Who:	Zhang Rui <rui.zhang@intel.com>

 ---------------------------

-What:	/proc/acpi/button
-When:	August 2007
-Why:	/proc/acpi/button has been replaced by events to the input layer
-	since 2.6.20.
-Who:	Len Brown <len.brown@intel.com>
-
----------------------------
-
 What:	/proc/acpi/event
 When:	February 2008
 Why:	/proc/acpi/event has been replaced by events via the input layer
@@ -585,16 +541,6 @@ Who:    NeilBrown <neilb@suse.de>

 ----------------------------

-What:	i2c_adapter.id
-When:	June 2011
-Why:	This field is deprecated. I2C device drivers shouldn't change their
-	behavior based on the underlying I2C adapter. Instead, the I2C
-	adapter driver should instantiate the I2C devices and provide the
-	needed platform-specific information.
-Who:	Jean Delvare <khali@linux-fr.org>
-
-----------------------------
-
 What:	cancel_rearming_delayed_work[queue]()
 When:	2.6.39

@@ -645,3 +591,12 @@ Who:	Florian Westphal <fw@strlen.de>
 Files:	include/linux/netfilter_ipv4/ipt_addrtype.h

 ----------------------------
+
+What:	i2c_driver.attach_adapter
+	i2c_driver.detach_adapter
+When:	September 2011
+Why:	These legacy callbacks should no longer be used as i2c-core offers
+	a variety of preferable alternative ways to instantiate I2C devices.
+Who:	Jean Delvare <khali@linux-fr.org>
+
+----------------------------

Documentation/filesystems/Locking

@@ -128,7 +128,7 @@ alloc_inode:
 destroy_inode:
 dirty_inode:				(must not sleep)
 write_inode:
-drop_inode:				!!!inode_lock!!!
+drop_inode:				!!!inode->i_lock!!!
 evict_inode:
 put_super:		write
 write_super:		read

Documentation/filesystems/adfs.txt

@@ -9,6 +9,9 @@ Mount options for ADFS
 		will be nnn.  Default 0700.
   othmask=nnn	The permission mask for ADFS 'other' permissions
 		will be nnn.  Default 0077.
+  ftsuffix=n	When ftsuffix=0, no file type suffix will be applied.
+		When ftsuffix=1, a hexadecimal suffix corresponding to
+		the RISC OS file type will be added.  Default 0.

 Mapping of ADFS permissions to Linux permissions
 ------------------------------------------------
@@ -55,3 +58,18 @@ Mapping of ADFS permissions to Linux permissions

   You can therefore tailor the permission translation to whatever you
   desire the permissions should be under Linux.
+
+RISC OS file type suffix
+------------------------
+
+  RISC OS file types are stored in bits 19..8 of the file load address.
+
+  To enable non-RISC OS systems to be used to store files without losing
+  file type information, a file naming convention was devised (initially
+  for use with NFS) such that a hexadecimal suffix of the form ,xyz
+  denoted the file type: e.g. BasicFile,ffb is a BASIC (0xffb) file.  This
+  naming convention is now also used by RISC OS emulators such as RPCEmu.
+
+  Mounting an ADFS disc with option ftsuffix=1 will cause appropriate file
+  type suffixes to be appended to file names read from a directory.  If the
+  ftsuffix option is zero or omitted, no file type suffixes will be added.

Documentation/filesystems/exofs.txt

@@ -104,7 +104,15 @@ Where:
     exofs specific options: Options are separated by commas (,)
 		pid=<integer> - The partition number to mount/create as
                                 container of the filesystem.
-                                This option is mandatory.
+                                This option is mandatory. integer can be
+                                Hex by pre-pending an 0x to the number.
+		osdname=<id>  - Mount by a device's osdname.
+                                osdname is usually a 36 character uuid of the
+                                form "d2683732-c906-4ee1-9dbd-c10c27bb40df".
+                                It is one of the device's uuid specified in the
+                                mkfs.exofs format command.
+                                If this option is specified then the /dev/osdX
+                                above can be empty and is ignored.
                 to=<integer>  - Timeout in ticks for a single command.
                                 default is (60 * HZ) [for debugging only]


Documentation/filesystems/ext4.txt

@@ -367,12 +367,47 @@ init_itable=n		The lazy itable init code will wait n times the
 			minimizes the impact on the systme performance
 			while file system's inode table is being initialized.

-discard		Controls whether ext4 should issue discard/TRIM
+discard			Controls whether ext4 should issue discard/TRIM
 nodiscard(*)		commands to the underlying block device when
 			blocks are freed.  This is useful for SSD devices
 			and sparse/thinly-provisioned LUNs, but it is off
 			by default until sufficient testing has been done.

+nouid32			Disables 32-bit UIDs and GIDs.  This is for
+			interoperability  with  older kernels which only
+			store and expect 16-bit values.
+
+resize			Allows to resize filesystem to the end of the last
+			existing block group, further resize has to be done
+			with resize2fs either online, or offline. It can be
+			used only with conjunction with remount.
+
+block_validity		This options allows to enables/disables the in-kernel
+noblock_validity	facility for tracking filesystem metadata blocks
+			within internal data structures. This allows multi-
+			block allocator and other routines to quickly locate
+			extents which might overlap with filesystem metadata
+			blocks. This option is intended for debugging
+			purposes and since it negatively affects the
+			performance, it is off by default.
+
+dioread_lock		Controls whether or not ext4 should use the DIO read
+dioread_nolock		locking. If the dioread_nolock option is specified
+			ext4 will allocate uninitialized extent before buffer
+			write and convert the extent to initialized after IO
+			completes. This approach allows ext4 code to avoid
+			using inode mutex, which improves scalability on high
+			speed storages. However this does not work with nobh
+			option and the mount will fail. Nor does it work with
+			data journaling and dioread_nolock option will be
+			ignored with kernel warning. Note that dioread_nolock
+			code path is only used for extent-based files.
+			Because of the restrictions this options comprises
+			it is off by default (e.g. dioread_lock).
+
+i_version		Enable 64-bit inode version support. This option is
+			off by default.
+
 Data Mode
 =========
 There are 3 different data modes:
@@ -400,6 +435,176 @@ needs to be read from and written to disk at the same time where it
 outperforms all others modes.  Currently ext4 does not have delayed
 allocation support if this data journalling mode is selected.

+/proc entries
+=============
+
+Information about mounted ext4 file systems can be found in
+/proc/fs/ext4.  Each mounted filesystem will have a directory in
+/proc/fs/ext4 based on its device name (i.e., /proc/fs/ext4/hdc or
+/proc/fs/ext4/dm-0).   The files in each per-device directory are shown
+in table below.
+
+Files in /proc/fs/ext4/<devname>
+..............................................................................
+ File            Content
+ mb_groups       details of multiblock allocator buddy cache of free blocks
+..............................................................................
+
+/sys entries
+============
+
+Information about mounted ext4 file systems can be found in
+/sys/fs/ext4.  Each mounted filesystem will have a directory in
+/sys/fs/ext4 based on its device name (i.e., /sys/fs/ext4/hdc or
+/sys/fs/ext4/dm-0).   The files in each per-device directory are shown
+in table below.
+
+Files in /sys/fs/ext4/<devname>
+(see also Documentation/ABI/testing/sysfs-fs-ext4)
+..............................................................................
+ File                         Content
+
+ delayed_allocation_blocks    This file is read-only and shows the number of
+                              blocks that are dirty in the page cache, but
+                              which do not have their location in the
+                              filesystem allocated yet.
+
+ inode_goal                   Tuning parameter which (if non-zero) controls
+                              the goal inode used by the inode allocator in
+                              preference to all other allocation heuristics.
+                              This is intended for debugging use only, and
+                              should be 0 on production systems.
+
+ inode_readahead_blks         Tuning parameter which controls the maximum
+                              number of inode table blocks that ext4's inode
+                              table readahead algorithm will pre-read into
+                              the buffer cache
+
+ lifetime_write_kbytes        This file is read-only and shows the number of
+                              kilobytes of data that have been written to this
+                              filesystem since it was created.
+
+ max_writeback_mb_bump        The maximum number of megabytes the writeback
+                              code will try to write out before move on to
+                              another inode.
+
+ mb_group_prealloc            The multiblock allocator will round up allocation
+                              requests to a multiple of this tuning parameter if
+                              the stripe size is not set in the ext4 superblock
+
+ mb_max_to_scan               The maximum number of extents the multiblock
+                              allocator will search to find the best extent
+
+ mb_min_to_scan               The minimum number of extents the multiblock
+                              allocator will search to find the best extent
+
+ mb_order2_req                Tuning parameter which controls the minimum size
+                              for requests (as a power of 2) where the buddy
+                              cache is used
+
+ mb_stats                     Controls whether the multiblock allocator should
+                              collect statistics, which are shown during the
+                              unmount. 1 means to collect statistics, 0 means
+                              not to collect statistics
+
+ mb_stream_req                Files which have fewer blocks than this tunable
+                              parameter will have their blocks allocated out
+                              of a block group specific preallocation pool, so
+                              that small files are packed closely together.
+                              Each large file will have its blocks allocated
+                              out of its own unique preallocation pool.
+
+ session_write_kbytes         This file is read-only and shows the number of
+                              kilobytes of data that have been written to this
+                              filesystem since it was mounted.
+..............................................................................
+
+Ioctls
+======
+
+There is some Ext4 specific functionality which can be accessed by applications
+through the system call interfaces. The list of all Ext4 specific ioctls are
+shown in the table below.
+
+Table of Ext4 specific ioctls
+..............................................................................
+ Ioctl			      Description
+ EXT4_IOC_GETFLAGS	      Get additional attributes associated with inode.
+			      The ioctl argument is an integer bitfield, with
+			      bit values described in ext4.h. This ioctl is an
+			      alias for FS_IOC_GETFLAGS.
+
+ EXT4_IOC_SETFLAGS	      Set additional attributes associated with inode.
+			      The ioctl argument is an integer bitfield, with
+			      bit values described in ext4.h. This ioctl is an
+			      alias for FS_IOC_SETFLAGS.
+
+ EXT4_IOC_GETVERSION
+ EXT4_IOC_GETVERSION_OLD
+			      Get the inode i_generation number stored for
+			      each inode. The i_generation number is normally
+			      changed only when new inode is created and it is
+			      particularly useful for network filesystems. The
+			      '_OLD' version of this ioctl is an alias for
+			      FS_IOC_GETVERSION.
+
+ EXT4_IOC_SETVERSION
+ EXT4_IOC_SETVERSION_OLD
+			      Set the inode i_generation number stored for
+			      each inode. The '_OLD' version of this ioctl
+			      is an alias for FS_IOC_SETVERSION.
+
+ EXT4_IOC_GROUP_EXTEND	      This ioctl has the same purpose as the resize
+			      mount option. It allows to resize filesystem
+			      to the end of the last existing block group,
+			      further resize has to be done with resize2fs,
+			      either online, or offline. The argument points
+			      to the unsigned logn number representing the
+			      filesystem new block count.
+
+ EXT4_IOC_MOVE_EXT	      Move the block extents from orig_fd (the one
+			      this ioctl is pointing to) to the donor_fd (the
+			      one specified in move_extent structure passed
+			      as an argument to this ioctl). Then, exchange
+			      inode metadata between orig_fd and donor_fd.
+			      This is especially useful for online
+			      defragmentation, because the allocator has the
+			      opportunity to allocate moved blocks better,
+			      ideally into one contiguous extent.
+
+ EXT4_IOC_GROUP_ADD	      Add a new group descriptor to an existing or
+			      new group descriptor block. The new group
+			      descriptor is described by ext4_new_group_input
+			      structure, which is passed as an argument to
+			      this ioctl. This is especially useful in
+			      conjunction with EXT4_IOC_GROUP_EXTEND,
+			      which allows online resize of the filesystem
+			      to the end of the last existing block group.
+			      Those two ioctls combined is used in userspace
+			      online resize tool (e.g. resize2fs).
+
+ EXT4_IOC_MIGRATE	      This ioctl operates on the filesystem itself.
+			      It converts (migrates) ext3 indirect block mapped
+			      inode to ext4 extent mapped inode by walking
+			      through indirect block mapping of the original
+			      inode and converting contiguous block ranges
+			      into ext4 extents of the temporary inode. Then,
+			      inodes are swapped. This ioctl might help, when
+			      migrating from ext3 to ext4 filesystem, however
+			      suggestion is to create fresh ext4 filesystem
+			      and copy data from the backup. Note, that
+			      filesystem has to support extents for this ioctl
+			      to work.
+
+ EXT4_IOC_ALLOC_DA_BLKS	      Force all of the delay allocated blocks to be
+			      allocated to preserve application-expected ext3
+			      behaviour. Note that this will also start
+			      triggering a write of the data blocks, but this
+			      behaviour may change in the future as it is
+			      not necessary and has been done this way only
+			      for sake of simplicity.
+..............................................................................
+
 References
 ==========


Documentation/filesystems/porting

@@ -298,11 +298,14 @@ be used instead.  It gets called whenever the inode is evicted, whether it has
 remaining links or not.  Caller does *not* evict the pagecache or inode-associated
 metadata buffers; getting rid of those is responsibility of method, as it had
 been for ->delete_inode().
-	->drop_inode() returns int now; it's called on final iput() with inode_lock
-held and it returns true if filesystems wants the inode to be dropped.  As before,
-generic_drop_inode() is still the default and it's been updated appropriately.
-generic_delete_inode() is also alive and it consists simply of return 1.  Note that
-all actual eviction work is done by caller after ->drop_inode() returns.
+
+	->drop_inode() returns int now; it's called on final iput() with
+inode->i_lock held and it returns true if filesystems wants the inode to be
+dropped.  As before, generic_drop_inode() is still the default and it's been
+updated appropriately.  generic_delete_inode() is also alive and it consists
+simply of return 1.  Note that all actual eviction work is done by caller after
+->drop_inode() returns.
+
 	clear_inode() is gone; use end_writeback() instead.  As before, it must
 be called exactly once on each call of ->evict_inode() (as it used to be for
 each call of ->delete_inode()).  Unlike before, if you are using inode-associated
@@ -395,6 +398,9 @@ Currently you can only have FALLOC_FL_PUNCH_HOLE with FALLOC_FL_KEEP_SIZE set,
 so the i_size should not change when hole punching, even when puching the end of
 a file off.

+--
+[mandatory]
+
 --
 [mandatory]
 	->get_sb() is gone.  Switch to use of ->mount().  Typically it's just

Documentation/filesystems/squashfs.txt

@@ -59,12 +59,15 @@ obtained from this site also.
 3. SQUASHFS FILESYSTEM DESIGN
 -----------------------------

-A squashfs filesystem consists of a maximum of eight parts, packed together on a byte
-alignment:
+A squashfs filesystem consists of a maximum of nine parts, packed together on a
+byte alignment:

 	 ---------------
 	|  superblock 	|
 	|---------------|
+	|  compression  |
+	|    options    |
+	|---------------|
 	|  datablocks   |
 	|  & fragments  |
 	|---------------|
@@ -91,7 +94,14 @@ the source directory, and checked for duplicates.  Once all file data has been
 written the completed inode, directory, fragment, export and uid/gid lookup
 tables are written.

-3.1 Inodes
+3.1 Compression options
+-----------------------
+
+Compressors can optionally support compression specific options (e.g.
+dictionary size).  If non-default compression options have been used, then
+these are stored here.
+
+3.2 Inodes
 ----------

 Metadata (inodes and directories) are compressed in 8Kbyte blocks.  Each
@@ -114,7 +124,7 @@ directory inode are defined: inodes optimised for frequently occurring
 regular files and directories, and extended types where extra
 information has to be stored.

-3.2 Directories
+3.3 Directories
 ---------------

 Like inodes, directories are packed into compressed metadata blocks, stored
@@ -144,7 +154,7 @@ decompressed to do a lookup irrespective of the length of the directory.
 This scheme has the advantage that it doesn't require extra memory overhead
 and doesn't require much extra storage on disk.

-3.3 File data
+3.4 File data
 -------------

 Regular files consist of a sequence of contiguous compressed blocks, and/or a
@@ -163,7 +173,7 @@ Larger files use multiple slots, with 1.75 TiB files using all 8 slots.
 The index cache is designed to be memory efficient, and by default uses
 16 KiB.

-3.4 Fragment lookup table
+3.5 Fragment lookup table
 -------------------------

 Regular files can contain a fragment index which is mapped to a fragment
@@ -173,7 +183,7 @@ A second index table is used to locate these.  This second index table for
 speed of access (and because it is small) is read at mount time and cached
 in memory.

-3.5 Uid/gid lookup table
+3.6 Uid/gid lookup table
 ------------------------

 For space efficiency regular files store uid and gid indexes, which are
@@ -182,7 +192,7 @@ stored compressed into metadata blocks.  A second index table is used to
 locate these.  This second index table for speed of access (and because it
 is small) is read at mount time and cached in memory.

-3.6 Export table
+3.7 Export table
 ----------------

 To enable Squashfs filesystems to be exportable (via NFS etc.) filesystems
@@ -196,7 +206,7 @@ This table is stored compressed into metadata blocks.  A second index table is
 used to locate these.  This second index table for speed of access (and because
 it is small) is read at mount time and cached in memory.

-3.7 Xattr table
+3.8 Xattr table
 ---------------

 The xattr table contains extended attributes for each inode.  The xattrs

Documentation/filesystems/vfs.txt

@@ -254,7 +254,7 @@ or bottom half).
 	should be synchronous or not, not all filesystems check this flag.

   drop_inode: called when the last access to the inode is dropped,
-	with the inode_lock spinlock held.
+	with the inode->i_lock spinlock held.

 	This method should be either NULL (normal UNIX filesystem
 	semantics) or "generic_delete_inode" (for filesystems that do not

Documentation/filesystems/xfs-delayed-logging-design.txt

@@ -791,10 +791,3 @@ mount option. Fundamentally, there is no reason why the log manager would not
 be able to swap methods automatically and transparently depending on load
 characteristics, but this should not be necessary if delayed logging works as
 designed.
-
-Roadmap:
-
-2.6.39 Switch default mount option to use delayed logging
-	=> should be roughly 12 months after initial merge
-	=> enough time to shake out remaining problems before next round of
-	   enterprise distro kernel rebases

Documentation/hwmon/ads1015

@@ -0,0 +1,72 @@
+Kernel driver ads1015
+=====================
+
+Supported chips:
+  * Texas Instruments ADS1015
+    Prefix: 'ads1015'
+    Datasheet: Publicly available at the Texas Instruments website :
+               http://focus.ti.com/lit/ds/symlink/ads1015.pdf
+
+Authors:
+        Dirk Eibach, Guntermann & Drunck GmbH <eibach@gdsys.de>
+
+Description
+-----------
+
+This driver implements support for the Texas Instruments ADS1015.
+
+This device is a 12-bit A-D converter with 4 inputs.
+
+The inputs can be used single ended or in certain differential combinations.
+
+The inputs can be made available by 8 sysfs input files in0_input - in7_input:
+in0: Voltage over AIN0 and AIN1.
+in1: Voltage over AIN0 and AIN3.
+in2: Voltage over AIN1 and AIN3.
+in3: Voltage over AIN2 and AIN3.
+in4: Voltage over AIN0 and GND.
+in5: Voltage over AIN1 and GND.
+in6: Voltage over AIN2 and GND.
+in7: Voltage over AIN3 and GND.
+
+Which inputs are available can be configured using platform data or devicetree.
+
+By default all inputs are exported.
+
+Platform Data
+-------------
+
+In linux/i2c/ads1015.h platform data is defined, channel_data contains
+configuration data for the used input combinations:
+- pga is the programmable gain amplifier (values are full scale)
+  0: +/- 6.144 V
+  1: +/- 4.096 V
+  2: +/- 2.048 V
+  3: +/- 1.024 V
+  4: +/- 0.512 V
+  5: +/- 0.256 V
+- data_rate in samples per second
+  0: 128
+  1: 250
+  2: 490
+  3: 920
+  4: 1600
+  5: 2400
+  6: 3300
+
+Example:
+struct ads1015_platform_data data = {
+	.channel_data = {
+		[2] = { .enabled = true, .pga = 1, .data_rate = 0 },
+		[4] = { .enabled = true, .pga = 4, .data_rate = 5 },
+	}
+};
+
+In this case only in2_input (FS +/- 4.096 V, 128 SPS) and in4_input
+(FS +/- 0.512 V, 2400 SPS) would be created.
+
+Devicetree
+----------
+
+Configuration is also possible via devicetree:
+Documentation/devicetree/bindings/hwmon/ads1015.txt

Documentation/hwmon/f71882fg

@@ -2,6 +2,10 @@ Kernel driver f71882fg
 ======================

 Supported chips:
+  * Fintek F71808E
+    Prefix: 'f71808e'
+    Addresses scanned: none, address read from Super I/O config space
+    Datasheet: Not public
   * Fintek F71858FG
     Prefix: 'f71858fg'
     Addresses scanned: none, address read from Super I/O config space
@@ -26,10 +30,25 @@ Supported chips:
     Prefix: 'f71889ed'
     Addresses scanned: none, address read from Super I/O config space
     Datasheet: Should become available on the Fintek website soon
+  * Fintek F71889A
+    Prefix: 'f71889a'
+    Addresses scanned: none, address read from Super I/O config space
+    Datasheet: Should become available on the Fintek website soon
   * Fintek F8000
     Prefix: 'f8000'
     Addresses scanned: none, address read from Super I/O config space
     Datasheet: Not public
+  * Fintek F81801U
+    Prefix: 'f71889fg'
+    Addresses scanned: none, address read from Super I/O config space
+    Datasheet: Not public
+    Note: This is the 64-pin variant of the F71889FG, they have the
+	  same device ID and are fully compatible as far as hardware
+	  monitoring is concerned.
+  * Fintek F81865F
+    Prefix: 'f81865f'
+    Addresses scanned: none, address read from Super I/O config space
+    Datasheet: Available from the Fintek website

 Author: Hans de Goede <hdegoede@redhat.com>


Documentation/hwmon/lm75

@@ -7,6 +7,11 @@ Supported chips:
     Addresses scanned: I2C 0x48 - 0x4f
     Datasheet: Publicly available at the National Semiconductor website
                http://www.national.com/
+  * National Semiconductor LM75A
+    Prefix: 'lm75a'
+    Addresses scanned: I2C 0x48 - 0x4f
+    Datasheet: Publicly available at the National Semiconductor website
+               http://www.national.com/
   * Dallas Semiconductor DS75
     Prefix: 'lm75'
     Addresses scanned: I2C 0x48 - 0x4f

Documentation/hwmon/sch5627

@@ -0,0 +1,22 @@
+Kernel driver sch5627
+=====================
+
+Supported chips:
+  * SMSC SCH5627
+    Prefix: 'sch5627'
+    Addresses scanned: none, address read from Super I/O config space
+    Datasheet: Application Note available upon request
+
+Author: Hans de Goede <hdegoede@redhat.com>
+
+
+Description
+-----------
+
+SMSC SCH5627 Super I/O chips include complete hardware monitoring
+capabilities. They can monitor up to 5 voltages, 4 fans and 8 temperatures.
+
+The hardware monitoring part of the SMSC SCH5627 is accessed by talking
+through an embedded microcontroller. An application note describing the
+protocol for communicating with the microcontroller is available upon
+request. Please mail me if you want a copy.

Documentation/hwmon/twl4030-madc-hwmon

@@ -0,0 +1,45 @@
+Kernel driver twl4030-madc
+=========================
+
+Supported chips:
+	* Texas Instruments TWL4030
+	Prefix: 'twl4030-madc'
+
+
+Authors:
+	J Keerthy <j-keerthy@ti.com>
+
+Description
+-----------
+
+The Texas Instruments TWL4030 is a Power Management and Audio Circuit. Among
+other things it contains a 10-bit A/D converter MADC. The converter has 16
+channels which can be used in different modes.
+
+
+See this table for the meaning of the different channels
+
+Channel Signal
+------------------------------------------
+0	Battery type(BTYPE)
+1	BCI: Battery temperature (BTEMP)
+2	GP analog input
+3	GP analog input
+4	GP analog input
+5	GP analog input
+6	GP analog input
+7	GP analog input
+8	BCI: VBUS voltage(VBUS)
+9	Backup Battery voltage (VBKP)
+10	BCI: Battery charger current (ICHG)
+11	BCI: Battery charger voltage (VCHG)
+12	BCI: Main battery voltage (VBAT)
+13	Reserved
+14	Reserved
+15	VRUSB Supply/Speaker left/Speaker right polarization level
+
+
+The Sysfs nodes will represent the voltage in the units of mV,
+the temperature channel shows the converted temperature in
+degree celcius. The Battery charging current channel represents
+battery charging current in mA.

Documentation/hwmon/w83795

@@ -0,0 +1,127 @@
+Kernel driver w83795
+====================
+
+Supported chips:
+  * Winbond/Nuvoton W83795G
+    Prefix: 'w83795g'
+    Addresses scanned: I2C 0x2c - 0x2f
+    Datasheet: Available for download on nuvoton.com
+  * Winbond/Nuvoton W83795ADG
+    Prefix: 'w83795adg'
+    Addresses scanned: I2C 0x2c - 0x2f
+    Datasheet: Available for download on nuvoton.com
+
+Authors:
+    Wei Song (Nuvoton)
+    Jean Delvare <khali@linux-fr.org>
+
+
+Pin mapping
+-----------
+
+Here is a summary of the pin mapping for the W83795G and W83795ADG.
+This can be useful to convert data provided by board manufacturers
+into working libsensors configuration statements.
+
+    W83795G			|
+  Pin	| Name			| Register	| Sysfs attribute
+------------------------------------------------------------------
+   13	| VSEN1 (VCORE1)	| 10h		| in0
+   14	| VSEN2 (VCORE2)	| 11h		| in1
+   15	| VSEN3 (VCORE3)	| 12h		| in2
+   16	| VSEN4			| 13h		| in3
+   17	| VSEN5			| 14h		| in4
+   18	| VSEN6			| 15h		| in5
+   19	| VSEN7			| 16h		| in6
+   20	| VSEN8			| 17h		| in7
+   21	| VSEN9			| 18h		| in8
+   22	| VSEN10		| 19h		| in9
+   23	| VSEN11		| 1Ah		| in10
+   28	| VTT			| 1Bh		| in11
+   24	| 3VDD			| 1Ch		| in12
+   25	| 3VSB			| 1Dh		| in13
+   26	| VBAT			| 1Eh		| in14
+    3	| VSEN12/TR5		| 1Fh		| in15/temp5
+    4	| VSEN13/TR5		| 20h		| in16/temp6
+  5/  6	| VDSEN14/TR1/TD1	| 21h		| in17/temp1
+  7/  8	| VDSEN15/TR2/TD2	| 22h		| in18/temp2
+  9/ 10	| VDSEN16/TR3/TD3	| 23h		| in19/temp3
+ 11/ 12	| VDSEN17/TR4/TD4	| 24h		| in20/temp4
+   40	| FANIN1		| 2Eh		| fan1
+   42	| FANIN2		| 2Fh		| fan2
+   44	| FANIN3		| 30h		| fan3
+   46	| FANIN4		| 31h		| fan4
+   48	| FANIN5		| 32h		| fan5
+   50	| FANIN6		| 33h		| fan6
+   52	| FANIN7		| 34h		| fan7
+   54	| FANIN8		| 35h		| fan8
+   57	| FANIN9		| 36h		| fan9
+   58	| FANIN10		| 37h		| fan10
+   59	| FANIN11		| 38h		| fan11
+   60	| FANIN12		| 39h		| fan12
+   31	| FANIN13		| 3Ah		| fan13
+   35	| FANIN14		| 3Bh		| fan14
+   41	| FANCTL1		| 10h (bank 2)	| pwm1
+   43	| FANCTL2		| 11h (bank 2)	| pwm2
+   45	| FANCTL3		| 12h (bank 2)	| pwm3
+   47	| FANCTL4		| 13h (bank 2)	| pwm4
+   49	| FANCTL5		| 14h (bank 2)	| pwm5
+   51	| FANCTL6		| 15h (bank 2)	| pwm6
+   53	| FANCTL7		| 16h (bank 2)	| pwm7
+   55	| FANCTL8		| 17h (bank 2)	| pwm8
+ 29/ 30	| PECI/TSI (DTS1)	| 26h		| temp7
+ 29/ 30	| PECI/TSI (DTS2)	| 27h		| temp8
+ 29/ 30	| PECI/TSI (DTS3)	| 28h		| temp9
+ 29/ 30	| PECI/TSI (DTS4)	| 29h		| temp10
+ 29/ 30	| PECI/TSI (DTS5)	| 2Ah		| temp11
+ 29/ 30	| PECI/TSI (DTS6)	| 2Bh		| temp12
+ 29/ 30	| PECI/TSI (DTS7)	| 2Ch		| temp13
+ 29/ 30	| PECI/TSI (DTS8)	| 2Dh		| temp14
+   27	| CASEOPEN#		| 46h		| intrusion0
+
+    W83795ADG			|
+  Pin	| Name			| Register	| Sysfs attribute
+------------------------------------------------------------------
+   10	| VSEN1 (VCORE1)	| 10h		| in0
+   11	| VSEN2 (VCORE2)	| 11h		| in1
+   12	| VSEN3 (VCORE3)	| 12h		| in2
+   13	| VSEN4			| 13h		| in3
+   14	| VSEN5			| 14h		| in4
+   15	| VSEN6			| 15h		| in5
+   16	| VSEN7			| 16h		| in6
+   17	| VSEN8			| 17h		| in7
+   22	| VTT			| 1Bh		| in11
+   18	| 3VDD			| 1Ch		| in12
+   19	| 3VSB			| 1Dh		| in13
+   20	| VBAT			| 1Eh		| in14
+   48	| VSEN12/TR5		| 1Fh		| in15/temp5
+    1	| VSEN13/TR5		| 20h		| in16/temp6
+  2/  3	| VDSEN14/TR1/TD1	| 21h		| in17/temp1
+  4/  5	| VDSEN15/TR2/TD2	| 22h		| in18/temp2
+  6/  7	| VDSEN16/TR3/TD3	| 23h		| in19/temp3
+  8/  9	| VDSEN17/TR4/TD4	| 24h		| in20/temp4
+   32	| FANIN1		| 2Eh		| fan1
+   34	| FANIN2		| 2Fh		| fan2
+   36	| FANIN3		| 30h		| fan3
+   37	| FANIN4		| 31h		| fan4
+   38	| FANIN5		| 32h		| fan5
+   39	| FANIN6		| 33h		| fan6
+   40	| FANIN7		| 34h		| fan7
+   41	| FANIN8		| 35h		| fan8
+   43	| FANIN9		| 36h		| fan9
+   44	| FANIN10		| 37h		| fan10
+   45	| FANIN11		| 38h		| fan11
+   46	| FANIN12		| 39h		| fan12
+   24	| FANIN13		| 3Ah		| fan13
+   28	| FANIN14		| 3Bh		| fan14
+   33	| FANCTL1		| 10h (bank 2)	| pwm1
+   35	| FANCTL2		| 11h (bank 2)	| pwm2
+   23	| PECI (DTS1)		| 26h		| temp7
+   23	| PECI (DTS2)		| 27h		| temp8
+   23	| PECI (DTS3)		| 28h		| temp9
+   23	| PECI (DTS4)		| 29h		| temp10
+   23	| PECI (DTS5)		| 2Ah		| temp11
+   23	| PECI (DTS6)		| 2Bh		| temp12
+   23	| PECI (DTS7)		| 2Ch		| temp13
+   23	| PECI (DTS8)		| 2Dh		| temp14
+   21	| CASEOPEN#		| 46h		| intrusion0

Documentation/i2c/busses/i2c-diolan-u2c

@@ -0,0 +1,26 @@
+Kernel driver i2c-diolan-u2c
+
+Supported adapters:
+  * Diolan U2C-12 I2C-USB adapter
+    Documentation:
+	http://www.diolan.com/i2c/u2c12.html
+
+Author: Guenter Roeck <guenter.roeck@ericsson.com>
+
+Description
+-----------
+
+This is the driver for the Diolan U2C-12 USB-I2C adapter.
+
+The Diolan U2C-12 I2C-USB Adapter provides a low cost solution to connect
+a computer to I2C slave devices using a USB interface. It also supports
+connectivity to SPI devices.
+
+This driver only supports the I2C interface of U2C-12. The driver does not use
+interrupts.
+
+
+Module parameters
+-----------------
+
+* frequency: I2C bus frequency

Documentation/i2c/busses/i2c-i801

@@ -16,8 +16,9 @@ Supported adapters:
   * Intel EP80579 (Tolapai)
   * Intel 82801JI (ICH10)
   * Intel 5/3400 Series (PCH)
-  * Intel Cougar Point (PCH)
+  * Intel 6 Series (PCH)
   * Intel Patsburg (PCH)
+  * Intel DH89xxCC (PCH)
    Datasheets: Publicly available at the Intel website

 On Intel Patsburg and later chipsets, both the normal host SMBus controller

Documentation/i2c/instantiating-devices

@@ -100,7 +100,7 @@ static int __devinit usb_hcd_pnx4008_probe(struct platform_device *pdev)
 	(...)
 	i2c_adap = i2c_get_adapter(2);
 	memset(&i2c_info, 0, sizeof(struct i2c_board_info));
-	strlcpy(i2c_info.name, "isp1301_pnx", I2C_NAME_SIZE);
+	strlcpy(i2c_info.type, "isp1301_pnx", I2C_NAME_SIZE);
 	isp1301_i2c_client = i2c_new_probed_device(i2c_adap, &i2c_info,
 						   normal_i2c, NULL);
 	i2c_put_adapter(i2c_adap);

Documentation/i2c/upgrading-clients

@@ -61,7 +61,7 @@ static int example_attach(struct i2c_adapter *adap, int addr, int kind)
 	return 0;
 }

-static int __devexit example_detach(struct i2c_client *client)
+static int example_detach(struct i2c_client *client)
 {
 	struct example_state *state = i2c_get_clientdata(client);

@@ -81,7 +81,7 @@ static struct i2c_driver example_driver = {
 		.name		= "example",
 	},
 	.attach_adapter = example_attach_adapter,
-	.detach_client	= __devexit_p(example_detach),
+	.detach_client	= example_detach,
 	.suspend	= example_suspend,
 	.resume		= example_resume,
 };
@@ -93,7 +93,7 @@ Updating the client
 The new style binding model will check against a list of supported
 devices and their associated address supplied by the code registering
 the busses. This means that the driver .attach_adapter and
-.detach_adapter methods can be removed, along with the addr_data,
+.detach_client methods can be removed, along with the addr_data,
 as follows:

 - static struct i2c_driver example_driver;
@@ -110,14 +110,14 @@ as follows:

  static struct i2c_driver example_driver = {
 -	.attach_adapter = example_attach_adapter,
--	.detach_client	= __devexit_p(example_detach),
+-	.detach_client	= example_detach,
  }

 Add the probe and remove methods to the i2c_driver, as so:

  static struct i2c_driver example_driver = {
 +	.probe		= example_probe,
-+	.remove		= __devexit_p(example_remove),
++	.remove		= example_remove,
  }

 Change the example_attach method to accept the new parameters
@@ -199,8 +199,8 @@ to delete the i2c_detach_client call. It is possible that you
 can also remove the ret variable as it is not not needed for
 any of the core functions.

-- static int __devexit example_detach(struct i2c_client *client)
-+ static int __devexit example_remove(struct i2c_client *client)
+- static int example_detach(struct i2c_client *client)
++ static int example_remove(struct i2c_client *client)
 {
 	struct example_state *state = i2c_get_clientdata(client);

@@ -253,7 +253,7 @@ static int example_probe(struct i2c_client *client,
 	return 0;
 }

-static int __devexit example_remove(struct i2c_client *client)
+static int example_remove(struct i2c_client *client)
 {
 	struct example_state *state = i2c_get_clientdata(client);

@@ -275,7 +275,7 @@ static struct i2c_driver example_driver = {
 	},
 	.id_table	= example_idtable,
 	.probe		= example_probe,
-	.remove		= __devexit_p(example_remove),
+	.remove		= example_remove,
 	.suspend	= example_suspend,
 	.resume		= example_resume,
 };
